Summary of Contents for Symmetry EN-7510
- Page 1 Symmetry EN-7510 Installation Guide...
- Page 2 INFORMATION TO USER CAUTION RISK OF ELECTRIC SHOCK, DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol is intended to alert the user to the presence of un-insulated “dangerous voltage”...
-
Page 3: Table Of Contents
Symmetry EN-7500 Series EN-7510 Installation Guide Table of Contents 1. FEATURES ......................4 2. PACKAGE CONTENTS ..................5 3. PART NAMES ....................6 3.1. Rear View ......................... 6 3.2. Bottom View ........................6 4. INSTALLATION ....................9 4.1. Installing a C/CS Mounting lens ................... 9 4.2. -
Page 4: Features
Symmetry EN-7500 Series EN-7510 Installation Guide 1. FEATURES Camera Box type IP Camera Sony 1/3” Super HAD CCD & High Quality SS-HQ1 Full Kit Chip Set True Day / Night (ICR) and WDR (Optional) Streaming Dual streaming mode (with different codec/resolution/bit rate etc.) ... -
Page 5: Package Contents
Symmetry EN-7500 Series EN-7510 Installation Guide 2. PACKAGE CONTENTS Unpack carefully and handle the equipment with care. The packaging contains: Camera DC power adaptor Mount ring 9 Pin terminal block Rubber cap (for protecting CCD) Hex wrench driver Adaptor for mounting the camera... -
Page 6: Part Names
Symmetry EN-7500 Series EN-7510 Installation Guide 3. PART NAMES 3.1. Rear View ○ 1 ○ 2 ○ 3 ① LOOP OUT RESET RS-485 DO AUDIO ○ 5 ○ 4 ① Out In ○ 6 Micro SD ETHERNET ○ 7 ○ 8 3.2. - Page 7 Symmetry EN-7500 Series EN-7510 Installation Guide 1. Analog video out Analog video output port (PAL or NTSC as appropriate). 2. Reset Reset switch is used for restarting or resetting the camera to Factory Default (FD). Refer to the section “6.3. Reset” for more specific information.
- Page 8 Symmetry EN-7500 Series EN-7510 Installation Guide 9. Adaptor for mounting the camera Mounting points adaptor is provided on the bottom (or the top) of the camera for mounting the camera on a bracket or tripod. 9600-0541 Issue 1.1 Page 8 of 23...
-
Page 9: Installation
Symmetry EN-7500 Series EN-7510 Installation Guide 4. INSTALLATION Set Screw SET SCREW (For IRIS LENS) 4.1. Installing a C/CS Mounting lens 1. Remove the protective rubber cap from the front of the camera. 2. Install the mount ring for lens and adjust the mount ring to fit C or CS lens. -
Page 10: Setting The Image Attribute
Attribute Setting. Brightness, contrast, hue, saturation and sharpness can be adjusted. 4.4. Operating the OSD Menu To operate the OSD of camera, refer to the „EN-7510 OSD Menu Control Manual‟ on the CD supplied with your camera. 9600-0541 Issue 1.1... -
Page 11: Connections
Symmetry EN-7500 Series EN-7510 Installation Guide 5. CONNECTIONS Analog Video Out LOOP OUT DC Jack Adaptor Cable RESET RS-485 DO AUDIO Out In Power Adaptor Micro SD LAN Cable ETHERNET 4 pin connector for iris When connecting the DC power supply, make sure the polarity is correct. -
Page 12: Connectors
Symmetry EN-7500 Series EN-7510 Installation Guide 5.1.Connectors 9 pin terminal block LOOP OUT RESET RS-485 AUDIO C 1 C 1 Out In Micro SD ETHERNET RS-485 The RS-485 serial port consists of TRX+(RX+) and TRX-(RX-) as shown below: <RS-485 Application>... - Page 13 Symmetry EN-7500 Series EN-7510 Installation Guide Internal Internal Output of Output of Sensor Sensor DI 1 Relay Type Voltage Type Alarm (DO) connection This is a relay output, with a maximum rating of 24VAC 500mA or 12VDC 1A Do not exceed the maximum relay rating.
