WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”...
Page 3
IMPORTANT SAFECUARDS 1. Read Instructions 13. Damage requiring Service Unplug this equipment from the wall outlet and refer servicing to All the safety and operating instructions should be read before the qualified service personnel under the following conditions: appliance is operated. A.
1. SAFETY CAUTIONS ※ Follow these instructions to keep the user safe and prevent property damage. Read them carefully before the use of the product. The responsibility falls on the user to install and use the product properly. 1.2 Installation-related 1.1 Power Source-related ①...
1.3 Cleaning and Usage-related ⑥ When cleaning the product, unplug the power ① Un p lu g the p o wer p l ug du rin g li ghtnin g , cord and gently wipe using a soft cloth. Do not thunderstorm or when not in use for long periods directly spray water on the product or do not use of time.
2. OUTLINE 2.1 Functions This DVR is divided 4ch, 8ch and 16ch by model. This DVR provide superior video image quality on Live view and Playback. • Pentaplex Operation Performance (Live, Recording, Playback, Backup, Network) • Up to maximum 16 channel composite input ports depending on model. (4/8/16) •...
2.2 System Organization CAMERA LCD/VGA PTZ KEYBOARD MONITOR Video Network input MAIN/SPOT Video out MONITOR Audio Input Alarm Sensors Audio Input Output SIREN SENSOR SPEAKER...
3. DVR ORGANIZATION 3.1 Front Panel Description NOTE: Turn on the DVR after connecting the power cord, camera input and monitor completely Power Record Network USB Port Remote Control Sensor...
Page 12
3. DVR ORGANIZATION 3.1 Front Panel Description NOTE: Turn on the DVR after connecting the power cord, camera input and monitor completely USB PORT Number Buttons Display/Record Menu / ESC Direction Buttons Enter Button Front LED Fast Play Button/ Remote ROTATE/Backup Search/Pause REPLAY...
Page 13
※ Front Button The front panel of DVR is similar as normal VCR or Multiplexer and the functions are also similar . Front buttons have various functions and are used for DVR initial setting and others. Please refer to the below explanation. NUMBER buttons (0 ~ 9) Displayed selected camera number to full screen.
Page 14
Direction buttons (▲, ▼, ◀, ▶ ) This buttons are used when move to other menu or change the position of the CAMEO screen. In PTZ mode, it is used PAN/TILT function. ▲ : In Playback mode, it is Panorama search function button. In PTZ mode, it is used to move the camera to up.
3.2 Real Panel ▪ LT-400 Power on CVBS Monitor HDMI Monitor Network Camera Input 4 Sensor Input RS-485 1 Alarm Out Audio In / Out...
Page 16
3.2 Real Panel ▪ LT-800 / 1600 Power On Network CVBS Monitor Spot Out HDMI Monitor Camera Input VGA out Audio In / Out 8 Sensor Input 2 Alarm Out HDMI Monitor...
3.3 Remote Controller RECORD DISPLAY ROTATE MENU LOCK(LOG-OUT)/ REPEAT NUMBER ▲ Direction Key /Panorama Play ◀ Direction Key / ENTER Reverse Play ▶ Direction Key / Play Fast Reverse Play/ ▼ Direction Key /Smart Play PAUSE Fast Forward Play / PLAY BACKUP SEARCH PTZ ZOOM...
4. LIVE 4.1 Live Screen Execution Information Message Camera Name Record Status Icon Live Screen PTZ Control Information Screen Expand/Reduction Backup Progress Window Status(%) Current Date and Current Channel Current Event Information Time Information Icon Icon Sequence Icon - Record Icon (Red) - Video-loss Icon When record in live screen.
4.1.1 Top Menu In live screen, if ▲ button of the remote controller or front panel is pressed, or if the mouse cursor is placed over the end of the top area, the top menu is appeared. Search Backup Status Setup Log-out 4.1.2 Bottom Menu...
