Page 1 RENLIG FWM7...
Page 3 ENGLISH...
Page 4: Table Of Contents
ENGLISH Contents Safety information Washing programmes Safety instructions Consumption values Product description Care and cleaning Control panel What to do if… First use Technical data Daily use Environment concerns Helpful hints and tips IKEA GUARANTEE Subject to change without notice. Safety information Before the installation and use of the appliance, carefully read the supplied instructions.
Page 5: Safety Instructions
ENGLISH • Obey the maximum load volume of 7 kg (refer to the “Pro- gramme chart” chapter). • If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. •...
Page 6 ENGLISH • Only for UK and Ireland. The appliance • Make sure that you remove all metal ob- has a 13 amp mains plug. If it is necessa- jects from the laundry. ry to change the fuse in the mains plug, •...
Page 7: Product Description
ENGLISH Product description Detergent dispenser drawer Control panel Door opening handle Rating Plate Adjustable feet Detergent dispenser drawer Compartment for powder or liquid de- tergent used for main wash. If using liquid detergent pour it just before starting the programme. Compartment for liquid additives (fabric softener, starch).
Page 8: Control Panel
ENGLISH Door safety button This appliance incorporates a special fea- ture to prevent children and pets becom- ing trapped inside the drum. To activate this de- To disable this de- vice, rotate the but- vice and restore the ton clockwise (with- possibility of closing out pressing it) in- the door, rotate the...
Page 9 ENGLISH Super Quick button Spin button Rinse Hold button Temperature button Table of Symbol = Cottons = Miniprogramme = Cottons + Prewash = Jeans = On/Off - Reset ECO = Cotton Economy = Synthetics = Temperature = Delicates = Cold wash = Handwash/Wool = Spin = Rinse...
Page 10 ENGLISH Display The display shows the following information: • A – Child safety lock. This device permits you to leave the appliance unatten- ded during it's functioning. • B – Duration of the selected programme. After selecting a programme, the duration is displayed in hours and minutes (for example ).
Page 11: First Use
ENGLISH Extra Rinse button This appliance is designed for saving energy. If it necessary to rinse the laundry using an extra quantity of water (extra rinse), select this option. Some additional rinses will be per- formed. This option is recommended for people who are al- lergic to detergents, and in areas where the water is very soft.
Page 12 ENGLISH close firmly the • Measure out the door. detergent. • Pour the powder Measure out detergent and fabric detergent into softener the main wash First check the flap position: compartment UP- Flap position if DOWN - Flap posi- using POWDER de- tion if using LIQUID tergent detergent during...
Page 13 ENGLISH Reduce the spin speed by pressing button Pour fabric softener or any additives in- By selecting a programme, the appliance to the compartment proposes automatically the maximum spin marked (do not speed provided for that programme. exceed the «MAX» Press button 9 repeatedly to change the mark in the draw- spin speed, if you want your laundry to be...
Page 14 ENGLISH 3. Press button 5: Changing a running programme is possible – the machine starts its hourly count- only by resetting it. Turn the programme se- down. lector dial to O and then to the new pro- – the programme will start after the se- gramme position.
Page 15: Helpful Hints And Tips
ENGLISH To empty out the water: Remove the laundry from the drum and 1. Turn the programme selector dial to carefully check that the drum is empty. If you do not intend to carry out another wash, close the water tap. Leave the door 2.
Page 16: Washing Programmes
ENGLISH Degrees of water hardness Characteristic German °dH French °T.H. Soft 0-15 Medium 8-14 16-25 Hard 15-21 26-37 Very hard > 21 > 37 A water softener must be added when water has a medium-high degree of hardness. Follow the manufacturer’s instructions. The quantity of detergent can then always be adjusted (reduced) to degree of hardness soft.
Page 17 ENGLISH DELICATES Delicate fabrics: for Main wash Spin 40° - 30° - example curtains. Rinses Rinse Hold 3.5 kg Cold Max. final Super Quick 1.5 kg spin at 700 Extra Rinse WOOL/HAND- Special programme Main wash Spin WASH for wool garments Rinses Rinse Hold 40°...
Page 18 ENGLISH Special programme Main wash Spin MIX 20° for cotton, synthetic Rinses Rinse Hold 20° and mixed fabrics Max. final Extra Rinse with light soil. spin at 900 3 kg Set this programme to decrease the en- ergy consumption. EASY IRON Synthetic fabrics: se- Main wash Spin...
Page 19: Consumption Values
ENGLISH The washing temperature of the washing phase may differ from the temperature declared for the selected pro- gramme. 3) If this option is not active the max. final spin for cotton items is 1600 rpm. 4) Make sure that the detergent is for low temperature in order to have good washing results. Consumption values The data of this table are approximate.
Page 20 ENGLISH To run a maintenance wash: • Use the previous • The drum should be empty of laundry. brush to clean the • Select the hottest cotton wash pro- recess, ensuring gramme. that upper and • Use a normal measure of detergent, must lower part of it is be a powder with biological properties.
Page 21 ENGLISH • before removing the filter, remove any fluff or small objects from around the filter; The filter is inserted correctly when the indicator on its top is visible and • remove the filter and clean it under the blocked. tap;...
Page 22: What To Do If
ENGLISH The dangers of freezing • Turn off the water If the appliance is installed in a place where tap. the temperature could drop below 0°C, • Unscrew the hose proceed as follows to remove any water re- from the tap. maining inside the appliance: •...
Page 23 ENGLISH Warning! Switch off the appliance before you do the checks. Problem Possible cause Solution The door has not been closed Close the door firmly. The plug is not properly inserted in Insert the plug into the power the power socket. socket.
Page 24 ENGLISH Problem Possible cause Solution The electronic unbalance detection Redistribute the load manually or device has cut in because the laun- load more laundry and select the dry is not evenly distributed in the spin programme. drum. The laundry is redistributed The appliance by reverse rotation of the drum.
Page 25: Technical Data
ENGLISH Problem Possible cause Solution Excessive laundry load. Reduce the laundry load in ac- cording to the "Washing Pro- grammes table". After the check, switch on the appliance The necessary data for the service centre is and press the button 5 to restart the pro- on the rating plate.
Page 26: Environment Concerns
ENGLISH Average annual water con- 9994 sumption (litres) 1) If the pressure in your area is lower or higher, please contact your After Sales Service. 2) The data is based on the washing programme for test institutes assuming 200 cycles per a year. Information on the electrical connection, voltage and overall power is given on the rat- ing plate, on the inner edge of the appliance door.
Page 27 ENGLISH What will IKEA do to correct the problem? • The use of the appliance in a non-domes- tic environment i.e. professional use. IKEA appointed service provider will exam- • Transportation damages. If a customer ine the product and decide, at its sole dis- transports the product to their home or cretion, if it is covered under this guarantee.
Page 28 ENGLISH 1. make a service request under this guar- Important! In order to provide You with a antee; quicker service, we recommend that You 2. ask for clarification on installation of the use the specific phone numbers listed at the IKEA appliance in the dedicated IKEA end of this manual.
Page 29 België Binnenlandse gesprekskosten 8 tot 20 Weekdagen 070 246016 f i r à България 00359 888 16 0 8 Такса за повикване от страната От 9 до 18 ч в работни дни Česká republika 246 019721 Cena za místní hovor 8 až...
