- Page 1 3" OSCILLATING AIR SANDER OWNER’S MANUAL WARNING: Read carefully and understand all INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item# 102181 Page: 1 of 8...
-
Page 2: Technical Specifications
For technical questions and replacement parts, please call 1-800-222-5381. Thank you very much for choosing a NORTHERN TOOL & EQUIPMENT CO., INC. Product! For future reference, please complete the owner’s record below: Model: _______________ Purchase Date: _______________ Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it. -
Page 3: Work Area
WORK AREA Keep work area clean, free of clutter and well lit. Cluttered and dark work areas can cause • accidents. Do not use your air sander where there is a risk of causing a fire or an explosion; e.g. •... - Page 4 Secure work with clamps or a vise instead of your hand to hold work when practical. This • safety precaution allows for proper sander operation using both hands. Store idle air sanders. When the air sander is not in use, store it in a dry, secure place out •...
- Page 5 OPERATION Set Up Fig. 1 1. You will need to prepare a 1/4" air connector (sold separately) to connect to the Air Inlet. First, wrap the 1/4" air connector (not included) with pipe thread seal tape before connecting to an Air Source Hose (not included). 2.
- Page 6 Diagram Parts List Ref. Ref. Description Qty. Description Qty. Body Cap Snap Ring (R-26) Bearing (626ZZ) Spacer R-Bearing Case Cylinder Bolt Set Spring Pin (2.5x6) Nut Set Rotor Valve Cap Vane O-Ring (KS-6) Rotor Spacer Valve Spring F-Bearing Case Valve Page: 6 of 8...
- Page 7 Bearing(608ZZ) Valve Pin Lock Nut Valve Lever 32.5 O-ring Spring Pin Body Cap Regulator Assy Balancer Silencer Bolt Nut Set Pad Retainer Support Bearing (6000DD) For replacement parts and technical questions, please call 1-800-222-5381. MANUFACTURER’S LIMITED WARRANTY The limited warranty set forth below is given by Northern Tool + Equipment Company Inc., (NTE) with respect to new merchandise purchased and used in the United States, its possessions and territories.
- Page 8 The provisions as set forth in this warranty provide the sole and exclusive remedy arising from the sales. NTE shall not be liable for incidental or consequential loss or damages including, without limitation, expenses incurred for substitute or related expenses, or for rental expenses to temporarily replace a warranted product.
