Driver Manual
(Supplement to the FieldServer Instruction Manual)
FS-8704-02 BACnet Ethernet
APPLICABILITY & EFFECTIVITY
Effective for all systems manufactured after May 1, 2001
Driver Version:
1.15
Document Revision: 17

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FS-8704-02 and is the answer not in the manual?

Questions and answers

Summary of Contents for FieldServer FS-8704-02

  • Page 1 A Sierra Monitor Company Driver Manual (Supplement to the FieldServer Instruction Manual) FS-8704-02 BACnet Ethernet APPLICABILITY & EFFECTIVITY Effective for all systems manufactured after May 1, 2001 Driver Version: 1.15 Document Revision: 17...

  • Page 2: Table Of Contents

    FS-8704-02_BacnetEthernet.doc Driver Manual BACnet Ethernet Description...3 Driver Scope of Supply...4 2.1. Supplied by FieldServer Technologies for this driver ...4 2.2. Provided by the Supplier of 3 2.2.1. Hardware...4 Hardware Connections ...5 Configuring the FieldServer as a BACnet Ethernet Client ...6 4.1.

  • Page 3: Bacnet Ethernet Description

    FS-8704-02_BacnetEthernet.doc Driver Manual Page 3 of 20 BACnet Ethernet Description The BACnet Ethernet driver allows the FieldServer to transfer data to and from devices over Ethernet using BACnet Ethernet protocol. The FieldServer can emulate either a Server or Client. The information that follows describes how to expand upon the factory defaults provided in the configuration files included with the FieldServer.

  • Page 4: Driver Scope Of Supply

    FS-8704-02_BacnetEthernet.doc Driver Manual Driver Scope of Supply 2.1. Supplied by FieldServer Technologies for this driver FieldServer Technologies PART # FS-8915-10 FS-8704-02 2.2. Provided by the Supplier of 3 2.2.1. Hardware Part # Trane Building Control Unit (BCU) ∗ Not all FieldServer models support 100BaseT. Consult the appropriate instruction manual for details of the Ethernet speed supported by specific hardware.

  • Page 5: Hardware Connections

    FS-8704-02_BacnetEthernet.doc Driver Manual Hardware Connections It is possible to connect a BACnet Ethernet device using the N1 or the N2 network ports. These ports just need to be configured for BACnet Ethernet in the configuration file. Configure the Controller according to manufacturer’s instructions FS-8915-10 FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com...

  • Page 6: Configuring The Fieldserver As A Bacnet Ethernet Client

    FS-8704-02_BacnetEthernet.doc Driver Manual Configuring the FieldServer as a BACnet Ethernet Client For a detailed discussion on FieldServer configuration, please refer to the FieldServer Configuration Manual. The information that follows describes how to expand upon the factory defaults provided in the configuration files included with the FieldServer (See “.csv” sample files provided with the FieldServer).

  • Page 7: Client Side Node Descriptors

    FS-8704-02_BacnetEthernet.doc Driver Manual Example Client Side Connections Connections Adapter, 4.3. Client Side Node Descriptors Section Title Nodes Column Title Node_Name Node_ID Protocol Adapter Example Client Side Nodes Nodes Node_Name, Node_ID, BCU_01, FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com Protocol, Bacnet_Eth,...

  • Page 8: Client Side Map Descriptors

    FS-8704-02_BacnetEthernet.doc Driver Manual 4.4. Client Side Map Descriptors 4.4.1. FieldServer Related Map Descriptor Parameters Column Title Map_Descriptor_Name Data_Array_Name Data_Array_Offset Function 4.4.2. Driver Related Map Descriptor Parameters Column Title Node_Name Data_Type Property Data_Array_Low_Scale* Data_Array_High_Scale* Node_Low_Scale* Node_High_Scale* 4.4.3. Timing Parameters Column Title Scan_Interval Note 2 - ANALOG INPUT...

  • Page 9: Map Descriptor Examples

    FS-8704-02_BacnetEthernet.doc Driver Manual 4.4.4. Map Descriptor Examples Client Side Map Descriptors Map_Descriptors Map_Descriptor_Name, Data_Array_Name, CMD_AI_01, DA_AI_01, CMD_AI_02, DA_AI_01, CMD_AI_03, DA_AI_01, CMD_AO_01, DA_AO_01, CMD_AO_02, DA_AO_01, CMD_AO_03, DA_AO_01, Map_Descriptors Map_Descriptor_Name, Data_Array_Name, CMD_DI_01, DA_DI_01, CMD_DI_02, DA_DI_01, CMD_DI_03, DA_DI_01, CMD_DO_01, DA_DO_01, CMD_DO_02, DA_DO_01, CMD_DO_03, DA_DO_01, FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com...

  • Page 10: Configuring The Fieldserver As A Bacnet Ethernet Server

    FS-8704-02_BacnetEthernet.doc Driver Manual Configuring the FieldServer as a BACnet Ethernet Server For a detailed discussion on FieldServer configuration, please refer to the FieldServer Configuration Manual. The information that follows describes how to expand upon the factory defaults provided in the configuration files included with the FieldServer (See “.csv” files on the driver CD).

