¿ TABLE OF CONTENT Precaution Application system diagram Standard Definition operation illustration Performance dome parameter camera parameter performance & features Function instruction positions of control system Dimension Functions of remote controller Instruction Pan/Tilt operation camera control Memory settings System setting setting System setting Installation instruction...
Precaution 1. Precaution Electrical Safety Confirm country and local electrical safety standard when using or installing the product The product itself has no power switch Please stop power supply or plug out power socket when it is not in good working Vide o wire and control wire should be insulated and individual connected not mix-up with other wires Transportation with care...
Operation illustration 2. Application system diagram Standard Definition camera operation illustration. for instance as below: Video cable To Video input To VIDEO YPbPr VIDEO YPbPr cable To TV input To HDMI VIDEO To S VIDEO To VISCA RS-232C IN To RS-232C Computer,TV or VCR with a To VISCA IN...
Performance 3. Performance 3.1 Camera parameter Communications Electricity Power supply Baud rate Power consumption Protocol Built in Address setting Decoder Operation Environmental Working Pan rotation environmental temperature Tilt rotation No-condensation Environmental humidity Rotation speed Physical Remote controller 9 Installation Stand-up position Presets Visca protocol 128 net weight...
Performance&Features 3.3 Performance&Features Remark The parameter for each video camera module is different; please refer to the details in Chapter 3.2 Ø System Video signal: PAL color Pixel: 2 mega Minimum distance for imaging: (wide view, the nearest settings under Visca protocol):10mm S/N Ratio: 50 dB Pan/Tilt: Pan 170 , maximum speed:100 /S Tilt:+90 , -30 , maximum speed: 90 /S...
Functions 4. Functions 4.1 positions of control system Lens (may fix wide lens) light of standby light of power Sensor of remote controller. VIDEO YPbPr HDMI IN RS-232C OUT DCIN12V DC 12v Power input interface Video interface Output interface YPbPr interface Input interface HDMI Interface...
Functions 4.2 Dimension Size for High definition video conference camera is as below: POWER STANDBY 131.56 Screw thread Screw thread 1/4-20 UNC, 1/4-20 UNC, 6.5mm 6.5mm...
Functions 4. 3 Functions of remote controller POWER open/close power DATA SCREEN Enter OSD Menu, Continuous press 6 times (Every time must be around 1 second), Restart may make the dome restore factory default. BACK LIGHT press for back light compensation. AUTO press for auto-focus.
Instruction 5. Instruction 5. 1 Pan/Tilt operation 1. Press direction keys to change the direction. If need to change vision angle of camera, please press the right direction key. Press short time for slow moving, press long time for fast moving. 2.
Page 11
Instruction Ø Back light imaging Light behind of the object, which will be black, press back light for compensation. Press again for cancel this function. DATASCREEN BACK LIGHT FOCUS AUTO NEAR MANUAL Far zoom near zoom Ø Change focus Press any button of zoom to realize different zoom. press to near zoom (far view) press to far zoom...
Instruction 5. 3 Memory settings-preset function Can set 9 combinations of presets: position, zoom and back light etc. 1. Confirm standby with no glitter. 2. Adjust camera position, zoom and focus on back light. 3. Keeping press preset key, then press any number 1-9 to save presets. meanwhile, press any number to preset the position...
Menu Setting 6. System setting 1 Operate remote controller, press DATA SCREEN enter MAIN MENU OSD menu; SYSTEM SETTING 2 Press the arrow keys to select the menu, press left and CAMERA SETTING right button to set functions; VIDEO OUT COMM PARA EXIT 6.1 System setting...
Menu Setting 7. CAMERA SETTING MAIN MENU Operate remote controller, Press DATA SCREEN enter SYSTEM SETTING OSD menu, press the arrow keys to move to CAMERA CAMERA SETTING SETTING press right 1button to enter next menu; VIDEO OUT COMM PARA as the left picture EXIT 7.1 CAMERA EXPOSURE SETTING...
Page 15
Menu Setting 7.2 CAMERA COLOR SETTING 1.Operate remote controller, Press DATA SCREEN enter MAIN MENU OSD menu, press the arrow keys to move to CAMERA SETTING press right button to enter next menu; SYSTEM SETTING CAMERA SETTING As the left picture: VIDEO OUT 2.Press arrow keys to move to COLOR...
Page 16
Menu Setting 7.4 CAMERA PICTURE SETTING 1.Operate remote controller, press DATA SCREEN enter MAIN MENU OSD menu, press the arrow keys to move to CAMERA SYSTEM SETTING SETTING press right button to enter next menu; CAMERA SETTING as the left picture VIDEO OUT COMM PARA 2.Press arrow keys to move to...
Page 17
Menu Setting 8. Video output and communication parameters setting 1.Operate remote controller, press DATA SCREEN enter OSD menu, press the arrow keys to move to VIDEO OUT MAIN MENU press right button to enter next menu; As the left picture SYSTEM SETTING CAMERA SETTING FORMAT Video output format including 1080P30...
(see above sketch), use 4pc STP4X16 the video conference camera on the cross screws to fix the upside-down connection board, showed as the installation board of D57 on ceiling sketch 3.Hang the discreteness made in step 4.Use 3pcs M3X5 cross screws to fix...
Maintenance service terms 10. Maintenance service terms 1. Range of warranty The product will be maintained free for one year. The product will be obtained the free maintenance service if the same malfunction appears again within three payable maintenance months. Malfunction of products caused by force majeure (such as war, earthquake, lightning strike and so on ), abuse, non-standard operation, change of construction, non-normal wear or accident are non-free of warranty.