4.1.3 CAMEO Menu In live screen, if the ENTER button of the remote controller or front panel is pressed, a blue square cursor will be appeared. If the ENTER button is pressed again, the CAMERA menu will be appeared. ▪ ADJUSTMENT : Adjust the selected camera color setting. ▪...
Page 21
▪ PTZ : PTZ Camera should be installed otherwise the PTZ menu is not activated. The following picture will be appeared when select PTZ menu. ※ Using Mouse : On the above menu, when click the right button of mouse, the control screen for Menu, Zoom, Focus and Iris will be appeared.
Page 22
- SPEED SETUP : Set the PTZ camera speed. ( 1 to 8) NOTE: If the mouse is used to move the PTZ camera, the movement speed depends on the position of the mouse. As the mouse pointer moves away from the center, speed becomes faster. - PRESET SETUP : Set the preset position.
5. SETUP In this category, there are General, Camera, Event, Schedule, Ethernet and System Information. On the Top menu, select the [SETUP] menu. After select the menu, the following Log-in window will be appeared. Enter the password by the key buttons and press the ENTER button.
5.1.1 GENERAL [SYSTEM] ▪ VIDEO FORMAT : Set the Camera Type (NTSC / PAL) If select AUTO menu, DVR recognize camera type automatically. NOTE: If NTSC and PAL cameras are connected simultaneously, error may occur. ▪ LANGUAGE : Select the language. (English, Germany, French, Spanish, Japanese, Chinese, Italian, Russian, Dutch and Korean) ▪...
Page 25
5.1.1 GENERAL [DATE / TIME] ▪ DATE FROMAT : Select the data format. (YY/MM/DD) / (MM/DD/YY) / (DD/MM/YY) ▪ TIMEZONE : Select the timezone and DST. The city which don’t use DST is set to [OFF] automatically. ▪ DATE DISPLAY : Display date on live screen or not. ▪...
5.1.2 ALARM OUT ▪ SIGNAL : Select on/off to use alarm by channel. ▪ ALARM SET : Check the alarm connection whether it works properly or not. Press the [SET] button then alarm device will be operated. ▪ ALARM CLEAR : Press the [CLEAR] button then alarm device will not be operated. 5.1.3 DISK ※...
Page 27
5.1.3 DISK [CHECK / USB] ▪ EARLIEST RECORD : Display the earliest recorded data information. ▪ LATEST RECORD : Display the latest recorded data information. ▪ DISK CHECK : Check the data from the earliest recorded to the latest recorded. ▪...
5.1.4 MONITOR ▪ RESOLUTION : Select the resolution for connected monitor. ▪ BORDER COLOR : Change the border color. ▪ ALPHA BLENDING : Set the transparency of menu. (Set 1 to 20 and 20 is closer to the more transparent.) [RESOLUTION selected screen] [ALPHA BLENDING selected screen]...
5.1.5 ACCOUNT ※ Add / delete any user and give permission freely. ※ When add new user, have to input new password. When delete use, confirm again. NOTE: ( Default ADMIN password is 1111 ), Initial user name can be modified but can not delete. CAUTION: Default Admin account must not be deleted before add new user.
5.1.6 CONFIG ▪ SLOT : Select the slot to load or save on DVR memory. ※ DEFAULT : Change factory default setting. ▪ DATE : Display the latest saved date. ▪ LOAD : Load the saved data. ▪ SAVE : Save the set data. ▪...
5.2 CAMERA SETUP In this category, there are Camera, PTZ, Spot, Sequence and Private Zone setting. Select the [CAMERA] Menu. 5.2.1 CAMERA ▪ CAMERA LABEL : Select the camera label of live screen. (ALL / NUMBER / NAME / OFF) ▪...
5.2.1 CAMERA If select the camera name, the virtual keyboard will be appeared. Max camera name should be less than 11 character. [Virtual Keyboard] 5.2.2 PTZ [PTZ] ▪ PORT : Select the Baud Rate for using PTZ camera. ▪ ID : Select the ID for using PTZ camera. ▪...