- Page 14 Symmetry EN-7500 Series EN-7510 Installation Guide Power Adaptor Connector (DC 12V) Power adaptor connector connects to DC Jack adapter cable. Make sure the polarity is correct. Incorrect connection may cause malfunction or damage to the IP device Caution Power Adaptor Connector (DC 12V) Caution 9600-0541 Issue 1.1...
-
Page 15: Configuration
Symmetry EN-7500 Series EN-7510 Installation Guide 6. CONFIGURATION 6.1.Set up network environment The default IP address of your IP device is 192.168.XXX.XXX. You can find the available IP address from the MAC address of your device. Please make sure the device and your PC are on the same network segment before running the installation. - Page 16 Symmetry EN-7500 Series EN-7510 Installation Guide To use the IPAdminTool and view the live video on a web page: 1. Start IPAdminTool. Names and info of currently activated devices appear as a list. 2. Right-click on the desired device and select Web view.
- Page 17 Symmetry EN-7500 Series EN-7510 Installation Guide 5. Wait for a few seconds while the web page loads. Then the live video is displayed on the main page of the web browser. 6. If the live video is not displayed and “Can not Create XMLDOMDocument Install MSXML4.0”...
-
Page 18: View Video Using Ip Address
Symmetry EN-7500 Series EN-7510 Installation Guide 6.2.2. View video using IP address View the live video on a web page using your IP device and its IP address. To have the correct IP address ready and use it on a web page: 1. -
Page 19: Appendix A: Specifications
Symmetry EN-7500 Series EN-7510 Installation Guide APPENDIX A: SPECIFICATIONS Summary Camera Module Image Sony 1/3” Super HAD CCD, 410K Pixel Sensor Effective NTSC: 768(H) x 494(V) Pixels PAL: 752(H) x 582(V) Size 1/3 inch interline transfer CCD Scanning 2:1 Interlace system NTSC: 15.734 KHz (H) 59.94 Hz(V) -
Page 20: Electrical Characteristics
Symmetry EN-7500 Series EN-7510 Installation Guide Input / Output 1/1 channel Compression Format G.711 Function Digital Input / Output 1/1 channel RS-485 Supported Network 10/100 Base-T TCP/IP, UDP/IP, HTTP, RTSP, RTCP, RTP/UDP, RTP/TCP, Protocol SNTP, mDNS, UPnP, SMTP, SOCK, IGMP, DHCP, FTP, DDNS, SSL v2/v3, IEEE 802.1X, SSH... -
Page 21: Analytics
Symmetry EN-7500 Series EN-7510 Installation Guide Analytics Intelligent Detection (Included as Standard) High Performance Advanced Tracking Algorithm, Low False Alarm Rate Easy to Use Intuitive Web Browser Interface Detection Zones Multi-segment Polygons and Lines On-screen Display Real-time Display of Tracking Data and Events Stream or Analog video out (※Analog video out support can vary depending on the... -
Page 22: Appendix B: Power Over Ethernet
Symmetry EN-7500 Series EN-7510 Installation Guide APPENDIX POWER OVER ETHERNET The Power over Ethernet (PoE) is designed to extract power from a conventional twisted pair Category 5 Ethernet cable, conforming to the IEEE 802.3af Power-over- Ethernet (PoE) standard. IEEE 802.3af allows for two power options for Category 5 cables. -
Page 23: Appendix C: Dimensions
Symmetry EN-7500 Series EN-7510 Installation Guide APPENDIX C: DIMENSIONS Front view Top view LOOP OUT RESET RS-485 AUDIO C 1 C 1 Out In Micro SD ETHERNET Rear view H.264 Network Camera Right side view UNIT: mm 9600-0541 Issue 1.1...
