- Page 1 1614 Series INDUSTRIAL RACK MOUNT PC Hardware Guide...
- Page 2 Automation can accept no responsibility for the EMC performance of this apparatus after system integrator/user installation of PCB assemblies not manufactured and/or expressly tested and approved for compliance by Xycom Automation. It is the re- sponsibility of the system integrator/user to ensure that installation and operation of such devices does not void EMC compli- ance.
-
Page 3: Table Of Contents
Table of Contents 1.Product Overview ......6 Product Features ..........7 Locating Components and Connectors. - Page 4 6.System Configuration ......40 Pin Assignments ..........40 AC Input Power Connector.
-
Page 5: Product Overview
Product Overview The Xycom Automation 1614 Industrial rack mount PC puts the power and versatility of a PC-compatible computer in an industry standard package that is ideal for the factory floor and other industrial applications. The 1614 industrial rack mount PC meets the requirements of a wide variety of applications where both a powerful PC and a durable industrial enclosure are required. -
Page 6: Product Features
PRODUCT FEATURES Rack mount 4U height • Choice of backplanes with eight ISA and four PCI or five ISA and seven PCI available • expansion slots Intel® Socket 370 Celeron® (SBC-370) and Slot 1 Pentium® III (SBC-SLOT1) processors • up to 550 MHz Up to 256 MB SDRAM •... -
Page 7: Locating Components And Connectors
LOCATING COMPONENTS AND CONNECTORS External Views Figure 1. Front view with the door closed. A, Logo area B, Case handles C, Air filters D, Access latch ™ The front panel incorporates a logo panel that can be customized. Figure 7 Logo area: depicts the label dimensions and provides the recommended requirements for a customized label. - Page 8 Figure 2. Front view with the door open. A, Power ON/OFF switch B, Reset switch C, PS Reset switch D, Power LED indicator light E, HDD1 LED indicator light F, HDD2 LED indicator light G, PS Alarm LED indicator light H, PS1 LED indicator light I, PS2 LED indicator light J, PS/2 mouse connector...
- Page 9 A keyboard can interface with the system through this six-pin PS/2 keyboard connector: PS/2-compatible connector. Refer to page 42 for pin assignments for the keyboard connector. • Note: Do not connect a keyboard to this front connector if a keyboard is plugged into the key- board connector on the rear panel.
- Page 10 Figure 3. Rear view. A, Power connector B, Parallel port C, PS/2 keyboard and mouse connector D, COM1 serial connector, RS-232 E, Ethernet port F, Video connector G, COM2 serial connector, RS-232 H, Fan Outlet grille For AC power units, the standard power cord must be securely posi- Power connector: tioned before turning power ON.
-
Page 11: Opening The Unit
Note: Do not connect a mouse to this rear connector if a mouse is plugged into the key- board connector on the front panel. Doing so may cause each mouse to operate improperly. This RS-232 compatible serial port is located right above the COM1 serial connector, RS-232: PS/2 keyboard/mouse connector (see figure 3). - Page 12 Remove the three Phillips-head screws from the top panel. Figure 5. Removing the top cover. Tilt the front of the top panel upward, and then slide the panel back towards the rear of the unit until it is free. Product Overview...
-
Page 13: Internal View
Internal View Figure 6. Internal system components. A, Backplane B, ISA/PCI expansion slots C, CPU board D, Power supply E, 5.25" drive bays F, 3.5" drive bays G, Speaker H, Cooling fan Depending on your system, the backplane has either eight ISA and four PCI Backplane: or five ISA and seven PCI available expansion slots. -
Page 14: Product Mounting And Dimensions
PRODUCT MOUNTING AND DIMENSIONS 16.86 (428.24) 6.80 (172.7) Rear 16.86 (428.24) (71.12) .9 (22.86) 15.36 (390.14) 22.75 22.875 (577.85) (581.03) 24.25 11.74 (615.95) (298.20) 8.12 (206.25) 4.50 (114.30) Side 19 (482.6) 1.50 (38.1) 7.00 4.00 (177.8) (101.6) (4U) Front Front with door closed All dimensions are in inches (mm) Product Overview... -
Page 15: Creating A Customized Logo
You may place a customized label on the unit. Figure 7 provides the dimensions and recommended requirements for a customized label. 0.12(3.05)R Figure 7. Customized logo. ™ 0.67(17.02) 2.17(55.12) Once you have created a customized label, place it over the “Xycom Automation” label. Product Overview... -
Page 16: Product Specifications And Ratings
PRODUCT SPECIFICATIONS AND RATINGS Environmental Operating Nonoperating 0C to 50C -20C to 60C Temperature 20% to 80% RH, noncondensing 5% to 90% RH, noncondensing Humidity Shock a 2g peak acceleration, 11 msec duration 7.5g peak acceleration, 11 msec duration 0.081" peak to peak displacement Vibration 5 to 2000 Hz .5 g acceleration... -
Page 17: Hardware Options
Hardware Options CONNECTING EXTERNAL OPTIONS To attach peripherals and make other external connections to your unit, refer to pages 9-11 for connector locations and appendix A for pin assignments. SYSTEM MEMORY You can order your CPU factory-configured for many configurations of SDRAM. You can reconfigure the SDRAM capacity by changing the SDRAM Double In-line Memory Modules (DIMMs) on the unit's motherboard. - Page 18 Insert memory vertically. Figure 8. Installing memory. A, DIMM Memory B, Locking Mechanism C, DIMM Socket Lock into place. Figure 9. Memory installed. Hardware Options...