5.2.3 SPOT CAMERA : Select the camera for display on spot monitor. DEFAULT : Select the camera for display on spot monitor when sequence is off. SEQUENCE : Select On/Off for sequence screen. INTERVAL : Select the interval time to move next channel. The max value is 256 sec. POPUP : Select On/Off for pop-up screen when event is occurred.
5.2.4 SEQUENCE PAGE DWELL TIME : Select the dwell time to move next channel. CAMEO DWELL TIME : Select the dwell time for CAMEO sequence. NOTE: CAMEO sequence means selected camera is rotated in select cameo of division screen. Camera image which is shown on the other CAMEO of division screen is not included in CAMEO sequence.
5.2.5 PRIVATE ZONE ▪ ZONE ENABLE : Select On/Off to use. (LIVE mode/ SEARCH mode) ▪ ZONE COLOR : Select the color to hide. ▪ ZONE : Select the zone to hide. (When select the ZONE button, the camera image will be appeared. NOTE : Move the blue dot to a desired location and press the OK button.
5.3 EVENT SETUP In this menu, there are Motion, Alarm in, Video Loss, System and Display setup. Select the [EVENT] menu. 5.3.1 MOTION [INPUT] ▪ ACTIVE : Select On/Off to activate motion. ▪ LEVEL : Select the sensitive for motion trigger. (Select 1 to 5 level) ▪...
Page 38
▪ AREA SETUP In the Area setup, the Red square is shown at the left top side of the screen. If select the OK button, the dot color will be changed to Green. A motion area can be selected by the direction buttons. NOTE : When the status is Red square, can move any direction to select.
Page 39
[ACTION] ▪ RECORD : Select the channel for record. ▪ ALARM : Select On/Off for alarm. ▪ BUZZER : Select On/Off for buzzer. ▪ PRESET : Set the preset number. (When motion is triggered, the PTZ camera move to the set preset number position) ▪...
5.3.2 ALARM IN TIP: If select the ACTIVE+ / TYPE+ menu, can change all settings at once. [INPUT] ▪ ACTIVE : Select On/Off to activate alarm. ▪ NAME : Type any name. ▪ TYPE : Select the alarm type. (NO : Normal Open / NC : Normal Close) [ACTION] ▪...
5.3.3 VIDEO LOSS TIP: If select the ACTIVE+ menu, can change all setting at once. [INPUT] ▪ ACTIVE : Select On/Off to activate. [ACTION] ▪ RECORD : Select On/Off for record. ▪ ALARM : Select On/Off for alarm. ▪ BUZZER : Select On/Off for buzzer. ▪...
[MAIL] – Select option On/Off for e-mail notification. ▪ POWER / MENU / LOGIN FAIL / DISK FULL / LOG IN / SMART [E-MAIL] ▪ Select On/Off to send e-mail notification with each item. (POWER On & Off, Menu Change, Login Fail, Disk Full, Log in and SMART information. 5.3.5 DISPLAY ▪...
5.4 RECORD SETUP In this menu, there are Resolution, Schedule, Record, Audio, Manual, Filter setup. Select the [RECORD] menu. 5.4.1 RESOLUTION ▪ RESOLUTION : Select the resolution by each channel. (STD=CIF / HIGH=Half D1 / HIGHEST=D1)
5.4.2 SCHEDULE ▪ SETUP MODE : Select the record schedule. (TYPICAL / CUSTOM) [TYPICAL] ▪ DAY TIME : Select the day time. (The night time is changed automatically according to the day time zone) ▪ WEEKEND : Set the weekend zone. [CUSTOM] ▪...
5.4.3 RECORD [DAY] / [NIGHT] / [WEEKEND] ▪ TIME : Set the recording frame and resolution by channel. ▪ EVENT : Set the event recording. (Frame / Resolution / Post recording time [5 to 100 second]) TIP : The frame can be set by the direction button in setup screen. If set to [Typical] in [SCHEDULE] menu, the DAY / NIGHT / WEEKEND menu will be changed to REC0/ REC1 / REC2.