  • Page 11: Server Side Node Descriptors

    FS-8704-02_BacnetEthernet.doc Driver Manual Example Server Side Connections Connections Adapter, 5.3. Server Side Node Descriptors Section Title Nodes Column Title Node_Name Node_ID Protocol Example Server Side Nodes Nodes Node_Name, Virtual_BCU_11, ∗ Note that no connection information is necessary on Server side. FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com Protocol...

  • Page 12: Server Side Map Descriptors

    FS-8704-02_BacnetEthernet.doc Driver Manual 5.4. Server Side Map Descriptors 5.4.1. FieldServer Specific Map Descriptor Parameters Column Title Map_Descriptor_Name Data_Array_Name Data_Array_Offset Function 5.4.2. Driver Specific Map Descriptor Parameters Column Title Node_Name Data_Type Object_ID Property Units Data_Array_Low_Scale* Data_Array_High_Scale* Node_Low_Scale* Node_High_Scale* Active_Text Inactive_Text1 Relinquish_Default1 Note 2 - ANALOG INPUT - ANALOG_OUTPUT...
  • Page 13 FS-8704-02_BacnetEthernet.doc Driver Manual Page 13 of 20 Object FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com...

  • Page 14: Map Descriptor Example

    FS-8704-02_BacnetEthernet.doc Driver Manual 5.4.3. Map Descriptor Example Server Side Map Descriptors Map_Descriptors Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, SMD_AI_01, DA_AI_01, SMD_AI_02, DA_AI_01, SMD_AI_03, DA_AI_01, SMD_AO_01, DA_AO_01, SMD_AO_02, DA_AO_01, SMD_AO_03, DA_AO_01, Server Side Map Descriptors Map_Descriptors Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, SMD_DI_01, DA_DI_01, SMD_DI_02, DA_DI_01, SMD_DI_03, DA_DI_01, SMD_DO_01, DA_DO_01,...

  • Page 15: Appendix A. Advanced Topics

    FS-8704-02_BacnetEthernet.doc Driver Manual Appendix A. Advanced Topics Appendix A.1. BACnet Object Names When an external BACnet Client builds a list of Object Names, the BACnet Server Map Descriptor name determines the BACnet Object Name. If the Map Descriptor length is greater than 1, then the Object Name will be suffixed with the index into the Map Descriptor.

  • Page 16: Appendix B. Troubleshooting

    Poll only the BACnet addresses that exist in the device when communicating with Liebert systems. Polling addresses that are not configured in these systems will cause the connection to fail. The newer versions of Lieberts do not suffer from this problem.

  • Page 17: Appendix C. Units

    FS-8704-02_BacnetEthernet.doc Driver Manual Appendix C. Units Unit Amperes Bars BTUs BTUs-per-hour btus-per-pound btus-per-pound-dry-air centimeters centimeters-of-mercury centimeters-of-water cubic-feet cubic-feet-per-minute cubic-feet-per-seconds cubic-meters cubic-meters-per-hour cubic-meters-per-seconds Currency1 Currency2 Currency3 Currency4 Currency5 Currency6 Currency7 Currency8 Currency9 Currency10 cycles-per-hour cycles-per-minute days degrees-angular Degrees-Celsius degrees-celsius-per-hour degrees-celsius-per-minute Degrees-days-Celsius Degrees-days-Fahrenheit Degrees-Fahrenheit degrees-fahrenheit-per-hour...
  • Page 18 FS-8704-02_BacnetEthernet.doc Driver Manual Unit imperial-gallons imperial-gallons-per-min inches inches-of-mercury inches-of-water Joules joules-per-degree-kelvin joules-per-kilogram-degree-kelvin joules-per-kilogram-dry-air Kilograms kilograms-per-hour kilograms-per-minute kilograms-per-second Kilohertz kilohms Kilojoules kilojoules-per-kilogram kilometers-per-hour Kilopascals kilovolt-amperes kilovolt-amperes-reactive kilovolts kilowatt-hour-per-square-foot kilowatt-hour-per-square-meter kilowatt-hours kilowatts liters liters-per-hour liters-per-minute liters-per-second lumens luxes Megahertz megajoules megajoules-per-square-foot megajoules-per-square-meter megavolt-amperes Megavolt-amperes-reactive megavolts...
  • Page 19 FS-8704-02_BacnetEthernet.doc Driver Manual Unit No-Units ohms parts-per-billion parts-per-million Pascals Percent percent-obscuration-per-foot percent-obscuration-per-meter percent-per-second percent-relative-humidity Per-hour per-minute per-second pounds-force-per-square-inch Pounds-mass pounds-mass-per-hour pounds-mass-per-minute pounds-mass-per-second Power-Factor psi-per-degrees-fahrenheit radians revolutions-per-minute seconds square-centimeters square-feet square-inches square-meters Therms ton-hours Tons Tons-refrigeration US-gallons us-gallons-per-minute Volt-Amperes volt-amperes-reactive Volts watt-hours Watts watts-per-square-foot...
  • Page 20 FS-8704-02_BacnetEthernet.doc Driver Manual Page 20 of 20 THIS PAGE INTENTIONALLY LEFT BLANK FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com...
