22 Litre Digital Microwave
User Guide
10 Sec/
Weight+
1 Min/
Weight-
10 Min
Model Number(s):
661043, 677336, 882457, 887747
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm
or visit us at
www.productcareuk.com
PLEASE RETAIN FOR FUTURE
REFERENCE
Advertisement
Table of Contents
Summary of Contents for Next 661043
- Page 1 1 Min/ Weight- 10 Min Model Number(s): 661043, 677336, 882457, 887747 For Customer Services & Spare Parts please call 0345 209 7461 Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm or visit us at www.productcareuk.com...
-
Page 2: Table Of Contents
CONTENTS Page(s) Safety instructions 3 – 4 Heating food – safety instructions 5 – 6 Cleaning your microwave About your microwave Product Information Unpacking your microwave Product overview 11 - 12 Microwave Installation 13 - 14 Turntable Installation Control Panel Using your microwave oven 17 –... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING: If the door or door seals are damaged, the oven must not be operated until it has been repaired by a competent person. WARNING: It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy. - Page 4 SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE This appliance is intended to be used in the household and general domestic applications. It is not intended to be used in industrial or commercial applications. This microwave is intended for heating food and beverages only.
-
Page 5: Heating Food - Safety Instructions
HEATING FOOD - SAFETY INSTRUCTIONS • Food containing a mixture of fat and water (for example, stock) should stand for 30 to 60 seconds in the oven after it has been turned off. This is to allow the mixture to settle and to prevent it from bubbling when a spoon is placed in it, or a stock cube is added. -
Page 6: Heating Food – Safety Instructions
HEATING FOOD - SAFETY INSTRUCTIONS • When heating food in plastic or paper containers, keep an eye on the oven due to the possibility of ignition. • If materials inside the oven smoke or catch fire, keep the oven door closed to stifle the flames, turn the oven off at the wall switch, or shut the power off at the fuse or circuit-breaker panel. -
Page 7: Cleaning Your Microwave
CLEANING YOUR MICROWAVE • Before you clean your microwave oven, turn it off and unplug it. • Keep the inside of the oven clean. When food or liquids stick to the oven walls, wipe with a damp cloth. We recommend that you do not use harsh detergent or abrasives. -
Page 8: About Your Microwave
ABOUT YOUR MICROWAVE Microwaves are high-frequency electromagnetic waves similar to radio waves. While radio waves may vary in length from one metre to many kilometres, microwaves are very short (less than 12.5 centimetres). Microwaves do not make any heat themselves but cause water molecules in food to vibrate. -
Page 9: Product Information
PRODUCT INFORMATION Rated Voltage 230V – 240V ~ 50Hz Rated Input Power (Microwave) 1280 W Rated Output Power (Microwave) 750-800W Oven Capacity Turntable Diameter 245 mm External Dimensions (HxWxD) 282mm x 470mm x 397mm Net Weight; Approx 10.5kg Number of Power Levels Number of Auto cook menus Display Type LED Display... -
Page 10: Unpacking Your Microwave
UNPACKING THE MICROWAVE Before you use your microwave oven 1. Remove all the packaging. Do not remove the small piece of card from the right hand side of the cavity wall. (Please see the below image). This is called a wave-guide cover and allows the microwaves to pass through to cook the food and stop debris from entering the mechanical parts. -
Page 11: Product Overview
PRODUCT OVERVIEW Inside the oven cavity Waveguide Cover Door Safety Interlock Latches Turntable coupling Turntable Ring Glass Turntable For Customer Services & Spare Parts please call 0345 209 7461 Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm or visit us at www.productcareuk.com... -
Page 12: Product Overview
PRODUCT OVERVIEW Control Panel (Explanation on how to use this will be on page 19) 10 Sec/ Weight+ 1 Min/ Weight- 10 Min Power/Defrost/ Auto Menu Start/Cancel Control Panel For Customer Services & Spare Parts please call 0345 209 7461 Opening times: Monday - Friday 8am –... -
Page 13: Microwave Oven Installation
MICROWAVE OVEN INSTALLATION • Place the oven as far away from radios and televisions as possible. Using the oven may cause interference with the reception. • Plug the oven into a suitable 13 amp mains socket, make sure the voltage is the same as on the rating label (do not use extension cables or mains socket adaptors). - Page 14 MICROWAVE OVEN INSTALLATION The minimum installation height is 85cm. A minimum clearance of 20 cm is required between the oven and any adjacent walls. Leave a minimum clearance of 30cm above the oven. The rear surface of appliance should be placed against a wall. WARNING: DO NOT install the oven over a cooker or other heat or steam producing appliance as this will damage the microwave...
