Stop! Missing a part? DO NOT RETURN PRODUCT TO STORE
1. Read this Manual before attempting to assemble or operate your heater.
2. Follow safety instructions.
3. Check for leaks according to the directions in this Manual before operating your heater,
even if purchasing an assembled heater.
4. Keep this Manual for future reference.
5. Contact 1-800-229-5647 should you need assembly assistance or have any questions.
The store where you made the purchase does not stock
parts for this item. If you need parts, whether they are
missing or damaged, please call Customer Service at
Call us between 8:00 AM and 5:00 PM Eastern time, Monday through Friday
USE AND CARE MANUAL
For Model FM35PHLP
Patio Heater
YOUR SAFETY:
or email us at saleshelp@sureheat.com
1-800-229-5647
FOR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FM35PHLP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Four Seasons FM35PHLP

  • Page 1 USE AND CARE MANUAL For Model FM35PHLP Patio Heater Stop! Missing a part? DO NOT RETURN PRODUCT TO STORE YOUR SAFETY: 1. Read this Manual before attempting to assemble or operate your heater. 2. Follow safety instructions. 3. Check for leaks according to the directions in this Manual before operating your heater, even if purchasing an assembled heater.

  • Page 2: Table Of Contents

    Table of Contents General Safety Instructions................Components & Hardware................. Assembly Process.................... Gas Requirement..................... Pre-Operation Leak Testing................Operation......................11-12 Care & Maintenance..................Troubleshooting....................Warranty......................

  • Page 3: General Safety Instructions

    General Safety Instructions IMPORTANT SAFETY INFORMATION This manual contains important information about the assembly, operation and maintenance of this patio heater. General safety information is presented in these first few pages and is also located throughout the manual. - Keep this manual for future reference and to educate new users of this product. This manual should be read in conjunction with the labeling on the product.
  • Page 4 General Safety Instructions ▲ DANGER ▲ WARNING Improper installation, adjustment, alteration, DO NOT use the heater in garages, breezeways, service or maintenance can cause injury or sheds or any enclosed area. Never operate the property damage. Read the installation, operating heater in enclosed areas as this could lead to a and maintenance instructions thoroughly before carbon monoxide buildup, which could result in...

  • Page 5: General Safety Instructions

    General Safety Instructions DANGER ▲ ▲ WARNING CARBON MONOXIDE HAZARD - This product is fueled by propane gas. Propane - This heater is a combustion appliance. All gas is invisible, odorless, and flammable. An combustion appliances produce carbon monoxide odorant is normally added to help detect leaks (CO) during the combustion process.

  • Page 6: Components & Hardware

    Components & Hardware 1. Cap nuts (3 pcs) 2. Reflector 3. Washer 4. Emitter 5. Wire guard 6. Access panel 7. Base 8. Cast iron ring weight 9. M6x20 bolts (4 pcs) 10. 3/16 Stainless bolts (4 pcs) and washers (4 pcs) 11.

  • Page 7: Assembly Process

    Assembly Process S t e p 1 - A t t a c h p o s t o n t o h o u s i n g , Step 2- Attach weight to base, using four using four bolts and washers. Keep the bolts.

  • Page 8: Assembly Process

    Assembly Process Step 5 - Place washers onto emitter bolts, Step 6 - Rotate regulator toward opening in then attach reflector to emitter assembly, housing. Line up threads on gas cylinder using three cap nuts. with those on the regulator. Insert and rotate cylinder clockwise until tight.

  • Page 9: Gas Requirement

    Gas Requirements L.P. GAS INSTALLATION Gas Heaters that are set to operate with L.P. gas come with a high capacity hose and regulator assembly. (Note: Only use the pressure regulator and hose assembly supplied with the heater or a replacement pressure regulator and hose assemblies ).

  • Page 10: Pre-Operation Leak Testing

    Pre-Operation Leak Testing GENERAL INFORMATION Although all gas connections on the heater are leak tested prior to shipment, a complete gas tightness check must be performed at the installation site due to possible shifting during shipment, installation or excessive pressure unknowingly being applied to the unit. Periodically check the whole system for leaks and immediately check the system if the smell of gas is detected.

  • Page 11: Operation

    Operation Do not attempt to "Light" the Heater if the odor of gas present!! BEFORE TURNING GAS SUPPLY ON: 1. Your heater was designed and approved for outdoor use only. Do NOT use it inside a building, garage, or any other enclosed area. 2.
  • Page 12 Operation Note: If pilot fails to remain lit, all valves should be closed and wait at least 5 minutes before attempting to light. If you experience any ignition problem please consult the "Troubleshooting" section in this manual. Caution: Avoid inhaling fumes emitted from the heater during initial use. Smoke and odor from the burning of oils used in manufacturing can cause some smoke and odor.

  • Page 13: Care & Maintenance

    Care and Maintenance To enjoy years of outstanding performance from your heater, make sure you perform the following maintenance activities on a regular basis: Keep exterior surface clean. Use warm soapy water for cleaning. Never use flammable or corrosive cleaning agents. While cleaning your unit, be sure to keep the area around the burner and pilot assembly dry at all times.

  • Page 14: Troubleshooting

    Troubleshooting BEFORE CALLING CUSTOMER SERVICE If the heater does not function properly, use the following checklist. If the problem is: And this condition exists: Then do this: Cylinder valve is closed Open valve Blockage in orifice or pilot tube Clean or replace orifice or pilot tube Pilot won't light Air in gas line Open gas line and bleed it (pressing...

  • Page 15: Warranty

    LIMITED WARRANTY Sure Heat Mfg warrants that the components of this appliance are warranted free from defects in material and workmanship for one year from the date of purchase. Sure Heat Mfg. at its option, will repair or replace this product or any component of the product found to be defective during the warranty period.