-
Page 19: Isa/Pci Expansion
ISA/PCI EXPANSION The 1614 comes with a choice of backplanes: eight ISA and four PCI or five ISA and seven PCI available expansion slots. To Add ISA/PCI Cards Check that the memory, I/O configuration, and processor requirements for the board you want to install do not conflict with the CPU and memory maps of boards already installed in your system. -
Page 20: Internal Drive Options
Slide the card into the slot. Push down on the card evenly until it firmly rests in the card cage connectors. Note: DO NOT force the card or apply uneven pressure. Secure the card's ORB to the 1614 by replacing and tightening the screw that was removed. - Page 21 Lift to remove the drive bay. Figure 11. 5.25" drive assembly. Add or replace 5.25" devices to the drive bay by securing each with screws. Note: If the drive bay is equipped with blue shock mounting grommets, insert stabiliz- ing cylinders into center of each grommet before securing devices with screws. To Add or Replace 3.5"...
- Page 22 Slide the 3.5" drive bay approximately 1" towards the back of the chassis to free it from the latches. Note: It may be necessary to remove cards that are in the way. Lift to remove the drive bay. Figure 12. 3.5" drive assembly. Add or replace 3.5"...
-
Page 23: Installation
Installation Note: The procedures in the section are intended for service personnel only. ENVIRONMENTAL CONSIDERATIONS The system’s rugged design allows it to be installed in most industrial environments. You can refer to the unit’s electrical and environmental specifications and tolerances (page 17) for more detailed information. -
Page 24: Excessive Heat
Excessive Heat The chassis is designed to dissipate heat with force convection cooling (drawing air from the front and exhausting hot air out the back). Therefore, the rack must provide sufficient air circulation paths in the front and back areas. The chassis temperature is usually elevated above ambient temperatures in a rack environment. -
Page 25: Location And Enclosure
Location and Enclosure Place the unit to allow easy access to the system ports. • Account for the unit’s dimensions when selecting an installation location or enclosure • (see page 15). Place the unit at a comfortable working level. • Mount the unit in an upright position. - Page 26 Disconnect all cables and cords from the unit. Place the unit on a solid work surface. Attach the slide rails to the unit (Xycom Part number 1600-RMS). Install the unit securely in the rack with standard rack-mounting hardware so that the drive access door faces outward.
- Page 27 To Rack-Mount the Unit Attach the unit securely in the rack using the proper mounting hardware for your rack. Figure 14. Installing the mounting hardware. Torque screws to 35 in/lbs (3.95 Nm). Install the unit in the rack, using standard rack-mounting hardware, so that the drive access door faces outward.
-
Page 28: Wall-Mounting
To Wall-Mount the Unit Remove the rack mount ears with handles by removing the screws holding them in place. Replace the screws. Attach wall-mounting brackets (Xycom order number 1600-WMB) on both sides of the unit. Figure 15. Installing wall-mounting hardware. -
Page 29: The Power Supply
THE POWER SUPPLY See page 17 for the electrical specifications. To Attach the Power Cable If your unit is equipped with -48 volt DC power supply, you must create a power cable before you can connect your unit to a power source. See "Creating a DC Power Supply Cable"... -
Page 30: Maintenance
Returned products are tested with standard Xycom Automation test diagnostics. To prepare the unit for shipment Obtain an RMA number for your unit by calling your nearest Xycom Automation Repair Department or Xycom Automation, Inc. at 1-800-289-9266 or 734-429-4971. Please have the following information available: Company name and shipping and billing addresses •... -
Page 31: Replacing Fan
Send the unit to the address given when you receive your RMA number. REPLACING FAN We do not recommend replacing the single 82 CFM fan yourself. Please contact Xycom Automation's Product Repair and Customization Department (PR&C). For product re- pair procedures, refer to page 32. -
Page 32: Spare Parts
Each power supply should have a back-up. In applications where immediate operation of a failed system is required, you may need to stock an entire spare computer module. Description Xycom Part Number Drives 6.4 GB 139923-001... -
Page 33: Troubleshooting
Xycom Automation. We do not recommend third-party replacement components as they may not be compatible with the unit's hardware and software. When a failed unit is returned to Xycom Automation for repair, a detailed and accurate problem description must accompany it (see page 32). -
Page 34: General Operational Problems
General Operational Problems Use this chart when there is a problem, but no error messages occur during power-up or normal operation. Problem Cause Action Blank screen on Power disconnected Check power supply voltage and attached monitor connection integrity Video cable disconnected Check video cable and connection integrity Line fuse blown... -
Page 35: Bios Error Messages
BIOS Error Messages Use this chart when the BIOS detects a problem during the Power On Self Test (POST). After the problem is detected, a BIOS error message displays (before the Windows op- erating system starts). Refer to board manual to change BIOS settings. Message Possible Cause Action... - Page 36 Message Possible Cause Action Previous boot Previous boot did not complete Enter Setup, access the Exit Menu, choose incomplete. Default the "Get Default Values" option, save the configuration used. settings, exit Setup, then reboot Diskette drive A (or Floppy drive error Check cable to floppy drive.
