IF THE TOTAL WATTS OF ELECTRICAL APPLIANCES EXCEEDS
THE OUTPUT CAPACITY OF INVERTER. OR AFTER OPERATING
FOR A PERIOD OF TIME. IF THE TEMPERATURE OF THE
INVERTER REACHES 60 ℃ , THE INVERTER SHALL BE
REDUCED AC OUTPUT BY THE PROTECTION CIRCUIT.
CAUTION
* ALWAYS PLACE THE INVERTER IN
AN ENVIRONMENT WHICH IS :
( A ) WELL VENTILATED
( B ) NOT EXPOSED TO DIRECT
SUNLIGHT OR HEAT SOURCE
( C ) OUT OF REACH FROM CHILDREN
( D ) AWAY FROM WATER/MOISTURE,
OIL OR GREASE
( E ) AWAY FROM ANY FLAMMABLE
SUBSTANCE
※ WARNING ※ FLUORESCENT LAMP
DO NOT USE THIS DEVICE WITH FLUORESCENT LAMPS.
AC IN
Power Factor
Capacitor
0
60 C
.
Glow switch
a
b
Lamp
BALLASTS
8
FULL AUTOMATIC DC-AC 600W
INVERTER & BATTERY CHARGER
DC12V or 24V to AC230V Instruction Manual
POWER
PROTECTION
ON
CHARGER
OFF
Please read user manual before use.
AC OUTPUT
AC
OUTLET
