Page 2: Instructions For Care And Operation
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy... -
Page 3: Power Safety
Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals. -
Page 4: Battery Precautions
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire. -
Page 5: Specifications
Introduction Specifications Processor Options Video Card Options W860CU: W860CU: Intel® Core i7 Mobile Processor nVIDIA® GeForce GTX 260M 1GB GDDR3 Video RAM on board i7-820QM (1.73GHz) Microsoft DirectX® 10 Compatible 8MB L3 Cache & 1333MHz FSB nVIDIA® GeForce GTX 280M i7-720QM (1.6GHz) Latest Specification Information 1GB GDDR3 Video RAM on board... - Page 6 Introduction Core Logic Card Reader Interface Intel® PM55 Chipset Embedded 7-in-1 Card Reader (MS/ MS Pro/ SD/ Mini SD/ Three USB 2.0 Ports and One USB 3.0 Port MMC/ RS MMC/ MS Duo) One eSATA Port Note: MS Duo/ Mini SD/ RS MMC Cards require a PC Memory One IEEE1394 Port adapter...
- Page 7 Introduction Power Full Range AC/DC Adapter AC Input: 100 - 240V, 50 - 60Hz DC Output: 20V, 6A Or 18.5V, 6.5A Or 19V, 6.3A Removable Li-Polymer Battery Pack, 42.18WH Environmental Spec Temperature ° ° Operating: 5 C - 35 Non-Operating: -20°C - 60°C Relative Humidity Operating: 20% - 80% Non-Operating: 10% - 90%...
-
Page 8: External Locator - Top View With Lcd Panel Open
Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. Optional Built-In PC Camera 2. LCD 3. Power Button 4. Speakers 5. LED Hot Key Buttons 6. LED Status Indicators 7. Keyboard 8. Built-In Microphone 9. -
Page 9: External Locator - Front & Right Side Views
Introduction External Locator - Front & Right side Views Figure 2 Front Views 1. LED Power Indicators 2. Consumer Infrared Transceiver (for W860CU Optional TV Tuner) W870CU Figure 3 Right Side Views 1. Headphone-Out W860CU Jack 2. Microphone-In Jack 3. Line-In Jack 4. -
Page 10: External Locator - Left Side & Rear View
Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. RJ-11 Modem Jack W860CU 2. USB 2.0 Port 3. Mini-IEEE 1394 Port 4. 7-in-1 Card Reader 5. Optical Device W870CU Drive Bay (for DVD Device) 6. -
Page 11: External Locator - Bottom View
Introduction External Locator - Bottom View Figure 6 Bottom View 1. Battery 2. Component Bay Cover 3. Vent/Fan Intake/ Outlet 4. Speaker Overheating W860CU W870CU To prevent your com- puter from overheating make sure nothing blocks the vent/fan in- takes while the com- puter is in use. -
Page 12: Maintenance Tools
Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •... -
Page 13: Maintenance Precautions
Disassembly Maintenance Precautions The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged. -
Page 14: Removing The Hard Disk Drive
Disassembly Removing the Hard Disk Drive The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm Figure 2 (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in HDD Assembly Chapter 4 of the User’s Manual) when setting up a new hard disk. - Page 15 Disassembly 5. Lift the hard disk assembly out of the computer in the direction of arrow (Figure 3c Figure 3 6. Remove the screws and the cover bracket from the hard disk (Figure 3d HDD Assembly 7. Reverse the process to install a new hard disk (do not forget to replace all the screws and covers). Removal (cont’d.) c.
-
Page 16: Removing The Hard Disk(S) In The Secondary Hdd Bay
Disassembly Removing the Hard Disk(s) in the Secondary HDD Bay (W870CU on- Figure 4 Secondary HDD Assembly Removal 1. Turn off the computer, and turn it over and remove the battery. 2. Locate the component bay cover and remove screws (Figure 6a a. -
Page 17: Removing The Optical (Cd/Dvd) Device
Disassembly Removing the Optical (CD/DVD) Device Figure 5 Optical Device 1. Turn off the computer, and remove the battery (page 2 - Removal 2. Locate the component bay cover and remove screws (W860CU) or (W870CU) (Figure 5a). 3. Carefully remove the component bay cover (Figure 5b). -
Page 18: Removing The System Memory (Ram)
Disassembly Removing the System Memory (RAM) Figure 6 The computer has two memory sockets for 204 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting RAM Module Removal DDR3 1333MHz. The main memory can be expanded up to 4GB. The SO-DIMM modules supported are DDRIII 1GB, and 2GB Modules. - Page 19 Disassembly 5. Gently pull the two release latches on the sides of the memory socket in the direction indicated by the & Figure 7 arrows (Figure 7c). RAM Module Removal (cont’d.) c. Pull the release latches. d. Remove the module. 6.
-
Page 20: Removing The Wireless Lan Module
Disassembly Removing the Wireless LAN Module Figure 11 Wireless LAN 1. Turn off the computer, remove the battery (page 2 - 5) and the component bay cover (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard (Figure 11a). -
Page 21: Removing The Bluetooth Module
Disassembly Removing the Bluetooth Module Figure 12 Bluetooth Module 1. Turn off the computer, remove the battery (page 2 - 5), and component bay cover (page 2 - 10). Removal 2. Locate the Bluetooth module, and remove the screw (Figure 12a). -
Page 22: Removing The 3G Module
Disassembly Removing the 3G Module Figure 13 3G Module Removal 1. Turn off the computer, remove the battery (page 2 - 2. Locate the 3G module cover, and remove the screw Figure 13a a. Remove the screw. 3. Remove the 3G module cover and carefully disconnect the cable and remove the screw from the 3G... -
Page 23: Removing The Keyboard
Disassembly Removing the Keyboard Figure 14 1. Turn off the computer, and remove the battery (page 2 - 5), component bay cover (page 2 - 10), and processor Keyboard Removal (page 2 - 12). 2. W860CU(scroll to the next page for W870CU): Press at point to unsnap the LED cover module Figure a. - Page 24 Disassembly 8. W870CU: Remove the screw and press at point to unsnap the the hinge cover module Figure 15a Figure 15 9. Turn the computer over, open the Lid/LCD and lift the hinge cover module and disconnect the cables & Keyboard Removal Figure 15b (cont’d.)