-
Page 15: Turntable Installation
TURNTABLE INSTALLATION • Before first use, check that any securing tape and all packaging has been removed from the glass tray and turntable ring assembly. • These parts must never be restricted from rotating. • Never place the glass tray upside down. •... -
Page 16: Control Panel
CONTROL PANEL Display: Cooking time, power, defrost, auto menu and weight information is shown. Please note that the display has 3 digits, and that the seconds increase in batches of 10 seconds. For example when increasing by 10 seconds, the display will increase from 00.1 to 00.2 etc., for 10 minutes 50 seconds the display will show 10.5. -
Page 17: Using Your Microwave Oven
USING THE MICROWAVE OVEN MICROWAVE COOKING 1) Press the “POWER/DEFROST/AUTO MENU“ button once, and “P10” will display . 2) Press the “POWER/DEFROST/AUTO MENU“ button to step through the power levels until your desired microwave power level, "P10", "P7","P5", "P3","P1" is displayed. Press the “10 MIN”, “... -
Page 18: Timed Quick Start Cooking
USING THE MICROWAVE OVEN TIMED QUICK START COOKING “ 1 MIN/ WEIGHT – ” or 1) Press the “10 MIN”, “ 10 SEC/ WEIGHT + ” buttons to set the require cooking time (The time setting should be between 10 seconds and 59 minutes 50 seconds). This function cannot work under defrost and auto menu cooking 2) Press the “START/CANCEL“... -
Page 19: Defrost
USING THE MICROWAVE OVEN DEFROSTING BY WEIGHT 1) Press the “POWER/DEFROST/AUTO MENU“ button until “dE F” shown on the display. 2) Press the “ 10 SEC/ WEIGHT + ” and the “ 1 MIN/ WEIGHT – ” buttons to select the weight of the food. -
Page 20: Auto Menu
MENU” button until the required auto cook menu, and "A ","A ","A ".."A " is displayed. PLEASE SEE THE AUTO COOK MENU TABLE ON THE NEXT PAGE TO FIND YOUR REQUIRED FUNCTION. Turn the “10 SEC/WEIGHT +” and the “... -
Page 21: Using The Microwave Oven
USING THE MICROWAVE OVEN Auto Cook Menu Cooking Guide Menu Rice Vegetable Meat Noodles Fish Reheat Weight (kg) -
Page 22: Child Lock, Checking Functions & General Information
USING THE MICROWAVE OVEN CHILD LOCK LOCK ON: In standby state, press "10 SEC/WEIGHT+” and the “1 MIN/WEIGHT- ” button for 3 seconds, there will be a "beep" as the lock activates. In locked state: press "10 SEC/WEIGHT+ ” and the “1 MIN/WEIGHT- ”... -
Page 23: Connection To The Mains Supply
CONNECTION TO THE MAINS SUPPLY WARNING- THIS APPLIANCE MUST BE EARTHED This appliance is designed to operate from a mains supply of 230-240V~ 50Hz. Check that the voltage marked on the product corresponds with your supply voltage. This product is fitted with a 13A plug complying with BS1363. Important: The wires in the mains lead are coloured in accordance with the following code: GREEN/YELLOW... - Page 24 CONNECTION TO THE MAINS SUPPLY For UK use only – PLUG As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: GREEN/YELLOW wire is the EARTH and must be connected to the terminal which is marked with the letter E or by the...
-
Page 25: Problem Solving
PROBLEM SOLVING WARNING: To reduce the risk of personal injury, always unplug the microwave before performing maintenance or trouble shooting checks. The microwave oven may cause interference to your radio, TV or similar equipment. If this happens, you can get rid of the interference by moving the radio, TV or equipment as far away from your microwave oven as possible. - Page 26 PROBLEM SOLVING Problem Potential Reason Potential solution Spillages or splashes can burn and catch fire, all food that is put into the microwave should be appropriately covered. All spillages or splashes must be cleaned, and all areas of microwave cleaned after each use. Burnt on food debris in the microwave, on the waveguide and the behind the waveguide can cause the microwave to 'spark'.
- Page 27 PROBLEM SOLVING Problem Potential Reason Potential solution By the very nature of how a microwave works, it ‘excites’ the water molecules in the food it is heating, causing them to move about and generate heat from within the food. Often when the food heats up it reaches the point where steam is released.
-
Page 28: Problem Solving
PROBLEM SOLVING Problem Potential Reason Potential solution Cooling vents allow the heat and steam to escape from the microwave. These cannot be covered as it can cause excessive water to settle inside the microwave or the microwave to overheat. Over heating Cooling vents covered The instructions in the instruction manual must be followed or the warranty will be void. -
Page 29: Guarantee And Customer Services
GUARANTEE & CUSTOMER SERVICES At Next, we take all our customer feedback seriously. Feel free to contact our Product Care Team on 0345 209 7461 Monday – Friday: 8am-6pm & Saturday: 9am – 1pm who will be more than happy to help you. -
Page 30: Spare Parts
SPARE PARTS The following spare parts are available from www.productcareuk.com or call 0345 209 7461 Turntable coupling Turntable Ring Glass turntable Wave Guide cover... -
Page 31: Notes
NOTES... - Page 32 For Product Care & Spare Parts please call 0345 209 7461 Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm or visit us at www.productcareuk.com www.next.co.uk www.nextflowers.co.uk www.nextwedding.co.uk www.nextwine.co.uk www.nextelectric.co.uk www.next-art.co.uk This symbol is known as the 'Crossed-out wheelie bin Symbol'. When this symbol is marked on a product/batteries, it means that the product/batteries should not be disposed of with your general household waste.