-
Page 37: System Configuration
System Configuration PIN ASSIGNMENTS This section specifies pin assignments of connectors. AC Input Power Connector This connector is the 3-pin power input for the AC and dual redundant AC units. AC Pin Number AC Description AC GND DC Input Power Connector Pin Number Description -VIN... -
Page 38: Com1 Serial Connector, Rs-232
Pin Number Description SELECT AUTOFEED PERROR INIT SELIN COM1 Serial Connector, RS-232 Pin Number Name System Configuration... -
Page 39: System Configuration
COM2 Serial Connector, RS-232 Pin Number Name PS/2 Keyboard Connector (on front panel and K side of Y cable) Pin Number Name KB DATA KB CLK PS/2 Mouse Connector (on front panel and M side of Y cable) Pin Number Name MS DATA MS CLK... -
Page 40: Ps/2 Keyboard/Mouse Connector (On Rear)
PS/2 Keyboard/Mouse Connector (on rear) Pin Number Name KB DATA MS DATA KB CLK MS CLK Ethernet (LAN RJ45) Port This connector is used for 10 BaseTX or 100 BaseTX Ethernet connection. Pin Number Description 75 W termination 75 W termination 75 W termination... -
Page 41: Vga Connector
VGA Connector Pin Number Description GREEN BLUE DDC DAT HSYNC VSYNC DDC CLK SYSTEM INTERRUPTS (IRQS) SBC-370 Board Description IRQ0 System Timer IRQ1 Keyboard IRQ2 Cascade to IRQ Controller IRQ3 COM2/COM4 IRQ4 COM1/COM3 IRQ5 Unused IRQ6 Floppy Drive (FDC) IRQ7 Printer IRQ8 Real Time Clock... -
Page 42: Sbc-Slot1 Board
Description IRQ13 IRQ14 Primary IDE IRQ15 Secondary IDE SBC-SLOT1 Board Description IRQ0 System Timer IRQ1 Keyboard IRQ2 Cascade to IRQ Controller IRQ3 COM2/COM4 IRQ4 COM1/COM3 IRQ5 Unused IRQ6 IRQ7 Printer IRQ8 RTC Clock IRQ9 Unused IRQ10 7880 SCSI IRQ11 82559LAN IRQ12 PS/2 mouse IRQ13... -
Page 43: Sbc-Slot1
SBC-SLOT1 DMA Channel Function Available Available Floppy Disk (8-bit transfer) Available Cascade for DMA controller 1 Available Available Available MEMORY MAP SBC-370 1st MB Memory Address Map The default setting is highlighted. Memory Address Description 00000-9FFFF System Memory A0000-BFFFF VGA Buffer C0000-CBFFF VGA BIOS D6000-D7FFF... -
Page 44: I/O Map
I/O MAP SBC-370 I/O Address Range Description 000-01F DMA Controller #1 020-021 Interrupt Controller #1, Master 040-05F 8254 Timer 060-06F 8042 (Keyboard Controller) 070-07F Real time Clock, NMI (non-maskable interrupt) Mask 080-09F DMA Page Register 0A0-0BF Interrupt Controller #2 0C0-0DF DMA Controller #2 Clear Math Coprocessor Busy Reset Math Coprocessor... -
Page 45: Sbc-Slot1
SBC-SLOT1 I/O Address Range Description 000-01F DMA Controller #1 020-021 Interrupt Controller #1, Master 040-05F 8254 Timer 060-06F 8042 (Keyboard Controller) 070-07F Real time Clock, NMI (non-maskable interrupt) Mask 080-09F DMA Page Register 0A0-0BF Interrupt Controller #2 0C0-0DF DMA Controller #2 Clear Math Coprocessor Busy Reset Math Coprocessor 0F8-0FF... -
Page 46: Agp Vga Controller
AGP VGA CONTROLLER S3 Trio® 3D/2x AGP VGA controller • 133 MHz AGP bus speed • Screen resolutions supported up to 1280 x 1024 x 64K colors @ 60 Hz refresh • Screen resolutions also supported up to: • 1600 x 1200 x 64K colors at 85 Hz refresh, non-interlaced mode •... - Page 47 Index AC power supply ....30 environmental specifications ... . . 17 access latch .
- Page 48 memory map ..... . 46 mounting dimensions ....15 unit, returning .
- Page 49 161420(C) Xycom Automation, Inc. Canada Sales: 905-607-3400 734-429-4971 • Fax: 734-429-1010 Northern Europe Sales: +44-1604-790-767 http://www.xycomautomation.com Southern Europe Sales: +39-011-770-53-11...
