Shanghai Jailing Vehicle Business La Vita 150CC Owners Book

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
L
V
150
O
B


A
ITA
CC
WNERS
OOK

Geason Power Sports., Ltd            V1.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the La Vita 150CC and is the answer not in the manual?

Questions and answers

Summary of Contents for Shanghai Jailing Vehicle Business La Vita 150CC

  • Page 1     A  ITA  CC  WNERS    Geason Power Sports., Ltd            V1.2...

  • Page 2: Owner's Manual

    Owner’s Manual Our scooter presents you with a challenge; a challenge to master a machine, a challenge to experience adventures, a challenge to be free. Unlike an automobile, there is no metal cage around you. There is only you and the road, linked together by a vehicle that responds to your every command like no other.

  • Page 3: Limited Warranty

    LIMITED WARRANTY Shanghai Jialing Vehicle Business Co., Ltd warrants that the products are free, under normal use and maintenance, from any defects in material and workmanship. If any such defects should be found in products within applicable warranty period, Jialing shall, at its option, repair or replace the parts as specified herein.
  • Page 4 is designed, built and equipped so as to conform at the time of initial retail purchase with all applicable regulations of the United States Environmental Protection Agency (“US EPA”); and is free from defects in material and workmanship which would cause such scooter to fail to conform with applicable regulations of the US EPA, for a period of five (5) years or 12,000km (7,456 miles) for models up to 169cc.
  • Page 5 Any motorcycle on which odometer mileage has been changed so that the actual mileage cannot be determined. LIMITED LIABILITY: The liability of Hammerhead under this Emission Control Systems Warranty is limited solely to the remedying of defects in materials or workmanship by any authorized Hammerhead motorcycle dealer at its place of business during customary business hours.

  • Page 6: Table Of Contents

    Contents  Owner’s Manual ............................2  IMPORTANT INFORMATION ..................... 7  SAFETY INFORMATION ......................8  Descriptions ............................ 9  Instrument Panel ........................... 10  Instrument Control ........................11  Handlebar Switches ........................12  Fuel Tank Cap ..........................13  Seat Lock ............................13  Brake System ..........................14  Side Stand Kill Switch ........................

  • Page 7: Important Information

    IMPORTANT INFORMATION 1. Operation and Passenger This scooter is designed to carry one operator and one passenger. Never exceeds the manufacturer’s recommended maximum weight capacity as shown on the loading label. 2. On-Road Use Only This scooter is designed to be used only on paved roads. 3.

  • Page 8: Safety Information

    SAFETY INFORMATION Important Safety Information Understanding the challenges that you will face when operating a scooter will greatly improve your safety on the roads. There are many things you can do to protect yourself when riding. You will find many helpful recommendations throughout this manual. Following are a few safety items we consider to be the most important.

  • Page 9: Descriptions

    Descriptions 1. Left and Right rear Mirror 2. Left and Right Brake 3. Front storage compartment (option) 4. Speedometer/ Digital Gauge 5. Main Switch 6. Battery 7. Air Cleaner 8. Seat Lock 9. Rear Light Assembly 10. Left and Right Rear turn Lights 11.

  • Page 10: Instrument Panel

    Instrument Panel Speedometer Riding speed is indicated by KM/H and MPH. Odometer The total riding distance is in KM and Miles. The black figures in black background indicate total miles traveled. Indicating lamp or turning light It flashes when turning light is in use. Fuel Gauge Fuel Gauge indicates the remaining fuel in the fuel tank (the gauge does not work when main switch is in the “OFF”...

  • Page 11: Instrument Control

    Instrument Control Main Switch NOTE: Do not leave the main switch in “ON” position for an extended period of time when the engine is stopped. The battery may drain itself empty. Lock the steering and remove the key after park to avoid theft. “ON”...

  • Page 12: Handlebar Switches

    Handlebar Switches 1. Dimmer Switch When light switch is in the “ON” position Push in to turn on the high beam. Push out to turn on the low beam 2. Turning Light Switch To use the turning light while making a turn or changing traffic lane, press the directional switch, press toward the left arrow to turn on the left turn signal, press toward the right arrow to turn on the right turn signal.

  • Page 13: Fuel Tank Cap

    Fuel Tank Cap Follow the steps below to OPEN and CLOSE the fuel tank cap. To Open Insert the key into the key slot; turn clockwise to open the access panel. Give fuel cap 1/4 of full turn, and then pull out the fuel cap. To Close Align the keyways of your fuel cap with the tank, press the fuel cap down and then turn counter clockwise 1/4 turn, remove the key to close the fuel cap.

  • Page 14: Brake System

    Brake System Rear Brake Lever The rear brake lever is located on the left handlebar. Pull the lever to apply the rear brake. Front Brake Lever The front brake lever is located on the right handlebar. Pull the lever to apply front brake.

  • Page 15: Side Stand Kill Switch

    Side Stand Kill Switch Remove the scooter from side stand before starting otherwise scooter will not turn on. If the side stand is on, the kill switch will automatically activate and scooter engine will be shut off.