5.4.4 EVENT ▪ PRE RECORD : Select the pre recording time by second. (0 ~ 60 SEC) ▪ POST RECORD : Select the post recording time by second. (0 ~ 100 SEC) 5.4.5 AUDIO ▪ RECORD : Select On/Off for audio recording by channel. TIP: If select the RECORD+ menu, can change all setting at once.
5.4.6 MANUAL ▪ SPEED : Select the recording frame by each channel. ▪ Quality : Select the resolution by each channel. ▪ AUDIO : Select On/Off for audio recording by each channel.
5.5 ETHERNET SETUP In this menu, there are Network, Serial, DDNS, E-mail setup. Select the [ETHERNET] menu. 5.5.1 NETWORK [ETHERNET] ▪ DYNAMIC IP : Select On/Off for dynamic IP. If Dynamic IP is OFF, DVR get IP address from router automatically. ▪...
Page 50
5.5.1 NETWORK [CLIENT] ▪ CLIENT ACCESS : Select client access options. ( ALL / RANGE ) ▪ BEGIN ADDRESS / END ADDRESS (When select RANGE option, type the IP address to accept) : Input the acceptable IP address. ▪ SMS PORT (TCP) : Select SMS port. ▪...
5.5.2 SERIAL [RS-485 INPUT SETUP] ▪ SERIAL TYPE : Select external device. ▪ MODEL : Select the protocol to use. ▪ PORT : Select the Baud Rate / DATA bit / Parity / Stop Bit.
5.5.3 DDNS ▪ DDNS SERVER : Select DDNS server. (Ddnsdvr.com / Dyndns.com / ChangeIP.com) ▪ HOST NAME : Input the host name from the registered on DDNS server. ▪ USER NAME : Input the user name from the registered on DDNS server. ▪...
5.5.4 E-MAIL [ADDRESS] ▪ SEND E-MAIL : Select On/Off for use. ▪ SCHEDULE : Set the usage time. (From : Start time / To : End time) ▪ E-MAIL ADDRESS : Input the E-mail address to receive. [SERVER] ▪ MAIL SERVER : Select the mail server. (SMTP server / DVR System) ▪...
5.6 SYSTEM SETUP In this menu, there are System Log, Status, Version. Select the [SYSTEM] menu. 5.6.1 SYSTEM LOG ▪ Check the system log by the left, right direction button.
5.6.2 STATUS [DISK] ▪ Display HDD Status. ▪ HDD INFORMATION : Display the HDD status. : DVR check the HDD bad sector automatically and if there is bad sector, skip the bad sector then record continuously.
Page 57
5.6.2 STATUS [RECORD] ▪ Display RECORD Status. [AUDIO] ▪ Display AUDIO Status.
6. SEARCH On the Top menu, select the [SEARCH] menu. After select the menu, the following Log-in window will be appeared. Enter the password by the key buttons and press the ENTER button. (The default password : 1111) ▪ QUICK SEARCH : Search by date, hour, minutes in detail. ▪...
6.1 Search Screen Configuration Execution Information Message Camera Name Search Information Icon Search Icon Search Screen Repeat Time Information Screen Expand/Reduction Window Backup Progress (%) Recorded Audio Search Date/Time Information Icon 6.1.1 Search Menu When mouse cursor is placed over on the bottom side, the Search menu is appeared. Division Screen Play 1 frame backward Fast forward play...
6.1.2 CALENDAR SEARCH a. Select the data by the direction button. - Recorded data is displayed the orange color. b. Select the time by the direction button. - After select hour, minutes will be appeared. NOTE: The time graph color is different by the recording mode. Continuous Recording = Blue, Audio Recording = Light Blue, Event Recording = Red.
6.1.3 EVENT SEARCH ▪ DATA : Select Date to search. ▪ MOTION : Select On/Off event for search. ▪ ALARM IN : Select On/Off event for search. ▪ VIDEO LOSS : Select On/Off event for search. ▪ SELECT CAMERA : Select the camera for search. ▪...
