Summary of Contents for Dlogixs MEETUS-E400
-
Page 1: Operation Manual
MEETUS - C400 Operation Manual www.meetns.com... -
Page 2: Table Of Contents
MEETUS-C400 Wireless Network System Contents Installation Features Front Panel Information Rear Panel Information Specifications www.meetns.com... -
Page 3: Installation
MEETUS-E400 Wireless Network System 1. Installation Before Using This is for content to prevent damage of property and to protect user, please read surely and use rightly. Caution This installation(Caution for using safety) is including the content of variable equipment generally, so there can be included a content not to accord with an equipment as customer had. - Page 4 MEETUS-E400 Wireless Network System 1. Installation Caution Keep using Power and Voltage to be indicated, otherwise there is the risk like electric shock, fire. This equipment has limitation of power to supply from AC outlet, so use total power consumption not to exceed power to be indicated.
-
Page 5: Features
MEETUS-C400 Wireless Network System 2. Features 7 INCH WIDE TFT LCD PANEL WITH FULL TOUCH SCREEN. NETWORK CONTROL FOR ALL FUNCTION. (CONTROL POSSIBILITY FROM MASTER CONTROL ROOM) INTERGRATED CONTROL SYSTEM, MOVEMENT CONTROL (2CH), LIGHTING CONTROL (2CH), AUDIO MIXER CONTROL (4CH IN/OUT, 4x4 MIXING, STEREO, 3BAND EQ), VIDEO MATRIX (4x4 RGB SWITCHER), POWER AMPLIFIER MONITOR (FEEDBACK FOR 4CH),... -
Page 6: Front Panel Information
MEETUS-C400 Wireless Network System 3. Front Panel Information 7 INCH TOUCH LCD Moving to SETUP menu and setting each function with touch screen. UP/DOWN Doing UP function for volume, lighting brightness and movement control. Doing DOWN function for volume, lighting brightness and movement control. CH(MUTE) Muting sound. -
Page 7: Rear Panel Information
MEETUS-C400 Wireless Network System 4. Rear Panel Information 11 12 AC POWER ON/OFF SWITCH Switch for turn on/off. EARTH TERMINAL Terminal to connect ground wire. MOVEMENT / DIMMER ・ Terminal for 2CH movement control. ・ Terminal for 2CH lighting control. AMP IN 4CH power amplifier input terminal for monitoring. -
Page 8: Specifications
POWER : AC 220V/4A, 60Hz ■ MOVEMENT CIRCUIT : 2 CIRCUIT POWER : AC 220V/4A, 60Hz ■ GENERAL COMMUNICATION : LAN DIMENSION(WxHxD) : 482(W)x132(H)x277(D)mm WEITGHT : 5kg ※This product specifications and specifications to improve performance, there may be some changes. www.dlogixs.com...
