DVM-500Ultra All Weather Video System
Installation Instructions
Copyright © 2009-2012, Digital Ally, Inc. All Rights Reserved, Printed in U.S.A. This publication may not be reproduced,
stored in a retrieval system, or transmitted in whole or part in any form or by any means electronic, mechanical,
DVM-500Ultra Installation Guide REV B
Page 1
recording, photocopying, or in any other manner without the prior written approval of Digital Ally, Inc.
Advertisement
Table of Contents
Summary of Contents for Digital-Ally DVM-500Ultra
- Page 1 DVM-500Ultra All Weather Video System Installation Instructions Copyright © 2009-2012, Digital Ally, Inc. All Rights Reserved, Printed in U.S.A. This publication may not be reproduced, stored in a retrieval system, or transmitted in whole or part in any form or by any means electronic, mechanical,...
-
Page 2: Table Of Contents
STEP 4: Attach the DVM-500Ultra Mount ....................10 STEP 5: DVM Connections ........................11 STEP 6: Mount the DVM-500Ultra and Interface Box ................. 11 STEP 7: GPS Connection ........................... 12 STEP 8: Power, Ignition, Ground, and Trigger Connections ............... 12 Wiring Connections Chart ........................ -
Page 3: Standard Limited Warranty Model Dvm-500Ultra
REAR VIEW MIRROR IN-VEHICLE DIGITAL VIDEO SYSTEM We warranty that our In-Car Digital Video System, Model DVM-500Ultra, will be free from defects in workmanship and material for a period of 24 months from the date of purchase by the original purchaser. If... -
Page 4: Before You Begin Installation
External Monitor Module 006-08104-00 with Sunshield 006-08105-00 Bullet Camera Saddlebag Mount 002-05027-00 For Main Module Saddlebag Mount 002-05027-01 For Main Module Faring Mount For 002-05028-00 Bullet Camera Rail Mount For 002-05029-00 Bullet Camera DVM-500Ultra Installation Guide REV B Page 4... - Page 5 Main Module to IF Box Cable 008-01263-00 Console Cable to Main Module 008-01264-00 Camera Cable to Main Module 008-01265-00 Power-Trigger to IF Box Cable 240-00030-00 Wiring Grommet 258-00055-00 Additional Mounting Plate 280-0014 (2) 7.5 Amp Fuses DVM-500Ultra Installation Guide REV B Page 5...
-
Page 6: Cautions & Notes
30-90 minutes. If the Backup Battery does not have a high enough charge at the time of installation, the DVM-500ULTRA system may not turn on correctly the first time. It may be necessary to charge the Backup Battery. -
Page 7: System Diagram
WTM to DVM serial cable (See WTM-555 Input Triggers installation guide) (see page 13) DVM to I/O Box harness Switched Ignition 12V+ Constant 12V+ Ground Voice Vault Wireless Microphone and Charger Assembly with Cigarette Lighter Adapter DVM-500Ultra Installation Guide REV B Page 7... -
Page 8: System Installation
DVM location. For Harley Davidson, the camera and monitor cabling can be run over the fuel tank, underneath the tank bezel. Make sure you allow enough clearance for left & right turns. Secure all cabling neatly with tie wraps. To DVM To Camera DVM-500Ultra Installation Guide REV B Page 8... -
Page 9: Step 3: Install The Waterproof Controller Or Monitor
Make sure you allow enough cable clearance for left & right turns. Secure all cabling neatly with tie wraps to minimize vibration. DB9 connector Interface Box RED=Constant +12Vdc BLACK=Ground DVM-500Ultra Installation Guide REV B Page 9... -
Page 10: Step 4: Attach The Dvm-500Ultra Mount
Route all cabling safely along the frame of the vehicle and to the DVM location. The included wiring grommet can be used for routing system cables inside the saddlebag. Refer to the illustrations below. DVM-500Ultra Installation Guide REV B Page 10... -
Page 11: Step 5: Dvm Connections
DVM connections, attach a tie wrap as shown below. Attach tie wrap here Mount the DVM-500Ultra and Interface Box STEP Attach your DVM to the vehicle and neatly secure all cabling using tie wraps. Examples are illustrated below. -
Page 12: Step 7: Gps Connection
It is highly recommended to install the provided 7.5 Amp fuse and holder on the Red +12V power source wire. Doing so will provide the proper protection for the wiring between the source and the device. DVM-500Ultra Installation Guide REV B Page 12... -
Page 13: Wiring Connections Chart
5 to 10 minutes following installation. The ignition input (Blue wire) MUST be connected to a point where +12V is present only when the ignition is in the ON position. DVM-500Ultra Installation Guide REV B Page 13... -
Page 14: Step 9: Wireless Microphone Charging Cradle
YOUR DVM INSTALLATION IS COMPLETE. TURN ON THE VEHICLE’S IGNITION, INSERT THE CF CARD INTO THE DVM-500ULTRA, AND PRESS THE “MARK” BUTTON ON THE DVM TO POWER ON THE SYSTEM. IF INSTALLING THE OPTIONAL WIRELESS TRANSFER MODULE, CONSULT THE WTM-555 INSTALLATION GUIDE. -
Page 15: Post Installation Checklist
Date of Installation Installer Signature HOW TO RESET THE DVM-500ULTRA SYSTEM Remove power from the Interface (I/O) Box for 30-60 seconds by removing the (2) 7.5 Amp fuses from the side of the small, black I/O Box located in the vehicle (location will vary). The I/O Box, DVM, and the Camera(s) will reset automatically. -
Page 16: Product Repair
DVM, Camera(s), I/O Box, or Remote charging equipment. Remote batteries are user serviceable and can be purchased directly through Digital Ally. Ph: 800-440-4947 or 913-814-7774 Fax: 913-814-7775 Email: support@digitalallyinc.com Website: www.digitalallyinc.com DVM-500Ultra Installation Guide REV B Page 16... - Page 17 The CE Mark is a European marking of conformity indicating that a product complies with the essential requirements of the applicable European laws or Directives with respect to safety, health, environment, and consumer protection. DVM-500Ultra Installation Guide REV B Page 17...
