Digipeater CLB26 User Manual Introduction The Digipeater CLB26 is designed to overcome problems with image processing systems ® in which distance is a limitation. A standard CameraLink cable can be used to connect a camera to a frame grabber over distances of up to 10 m. It frequently occurs, however, that twice this length is required to feed signal cables through the trunking of automation systems.
Digipeater CLB26 User Manual Connections / Block diagram Fig. 2 shows a block diagram of the Digipeater. Data from the camera are connected to Port 1. The regenerated data are transmitted on to the frame grabber from Port 2. The direction of the data flow is marked with arrows on the Digipeater case (see Fig.
Page 6
Digipeater CLB26 User Manual When installing cables in the vision system the cables have to be handled with extreme care to avoid destruction of the inner cable structure. Please do not apply extra force to the cables and mind the minimum bending radius. Otherwise the characteristic impedance of the cable will not be longer 100 Ohm and transmission errors or an interruption of the data transmission will occur.
Digipeater CLB26 User Manual Performance of the complete system The performance of the vision system is determined by the performance of the vision components at given bandwidth of the data transmission. The bandwidth of the ® CameraLink interface is given by the bit depth of the camera, the number of taps and the transmission frequency (PixelClock frequency).
Page 8
Digipeater CLB26 User Manual ® In vision systems most often AWG28 CameraLink cables are in use. Table 1 shows the distances for different configurations and transmission frequencies for an AWG28 ® CameraLink standard cable. High performance cables, high flexible cables, cables for drag chains and robots are available from Photonfocus.
Page 9
Digipeater CLB26 User Manual ® CameraLink Interface and Power Supply The Digipeater has two sockets with signals for data transmission and the control of camera functions as well as one socket for external power supply. The pin assignments ® for the data and control signals are defined in the CameraLink Standard [CLS2004].
Page 10
Digipeater CLB26 User Manual ® Table 3: Pin assignments for the MDR26 socket of the CameraLink PORT 2 (Frame grabber) PIN I/O Name Description SHIELD Shield ® N_XD0 Negative LVDS Output, CameraLink Data D0 N_XD1 Negative LVDS Output, CameraLink ®...
Page 11
For wall or ceiling mounting, two additional attachment variants are offered. Fig. 6 shows the different attachment variants. Fig. 6: Attachment variants (left: fix; right: adjustable) Technical Data for the Digipeater CLB26 Table 5: Technical Specifications Technical Data Digipeater CLB26...
Page 12
1 gives an overview about the attainable distances in this application. Fig. 8 shows an example with two Digipeaters in series. CameraLink Frame Grabber Digipeater CLB26 Camera Fig. 7: Standard application for a Digipeater CLB26 Camera Digipeater CLB26 CameraLink Frame Grabber Digipeater CLB26 Fig.
Page 13
Frame Grabber Digipeater CLB26 Camera Digipeater CLB26 Fig. 9: Two Digipeater CLB26 in two camera vision system ® Two Digipeaters can be used in parallel for CameraLink Medium data transmission (see Fig. 10). In this application it is important to use the same cable length and cable sort in ®...
Page 14
Digipeater 1/2 Fig. 11: Data transmission in a long mounting line The Digipeater CLB26 can also be used for signal regeneration at cable feedthroughs or connections between cable sorts. This is often the case in robot applications where high flexible cables are in use on the robot itself and rigid cable are used to bridge the distance between the place of the robot and the system control unit.
Digipeater CLB26 User Manual System Control Unit Machine Vision System PC Camera 2 CameraLink Digipeater CLB26 Frame Grabber Fig. 12: Data transmission in a robot application Fig. 12 shows a robot application with two cameras. One camera is mounted on the robot and connected via Digipeater with the frame grabber in the system PC.
Standard application for a Digipeater CLB26 ..........12 Fig. 8: Multiple applications for a Digipeater CLB26 ..........12 Fig. 9: Two Digipeater CLB26 in two camera vision system........13 ® Fig. 10: Two Digipeater CLB26 in CameraLink Medium data transmission....13 Fig.
Page 18
Digipeater CLB26 User Manual 14 Revisions and State of Product development 14.1 Revisions Table 7: Document revisions Changes Date First edition 02/12/02 Complete revision of the document 12/08/03 CE Compliance Statement integrated 28/07/04 document review and application information 28/01/08 REV: 1.3...
Digipeater CLB26 User Manual 15 Service information 15.1 Contact for product enquiries and quotations For product enquiries and quotations, please contact one of our distributors in your area. A list of distributors can be found at: www.photonfocus.com 15.2 Product information, documentation and software updates www.photonfocus.com...
Digipeater CLB26 User Manual 16 Guarantee conditions Guarantee claims The manufacturer alone reserves the right to recognize guarantee claims. The guarantee will be rendered null and void in the event of unauthorized manipulation, mechanical damage or damage arising from inappropriate use or from mechanical or electrical modifications, especially soldering.
