KOBALT
and the K Design
®
trademarks of LF, LLC. All Rights Reserved.
ATTACH YOUR RECEIPT HERE
Serial Number
Questions, problems, missing parts? Before returning
to your retailer, call our customer service department at
1-888-3KOBALT (1-888-356-2258), 8 a.m. - 8 p.m., EST,
Monday - Friday.
AB12437
are registered
®
Purchase Date
kobalttools.com
ITEM #0437530
20-VOLT COMPACT
LITHIUM-ION BATTERY
MODEL #K20-LB20A
Français p. 13
Español p. 27
Advertisement
Related Manuals for Kobalt K20-LB20A
Summary of Contents for Kobalt K20-LB20A
- Page 1 ITEM #0437530 20-VOLT COMPACT LITHIUM-ION BATTERY MODEL #K20-LB20A KOBALT and the K Design are registered ® ® trademarks of LF, LLC. All Rights Reserved. Français p. 13 Español p. 27 ATTACH YOUR RECEIPT HERE Serial Number Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-888-3KOBALT (1-888-356-2258), 8 a.m.
-
Page 2: Table Of Contents
Warranty ..........12 SPECIFICATIONS Component Specifications Model K20-LB20A Battery type Lithium Battery voltage 20V D/C... -
Page 3: Safety Information
SAFETY INFORMATION Carefully read this manual and all labels affixed to the battery pack before using. Keep this manual available for future reference. IMPORTANT This battery pack should only be serviced by a qualified service technician. READ ALL INSTRUCTIONS THOROUGHLY General Safety Rules for All Power Tools WARNING: Read all safety warnings and all instructions. - Page 4 SAFETY INFORMATION Electrical Safety • Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded. • Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock. Battery Tool Use and Care • Recharge only with the charger specified by the manufacturer.
- Page 5 SAFETY INFORMATION Specific Safety Rules for Battery Pack • Use battery only with the charger listed. Battery pack Charger K20-LB20A K20-MC60A • Know your power tool. Read the operator’s manual carefully. Learn the tool’s applications and limitations, as well as the specific potential hazards related to this tool. Following this rule will reduce the risk of electric shock, fire, or serious injury. • Battery tools do not have to be plugged into an electrical outlet; they are always in operating condition. Be aware of possible hazards when not using your battery tool or when changing accessories.
- Page 6 SAFETY INFORMATION • Do not charge the battery in a damp or wet location. Following this rule will reduce the risk of electric shock. • For best results, your battery should be charged in a location where the temperature is greater that 41°F (5° C) and less that 104°F (40° C). Do not store outside or in vehicles. • Under extreme usage or temperature conditions, battery leakage may occur. If liquid comes in contact with your skin, wash immediately with soap and water, then neutralize with lemon juice or vinegar. If liquid gets in your eyes, flush...
-
Page 7: Preparation
PREPARATION Know Your Battery Pack Before attempting to use the battery pack, familiarize yourself with all of its operating features and safety requirements. Part Description Battery release button Electrical contacts Battery vents... -
Page 8: Operating Instructions
OPERATING INSTRUCTIONS Power Indicator This lithium-ion battery pack is equipped with a power indicator that displays the battery pack’s charge status. Press the power indicator button to display the LED lights. The LED lights will stay lit for approximately 4 seconds. NOTICE: The power indicator can be used whether the battery is attached or removed from tool. - Page 9 OPERATING INSTRUCTIONS Low Capacity Warning If one LED on the POWER BAR begins to flash, the battery pack is charged to less than 10% of its capacity and should be recharged. Unlike other types of battery packs, lithium-ion battery packs deliver fade-free power for their entire run time.
- Page 10 OPERATING INSTRUCTIONS Cold Weather Operation This lithium-ion battery pack will provide optimal performance in temperatures between 32°F (0°C) and 104°F (40°C). When the battery pack is very cold, it may “pulse” for the first minute of use to warm itself. Put the battery pack on a tool and use the tool in a light application.
- Page 11 A fully discharged battery pack model K20-LB40A will charge in about 45 minutes and model K20-LB20A will charge in about 35 minutes in a surrounding temperature between 32°F (0°C) and 104°F (40°C).
-
Page 12: Care And Maintenance
CARE AND MAINTENANCE All maintenance should be carried out only by an authorized service organization. Cleaning Before cleaning or performing any maintenance, remove the battery pack from the tool. For safe and proper operation, always keep the tool and its ventilation slots clean. Always use only a soft, dry cloth to clean your battery pack, never use any detergent or alcohol.
