Summary of Contents for Blue Aura x30
- Page 1 Q U I C K S TA R T G U I D E...
-
Page 2: Table Of Contents
INDEX Features What's in the box? Remote Control Rear Panel NFC Pairing Bluetooth Pairing Other Ways To Connect Transmitter And Receiver Option Important Safety Instructions FCC Compliance FCC RF Exposure Requirements (MPE) Specifications / Blue Aura Worldwide Guarantee... -
Page 3: Features
Features: ® + Powered stereo speaker system with Bluetooth + NFC Bluetooth pairing function + Use with any source with Line-in or optical input + aptX ® audio coding delivers CD-quality sound wirelessly over Bluetooth ® + Pair & Play... -
Page 4: What's In The Box
What's in the box? 2 x Bluetooth Speaker 1 x Remote Control 1 x Power Cords / Power supplies 1 x Blue Aura Quick Connect Cable 1 x Audio Cable- (Mini Jack – RCA) -
Page 5: Remote Control
Remote Control POWER ON/OFF MUTE BLUETOOTH PAIRING VOL+ INPUT SELECTION VOL-... -
Page 6: Rear Panel
Rear Panel USB FOR BLUE AURA WIRELESS RECEIVER OPTICAL ONLY INPUT BLUETOOTH PAIRING BUTTON WB29 (OPTIONAL) AUX IN WALL BRACKET (AUDIO INPUT) SUB OUT POWER BLUE AURA QUICK INPUT CONNECTION... -
Page 7: Nfc Pairing
NFC Pairing (where available) Step 3 Step 1 Red→Blue Step 2 Step 4 Blue Hint: Ensure NFC function is enabled in your Bluetooth device, refer to your device manual for further information. www.blueaura/information Near Field Communication A contactless way to pair Bluetooth enabled devices... -
Page 8: Bluetooth Pairing
Bluetooth Pairing Step 1 Step 3 Bluetooth BLUE AURA X30 Step 2 Step 4 Blue SETTINGS www.blueaura/information... -
Page 9: Other Ways To Connect
Other Ways To Connect Optical Out Optical In Line Out Line In Green... -
Page 10: Transmitter And Receiver Option
Wireless dongl e pair ONLY FOR WSr WIRELESS RECEIVER OPTICAL AUX IN INPUT DC OUT 5V 250ma SUB OUT SPEAKER DC IN OUT TO LEFT 24V / 2A FCC ID: OSY-X30 IC:10515A-X30 Benefits + increased range + use multiple source devices... -
Page 11: Important Safety Instructions
Important Safety Instructions The loudspeaker is covered with a soft faux leather material. Please take care when unpacking the loudspeaker to avoid scratching or indenting the material. Warning: The AC Input connector (see page 5) is used as a safety disconnect device. It must be easily accessible after installation. - Page 12 01. Read these instructions. 02. Keep these instructions. 03. Heed all warnings. 04. Follow all instructions. 05. Do not use apparatus near water. 06. Clean only with a dry cloth. 07. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 08.
- Page 13 C. If the apparatus has been exposed to rain or water, D. If the apparatus does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the apparatus to its normal operation.
-
Page 14: Fcc Compliance
FCC Compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. -
Page 15: Fcc Rf Exposure Requirements (Mpe)
FCC RF Exposure Requirements (MPE) To satisfy FCC RF exposure requirements, a separation distance of 20 cm or more should be maintained between the antenna of this device and persons during device operation. To ensure compliance, operations at closer than this distance is not recommended. Les antennes installées doivent être situées de facon à... - Page 16 Blue Aura Customer Support, 01480 477738 or email support@blueaura.co.uk. If your Blue Aura dealer is unable to answer any query regarding this or any other Blue Aura product please contact Blue Aura Customer Support at the above address and we will do our best to help you.
-
Page 17: Specifications
Stage 1 of annex II of Commission regulation (ErP) EC no. 1275/2008 The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by BLUE AURA is under license. © 2013 ®... - Page 18 w w w . b l u e a u r a . c o . u k x30manv.01...
