Summary of Contents for ATW AirDew AD-5

Page 3: Table Of Contents
Table of Contents Safety Precautions General Specifications Contents General Overview Hybrid Connection Installation & Operation Location of installation Installation precautions Operational procedures Maintenance Operation precautions Storage Cleaning (top tank) Cleaning (bottom tank) Cleaning (exterior case) Filter Replacement Water Filter U.V Light Air Filter Water Production Chart Operational indicator...
Page 4: Safety Precautions
Safety Precautions AirDew AD-5 Safety Instructions 1. Check country electric power supply 230V or 115. 2. Ensure to plug into appropriate grounded socket. 3. Use socket connected to circuit breaker only. 4. DO NOT share socket with other appliances. 5. DO NOT touch power plug with wet hands.
Page 5: General Specifications
Specification Unit 380 (W) x 520 (D) x 560(H)mm Dimension After Packing 455(W) x 580 (D) x 640 (H)mm Unit 39.5 Kg Weight After Packing 42 Kg Input Power 230V 50Hz 115V 60Hz Power Consumption 440 W 550 W Power Electrical Current 2.35 A Cold Water...
Page 6: General Overview
General Overview Ventilation fan Air outlet Front Top cap Menu Button Set Button Power Button FND Display Water valve Rear Top cover Air filter bracket Air filter Easy screws (Simpiy unscrew for air filter exchange) Rear panel Hybrid connection plug Drain connection Hybrid power connector Power cord...
Page 7: Installation & Operation
Installation & Operation Location of installation (Indoor use only) 1. Avoid direct sunlight, exposure to rain and extreme heat or cold. (water parts may freeze or rupture) 2. Place the unit on hard, flat surface to prevent noise, leakage or shaking.
Page 8: Maintenance
Maintenance Operating Precautions 1. DO NOT place objects on-top of unit. 2. To prevent leakage DO NOT tilt unit on side. 3. Completely drain water when moving unit. 4. If leak occurs, unplug unit, drain water completely and call Service Centre. 5.
Page 9: Cleaning (Bottom Tank)
Cleaning (Bottom tank) 1. Use Phillips screwdriver to loosen 2 screws and remove rear panel. (Image 3-1) 2. Touch water level sensor with finger. (5 seconds) (Image 3-2) 3. Wait 2 minutes before unplugging power cord. 4. Disconnect fitting and wire from booster pump and water level sensor respectively.
Page 10: Air Filter
UV light 1. Power Off and unplug unit. Separate rear cover. (loosen & remove 2 screws with Phillips screwdriver) 2. Remove filters. (See water filter replacement) 3. Disconnect the housing of the U.V from ballast. 4. Remove U.V from U.V clip carefully. (There may be water in hose, fitting and U.V) 5.
Page 11: Operational Indicator
Indicator Lights 1. Temperature indicator 2. Humidity indicator 3. Generating water indicator 4. Water level indicator 5. Refresh indicator 6. U.V indicator 7. Cold water temperature indicator 8. Air filter replacement indicator 9. Water filters replacement indicator 10. U.F replacement indicator 11.
Page 12 Self-Error detection function In case of error during operation 2digits on the temperature/humidity indicator show ERROR signals respectively. Turn off and unplug unit. Wait few seconds and Plug In and Turn On again. If the ERROR signal continues to light up, turn unit off and call the Service Centre - Cold temp.
Page 13 Cold water temperature indicator - Shows water temperature selected by Menu/Set button. - Coldest : 7 ~ 12 Celsius degrees - Colder : 15 ~ 20 Celsius degrees - Normal : 20 ~ 25 Celsius degrees. - Yellow text light turns green when cooling system is active Air filter replacement indicator - Air filter needs replacing when the green light turns red.
Page 14: Menu/ Set Button
Set / Reset Button Set/ Reset function 1. Push the menu button for 3 seconds 2. Set/Reset function is selected with blinking text as indicated by pushing the menu button for seconds in sequence, as follows; 1) AWS : Water Generating function - 2) U.V : U.V light self-detector function - RESET 3) Cold water temperature - Coldest ( 7~12...
Page 15: Troubleshooting
Trouble shooting Water generating system-related problems. 1. Is unit connected to proper voltage socket? 2. Is humidity and temperature right to generate water ? (Check if temperature and humidity shows Lo signal) 3. Has air filter been changed? Is RED indicator showing? (Check if air filter exchange indicator shows red) 4.
Page 16: Warranty
A return authorization from your Airdew supplier must be issued prior to returning Airdew products for repair or warranty. RA# must be displayed on outside of box. Atmospheric Water Maker Product name AirDew AD-5 Model number Serial number (YYYY-MM-DD) Purchase date...
