Summary of Contents for solarwholesaler RV
- Page 1 SolarWholeSaler.ca S o l a r W h o l e S a l e r . c a - RV Solar Installation Guide - Motor Homes - Trailers - Boats...
-
Page 2: Table Of Contents
Index Tools and Hardware Needed......1 Parallel Solar Panel Connections......2 Serial Solar Panel Connections......3 Inverter Connection Diagram......4 Mounting Kit Installation........5 Battery Connection Diagrams....6... -
Page 3: Tools And Hardware Needed
Tools & Hardware Needed Tools Wire Cutters 9/64 Drill Bit 3/8 Nut Driver Power Drill Caulking Gun Mounting HardWare Z-Bracket Stainless Steel 10 x 1 Inch Quad Caulking Nuts & Bolts Wood/Sheet Metal Screw (Advanced Formula Sealant & Glue) Page 1... -
Page 4: Parallel Solar Panel Connections
Planning & Starting The Installation Layout & Configuration 1. Figure out how many panels you will need, and the amount of panels you can actually fit on the space you will be installing them. 2. Measure how much wire you will need, by measuring where and how the wire will run to the charge controller than to the batteries. 3. -
Page 5: Serial Solar Panel Connections
Planning & Starting The Installation MPPT Charge Controller Serial & Parallel Connections This diagram shows two 37 Volt Solar Panels connected in series which increases the voltage to 74 Volts. The MPPT charge controller will match the battery voltage and convert the rest into Amperage allowing it to use up to 97 % of the solar panel power. -
Page 6: Inverter Connection Diagram
Inverter Connection Diagram Inverter Installation Diagram - Batteries fasten to inverter terminals using 3/8 connectors normally. (Terminal size is based on inverter & Battery Type) - Cable thickness is determined by Length Volts and Amperage. Good Practice to use 00AWG Wire no longer than 4 feet. 12 Volt Controller - Any wires/cables coming from battery power source need to have a protective fuse with the positive line. -
Page 7: Mounting Kit Installation
Mounting Kit Installation Solar Panel Mounting (12" Mounting kit installation example) Layout & Configuration - Install mounting on solar panel frame (12" mounting kit comes with Z-Bracket, nuts and bolts to fasten directly onto solar panel) - Find a spot that you can run down your cable easily (ventilation or drill a hole through the roof top) - Place solar panel as close to your wire drop down spot as you can. -
Page 8: Battery Connection Diagrams
Serial & Parallel Battery Connection Diagrams 6 Volt Batteries in Series 6 Volt Batteries in Series (Series Increases Voltage) (Series Increase Voltage) 6 Volt Batteries in Series & Parallel 6 Volt Batteries in Series and Parallel (Increase Voltage & Amp Hours) (Increase Voltage &... - Page 10 Installation Guide Solar Panels Solar Homes RV & Boat Kits Manual Designed By: Jon Rotter...
