Summary of Contents for Elcometer 213/2
- Page 1 Elcometer 213/2 Digital Thermometer Operating Instructions...
- Page 2 (electronic, mechanical, magnetic, optical, manual or otherwise) without the prior written permission of Elcometer Limited. A copy of this Instruction Manual is available for download on our Website via www.elcometer.com. Doc No. TMA-0430 Issue 02...
-
Page 3: Table Of Contents
CONTENTS Section Page About your gauge ..............2 Fitting a battery . -
Page 4: About Your Gauge
Our products cover all aspects of coating inspection, from development, through application to post application inspection. Your Elcometer 213/2 Digital Thermometer is a world beating product. With the purchase of this product you now have access to the worldwide service and support network of Elcometer. For more information visit our website at www.elcometer.com... -
Page 5: Fitting A Battery
Note: A probe is not supplied with the thermometer. Probes must be ordered separately - see “Spare parts and accessories” on page 8. The Elcometer 213/2 Digital Thermometer is packed in a cardboard and foam package. Please ensure that this packaging is disposed of in an... -
Page 6: Fitting A Probe
Do not dispose of any batteries in fire. 3 FITTING A PROBE Your Elcometer 213/2 Digital Thermometer should only be used with a 'K Type' thermocouple probe made to BS EN 60584:1996 which is fitted with a suitable miniature thermocouple plug. A range of suitable probes is available from your Elcometer supplier or direct from Elcometer - see “Spare parts and accessories”... -
Page 7: Taking A Reading
4 TAKING A READING 1. To switch on the gauge, press 2. Apply the tip of the probe to the substance, medium or surface to be measured. The reading on the display may take a number of seconds to stabilise depending on the nature of the measurement and the sensitivity of the probe. -
Page 8: Changing Measurement Units
5 CHANGING MEASUREMENT UNITS To change the instrument units from °C to °F or vice versa: 1. Switch off the gauge. 2. Press but do not release the button. 3. While continuing to press , press to switch on the gauge. 4. -
Page 9: Maintenance/Storage
Elcometer supplier. Your gauge does not contain any user-serviceable components .In the unlikely event of a fault, the gauge should be returned to your Elcometer supplier or directly to Elcometer. The warranty will be invalidated if the instrument has been opened Contact details can be found on the outside cover of these operating instructions and at www.elcometer.com... -
Page 10: Spare Parts And Accessories
8 SPARE PARTS AND ACCESSORIES The following spare parts and accessories are available direct from Elcometer or your local supplier: Beschrijving Reeks Artikelnummer Magnetic Surface Probe, 13mm -50°C to 150°C (-58°F to 302°F) T99911728 (0.51”) Diameter Surface Probe, 130 x 4.2mm -50°C to 600°C (-58°F to 1112°F) -
Page 11: Technical Specifications
9 TECHNICAL SPECIFICATIONS Measurement Range: -49°C to +1372°C (-56°F to +2500°F) Resolution: 0.1°C (0.1°F) up to +299.9°C (+ 599.9°F) 1°C (1°F) above +299.9°C (+ 599.9°F) Accuracy: ±1% of the reading ±1 digit Probe: ‘K type’ Thermocouple Ambient Temperature: 0°C to +50°C (0°F to +122°F) Case Dimensions: 35 mm x 60 mm x 115 mm (1.4"... -
Page 12: Related Equipment
10 RELATED EQUIPMENT In addition to the Elcometer 213/2 Digital Thermometer, Elcometer produces a wide range of environmental measuring equipment and other equipment for measuring the characteristics of surface coatings. Users of the Elcometer 213/2 Digital Thermometer may also benefit from the following Elcometer products: •...