  • Page 16: Pre-Operation Check

    Pre-Operation Check Pre-operation checks should be made each time before using the scooter. Such an inspection can be accomplished in a very short time. The added safety it insures is worth more than the time involved. Before using this scooter, check the following points: ITEM ROUTINE PAGE(S...
  • Page 17 Pre-Operation Checks – Brakes Brake Levers Check for correct free play in the brake levers and correct them if necessary. Make sure the brakes are working properly by checking at low speed shortly after starting out. The free play range, it should be within 10-20mm. NOTE: A soft, spongy feel in the brake lever indicates a failure in the brake system.
  • Page 18 Pre-Operation Check – Throttle Grip Turn the throttle grip and check for free play to see if it operates properly. Make sure the grip returns to the original position by the spring force when released. Ask your authorized dealer to make any necessary adjustments.
  • Page 19 Pre-Operation Check – Tires To ensure the maximum performance, longer durability and safe operation, always check and adjust the tire pressure before operating your scooter. 22 psi front, 29 psi rear, add 5 psi to rear with load. NOTE: Tire pressure should be checked and adjusted when tire temperature equals the ambient air temperature.
  • Page 20 Pre-Operation Check – Fittings and Fasteners Always check the tightness of chassis fittings and fasteners before every ride. Take your scooter to an authorized dealer to correct all fittings and fasteners to proper torque if needed. Pre-Operation Check – Head Lights, Signal Lights and Switches Check all the headlight, signal lights and switches to ensure they are working properly.

  • Page 21: Operation

    OPERATION Starting an Engine Park before starting with center stand. Return the side stand to its original position. Check if there is sufficient fuel and engine oil 1. Turn the main switch to OPEN position 2. Check to see that the engine kill switch is turned OFF 3.
  • Page 22 NOTE: For maximum engine life, never accelerate hard with a cold engine Always return the kick start to the original position after starting. The exhaust fumes are poisonous and can cause loss of consciousness and even death within a short time. You must operate your scooter in an area with adequate ventilation. Starting Off 1.

  • Page 23: Engine Break-In Period

    Engine Break-In Period There is never a more important period in the life of your scooter than period between zero and 1500 km (900 miles). For this reason we ask that you carefully read the following material. You should not place an excessive load on the engine for the first 1,500 km (900 miles). The various parts in a new engine wear and polish themselves to the correct operation clearances during this period.

  • Page 24: Periodic Maintenance And Minor Repair

    Periodic Maintenance and Minor Repair Period inspection, adjustments, and lubrication will keep your scooter in the safest and most efficient condition possible. You must take into consideration that weather, terrain, geographical locations, and variety of causes all tend to demand that each owner alter the time schedule for regular maintenance to shorter intervals.

  • Page 25: Periodic Maintenance Chart

    Periodic Maintenance Chart...

  • Page 26: Engine Oil

    Engine Oil 1. Oil Level Measurement a. Place the scooter on the center stand. Warm up the engine for several minutes. b. Stop the engine and wait a few minutes until the oil levels before removing the dipstick. c. The oil level should be between the minimum and maximum mark on the dipstick.

  • Page 27: Gear Oil Replacement

    Gear Oil Replacement Replace the gear oil after the initial 300 km(180 miles). Thereafter, replace oil again every 4 months or 3000 km (1800 miles), whichever occurs first. Best done when gear oil is warm. Do as Described Below for Replacement: 1) Put the scooter on the center stand.

  • Page 28: Spark Plug Inspection

    Spark Plug Inspection The spark plug is an important engine component. The condition of the spark plug can indicate the condition of the engine. Therefore, you should periodically inspect it for signs of deterioration. The ideal color of the white insulator around the center electrode is a medium to light tan color for a scooter that is being ridden under normal conditions.

  • Page 29: Brake Lever Free Play Adjustment

    Brake Lever Free Play Adjustment The front brake lever free play should be adjusted to 2-5mm at the brake lever end. The rear brake lever free play should be adjusted to 2-5mm at the brake lever end. Note: When it is impossible to make adjustments on your own, consult your local dealer for professional guidance.

  • Page 30: Brake Fluid Replacement

    Brake Fluid Replacement 1. Complete fluid replacement should only be completed by trained professionals. 2. Have a dealer replace the following components during periodic maintenance, when they are damaged or leaking. a. Replace all rubber seals every two years. b. Replace all hoses every four years. Brake Lever Lubrication Lubricate the pivoting parts of both brake levers.

  • Page 31: Front Fork Inspection

    Front Fork Inspection Securely support the scooter so there is no danger of it falling over. 1. Visual Check: For scratches or damage to the inner tube and excessive oil leakage from the front fork 2. Operation Check: a. Place the scooter on level ground b.

  • Page 32: Steering Inspection

    Steering Inspection Periodically inspect the condition of the steering. Worn out or loose steering bearings may be dangerous. Place a stand under the engine to raise the front wheel off of the ground. Hold the lower end of the front forks and try to move them forward and backward. If any free play can be felt, ask a dealer to inspect and adjust the steering.

  • Page 33: Battery

    Battery This scooter uses a sealed type battery. It is unnecessary to check and add liquid. NOTE: The battery will lose its charge if the scooter is not operated for an extended period of time. Remove the battery from the scooter and charge it fully when not in use. Store it in a place with adequate ventilation.

  • Page 34: Major Technical Parameters

    Major Technical Parameters Wheel Base 1950 x 750 x 1110 mm Engine Displacement 149.6 cc Compression 9.5 :1 Idling Speed 1600 +- 150 rpm Max Power 5.8 kw / 7000 rpm Max Torque 9.3 N M / 6000 rpm Min. Ground Clearance 1380mm Dry Weight 210 lbs.

  • Page 35: Maintenance Records

    Maintenance Records MAINTENANCE RECORDS Date Mileage Item Maintained Dealer 300 miles 1000 Oil/ All Nuts 2000 3000 4000 5000 Oil/ All Nuts 6000 7000 8000 9000 10,000 Oil / Belts/ Spark Plug/ Air Filter 11,000 12,000 13,000 14,000 15,000 Oil / Air Filter 16,000 17,000 18,000...
