Advanced Technology: with exclusive patented technology, high-
•
temperature and high-pressure steam is used for clearing away dirt and
stains on floor boards, windows, doors and clothes. The unit will also kill
bacteria on surfaces, while being completely environmentally friendly.
Improved Safety: To ensure that the unit avoids empty heating, once the
•
water in the boiler tank is heated and evaporated, the unit will
automatically shut-down the power supply.
With a highly sensitive thermostat, 135C high-temperature steam is
available, ensuring complete disinfection and sterilization. The safety valve
has an automatic pressure release function ensuring that excessive
pressure will not build up inside the unit.
Durable Construction: The machine is manufactured with an aluminium
•
alloy die casting boiler body with an extra-thick inner wall designed to
resist high pressures.
1.
Body
2.
Short spray nozzle
3.
Safety cap
4.
Steam button
5.
Handle
6.
Power cord and plug
7.
Power indicator
8.
Funnel
9.
Measuring cup
10. Spray cup with round brush
11. Bent spray nozzle
12. Long spray nozzle
13. Extended connecting spray nozzle
14. General spray nozzle
15. Door/window spray nozzle
16. Towel sleeve
1
Advertisement
Table of Contents
Related Manuals for Certa CTSTMCLN900A
Summary of Contents for Certa CTSTMCLN900A
- Page 1 Advanced Technology: with exclusive patented technology, high- • temperature and high-pressure steam is used for clearing away dirt and stains on floor boards, windows, doors and clothes. The unit will also kill bacteria on surfaces, while being completely environmentally friendly. Improved Safety: To ensure that the unit avoids empty heating, once the •...
- Page 2 Do not allow children to use this machine. Keep the unit out of reach of • children when not in use. This device is not intended for use by persons (including children) with • reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person who is responsible for their safety.
- Page 3 Power supply rating: AC 220-240V~ 50Hz Tank capacity: 300ml Max capacity of water cup: 175ml Rated power: 900W ~ 1050W Steam pressure: 2.5 ~ 4.2bar Injected steam capacity: 28g/min Overall dimensions: 250 x 140 x 230mm Net weight: 1.85kg 1. Unpack the product, check accessories and make sure all parts are present and undamaged.
- Page 4 Hold the pipe section of the long spray cup in your hand, aligning the arrow on the spray cup with the single-line mark on the short spray nozzle on the machine body, then insert the spray cup into position. Rotate the spray cup in a clockwise direction, aligning the arrow on the spray cup with the double-line mark on the short spray nozzle on the machine body, as shown in Figure 1.
- Page 5 As shown in Figure 4 and Figure 5, install the two small hooks of the spray cup for doors/windows, then connect the trigger for the big hook. Then push the spray cup for doors/windows up and attach it onto the body of the general spray nozzle.