6.1.4 OVERLAPPED LIST ▪ If user change the time or applied DST (Daylight Saving Time), there will be overlapped data. ▪ After select the list, if select the [PLAY] button, can search [QUICK SEARCH] or [EVENT SEARCH].
6.1.5 PANORAMA SEARCH ▪ During normal search, press the [PANORAMA] button. ▪ By mouse, click the right mouse button and click the [PANORAMA] Search. ▪ Playback with frame by frame. 6.1.6 SMART SEARCH ▪ During normal search, press the [SMART] button. ▪...
6.1.7 SECTION REPEAT SEARCH ▪ During normal search, press the [LOCK] button. When press one time, the start position is set, press one more time, the end position is set. ▪ By mouse, click the below red circle button. ▪ Only playback the set section repeatedly. ▪...
Page 66
※ Button Explanation in Search mode ▪ Remote Controller or Front button Button Explanation SEARCH Display the [SEARCH] menu. Cancel the Search mode or return to the live screen. ENTER Select the CAMEO menu. FAST REVERSE When reverse play, up and down play speed. FAST FORWARD When forward play, up and down play speed.
7. BACKUP On the Top menu, select the [BACKUP] menu. After select the menu, the following Log-in window will be appeared. Enter the password by the key buttons and press the ENTER button. (The default password : 1111) ▪ TARGET : Select the device to backup. (USB / DVD) ▪...
7.1 Play with backup data ▪ After backup, the DVR Player is copied with data. ▪ Backup data only can be played on DVR Player at PC. ▪ Can export to JPEG still shot.
8. APPENDIX 8.1 Firmware Upgrade ① Copy the firmware on USB and connect on the Memory Stick USB. ② For upgrade, restart the DVR. ③ After restart, when upgrade window is appeared, select the START button. ⑤ After upgrade, remove the USB and select OK button. Then DVR is restarted.
8. APPENDIX 8.2 Web Client ※How to connect For using web connection through internet, 7000 and 80 ports should be set as port forwarding at the Router. 1. To connect Web viewer, the [Ethernet] setup on DVR is required firstly. 2.
8.2.1 Web viewer Functions Division screen ① ② ③ ④ Disconnect Connect ① ② Control Zoom In Brightness control Contrast control Zoom Out ③ ④ SEARCH ALARM Open data Exit Search...
8. APPENDIX 8.4 Trouble Shooting SYMPTOM MEASURES If the power LED is not lighted, check the below items. No Power - Check the power plug and outlet. (Refer to the [Cautions for safety] - Connect the power cord to the power connector of DVR properly. - Connect the camera cable to the DVR port properly.
Page 74
- Check the battery polarity. - Check the remote controller ID. (Refer to the [Remote Controller Configuration]) Not work remote controller - Focus on the remote controller to the IR sensor. - Use the remote controller within 7 meters from DVR. - Change the battery.
8. APPENDIX 8.6 Mobile Viewer (Apple & Android) -. Download the [mpocketdvr] on App store. (Free software) -. Download the [pocketdvr] on Android market. (Free software) -. How to use two apps are the same. - Execute the [mpocketdvr or pocketdvr] then appears the below screen. Press the [+] button and move to next step.
Page 76
8.6 Mobile Viewer (Apple & Android) -. Enter the DVR information for connection. - After enter the DVR information, press the button. - On the DVR list, press the below red circle area then connections is started. - ADD : Press the button for other DVR.
Page 77
8.6 Mobile Viewer (Apple & Android) - Support 1,2,8,16 split screen. - By the screen touch, change 1 screen or multi screen. - Horizontal view, Vertical view are supported. : Exit application. : Playback by date / time. After select date and time, press the button for playback.
Page 78
8.6 Mobile Viewer (Apple & Android) - Explanation of each button. Image capture : In 1 screen mode, save JPEG image by this button. Pause : In live view, image is paused by this button. Paused Icon : Press this button again, Pause is stopped by this button. Screen Split : Change to 2,8, 16 split screen by this button.
