Summary of Contents for innoXplore IX-M20
-
Page 1: Table Of Contents
Index 1 BASIC INFORMATION ..........2 NTRODUCTION ............ 2 RODUCT EATURE ..........3 AFETY RECAUTIONS ........4 1.3.1 Safty warning and attentinon ....4 1.3.2 Cleaning and Maintanance ...... 5 BEFORE USING THE GAMEPAD ......6 VERVIEW ............6 2.1.1 Technical Parameters ....... - Page 2 TROUBLESHOOTING ........... 12 APPENDIX Ⅰ ............14 APPENDIX Ⅱ ............14...
-
Page 3: Basic Information
Embed the iPhone in the gamepad will help you get a wonderful handle feeling and shocked sound effect. Thanks for choosing iPhone Gamepad IX-M20，it is a new designed gamepad for iPhone with multi-functions and built-in 2000MAH li-ion battery.With application of the most advanced electronic boost technology components, high fidelity amplifier and quality accessories;... -
Page 4: Product Feature
After reading this user’s guide, you will have a comprehensive understanding on this excellent gamepad IX-M20. Besides, in the back of IX-M20, there is a universal car holder port, and a universal USB port for external charging. No matter where you are, you can charge the mobile phone, MP3, MP4, PDA, digital camera in different models. -
Page 5: Safety Precautions
Please do not disassemble or modify the gamepad, otherwise it will result in personal inquiry and damadge of the gamepad. Please avoide any liquid or moisture enter into IX-M20 that will lead to short circuit, creepag or some other trouble. -
Page 6: Cleaning And Maintanance
Please avoid using or charging gamepad under the high humidity place, like bath room. As well as avoid the rain. Use the soft cloth to clean the IX-M20. Please do not wipe the gamepad by alcohol, thinner, benzene or other chemical reagents. -
Page 7: Before Using The Gamepad
2 Before using the Gamepad 2.1 Overview 2.1.1 Technical Parameters Model No.: IX-M20 Measurement: 224.5*128.0*54.5mm N.W.: 155g Battery: Polymer lithium battery Capacity: 2000 mAH Input: 5.2V DC, 500mA Output: 5.2V DC, 2.1A (MAX) Cycles: ＞500 times Operation tempreture: -10℃—40℃ Transportation tempreture: -20℃—50℃... -
Page 8: Appearance Description
2.1.2 Appearance Description ① peaker ② miniUSB 5Pin input charging port ③ Function switch ④ Volume control ⑤ ø3.5mm audio output port ⑥ USB 5Pin output charging port ⑦ Cover used to fix the iphone ⑧ iPhone 30pin connctor ⑨ Car holder connector ⑩... -
Page 9: Detach And Installation Of Iphone
⑪ Light indicator area 2.1.3 Detach and Installation of iPhone According to the following steps to detach: ① Slide the function switch to right side to make the gamepad power off. ② 2.Pull the the cover (Please refer to the picture) slightly to left, and then open it up. - Page 10 ② Pull the cover slightly to left, and then open it up. ③ Align the iPhone port and the gamepad male jack, connect the iPhone to IX-M20 male connector, and push it into the very position. ④ Close the cover for fixing.
-
Page 11: Charging Your Gamepad
Disconnect the AC adapter after finishing charging. Attention： Please put the IX-M20 in ventilated place with the tempreture of -10℃~＋45℃ while charging. And make sure to use the charger that offered by the vendor.Use the... -
Page 12: Quick Guide
warranty terms. Charge the battery in time when the gamepad power off automatically or it has the low power warning. And the gamepad will reduce the charging time itself when the battery has not run out. 3 Quick Guide Operations Functions Operation Description... -
Page 13: Troubleshooting
Charging When charging Please refer to the indication appendix Ⅰ Power detection Slide the switch Please refer to the appendix Ⅱ bracket Open it up When enjoy videos, gamepad desk, open bracket in back and adjust it to the right angel. - Page 14 refer to the table below: Cause Solutions Power on disabled Damage of the battery or Detect power charger. capacity or charge the gamepad. Charging when Change power to iphone tempreture is under environment -10℃or above 45℃ Bad connection Change the USB cable or the charger.
-
Page 15: Appendix Ⅰ
5 Appendix Ⅰ LED Indication when Charging Electric Voltage of Quantity LED1 LED2 LED3 LED4 Battery of Batery 3.0-3.7 V flash 3.7-3.8V flash 3.8-4.0V flash 100% 4.0-4.15V flash flash Full ≥4.15V charged Remark: the switch is disabled when charging. 6 Appendix Ⅱ LED indication of examining the battery electric quantity: Electric Voltage of... - Page 16 100% 4.0-4.15V Remark; The led will turn off after 2~5 seconds when you switch for poeer capacity detection. 20101208A1LR...
