Summary of Contents for RKM MK802IIIS

  • Page 1 RKM MK802IIIS/MK802 IV User Manual USER MANUAL...
  • Page 2: Table Of Contents

    RKM MK802IIIS/MK802 IV User Manual Table of Contents 1. Connector................................... 2 2. Device connection Instruction............................3 4. Main Screen Introduction..............................5 4.1 Move/Delete desktop icon............................. 5 4.2 Function column..............................6 4.3 Status bar................................. 7 4.4 Application................................8 5. Settings....................................9 5.1 WIFI Setting................................9...
  • Page 3 RKM MK802IIIS/MK802 IV User Manual Declaration  The user manual includes all the information of safe and correct operation instruction. To avoid accident and product damaged, please make sure go through all the content carefully before using the product.  Please keep the product away from high temperature, humid and dusty environment.
  • Page 4: Connector

    Power supply connection: MK802IIIS: Take out Micro USB cable to USB cable and connect the MK802IIIS with the TV’s USB port via this cable; If the TV USB port is unable to provide enough current, please use the USB power supply. (Any...
  • Page 5 RKM MK802IIIS/MK802 IV User Manual USB power supply that can provide 5V/1A to 5V/2A can be used). MK802IV: Take out the USB power supply in the box and connect it with MK802IV via micro USB port. c) All USB Keyboards and Mice can be used however for convenience sake we recommend using a 2.4Ghz wireless keyboard and mouse.
  • Page 6: Main Screen Introduction

    RKM MK802IIIS/MK802 IV User Manual 4. Main Screen Introduction 4.1 Move/Delete desktop icon Long-press any icon in the main menu, you could put it in any position as you like, at the same time you could put the other apps shortcut to the desktop.
  • Page 7: Function Column

    RKM MK802IIIS/MK802 IV User Manual Move your cursor to any space and drag towards left or right for page rolling. Also you can use the mouse wheel for rolling page. 4.2 Function column Return button: click to return to previous directory;...
  • Page 8: Status Bar

    RKM MK802IIIS/MK802 IV User Manual Program tools button: Located in the right top corner of the desktop, click this icon to pop up all the apps which has been installed. 4.3 Status bar Located on the right bottom, display T-Flash Card, USB connection, Time, Wifi and Download status.
  • Page 9: Settings

    RKM MK802IIIS/MK802 IV User Manual Click to access widgets, long press any widgets to form corresponding shortcut on the desktop. 5. Settings In the system user can setup according to their own requirements, such as network connection, language, input methods, Video output resolution, Sound output and check storage space.
  • Page 10: Ethernet Setting

    RKM MK802IIIS/MK802 IV User Manual user just choose a router and input correct password to connected network. 5.2 Ethernet Setting If there is no WIFI in the house, suggest to connect a USB LAN adapter (please select right matched USB LAN adapter) to setting Ethernet.
  • Page 11: Sound

    RKM MK802IIIS/MK802 IV User Manual device and you can copy/paste files freely. 5.7 Sound This is for Sound settings; Volume: Control volume level; Operate prompt tone: Setting prompt tone during operating; Screen saver sound: Setting screen saver sound. 5.8 Display Font size: Setting font size according to their own request;...
  • Page 12: Apps

    RKM MK802IIIS/MK802 IV User Manual 5.11 Apps In this option, user could view installed and running apps, at same time could check DDR parameters. 5.12 Security User can set password according to their request. 5.13 Language & input 1. User can set the language for system menus according to their Country or preference(60 languages supported) 2.
  • Page 13: Install/Uninstall Apps

    RKM MK802IIIS/MK802 IV User Manual Internal Flash: Check internal storage space SD Card: If TF card inside, icon will be highlight USB: If USB device (HDD, U-disk) connected, the icon will be highlight. Network Places: Through this option, user can access to other PC to find files and playback.
  • Page 14: Uninstall Apps

    RKM MK802IIIS/MK802 IV User Manual 7.3 Uninstall Apps Click SettingsApps, click an Apps you want to uninstall, the uninstall window will pop up click uninstall to uninstall. If you don′t want to uninstall just exit. 8. DLNA DLNA : Through some special APP(such as iMedia Share Lite.), all the multimedia files can be pushed from smart phone or Android tablet PC to big screen, user can share those pictures/music/videos with family or friends freely.
  • Page 15 RKM MK802IIIS/MK802 IV User Manual Touch Pad Virtual keyboard Remote control Page14...
  • Page 16: Web Browsing

    RKM MK802IIIS/MK802 IV User Manual 10. Web Browsing After connected network, you can access the webpage screen through the system browser. New opened webpage will be shown on the screen as tag, click “+” to add new webpage, click “x“ to close the webpage.
  • Page 17: Switch Input Methods

    RKM MK802IIIS/MK802 IV User Manual If connect with physical keyboard, system will hidden the virtual keyboard. 13. Switch input methods Click the keyboard icon at the right-bottom status bar from desktop; All the installed methods will display as below picture, and you can choose one of you prefer: 14.
  • Page 18 RKM MK802IIIS/MK802 IV User Manual 3. There is only boot screen; 4. System running very slow, crashing; 5. Can’t find the wireless network equipment, or can’t connect wireless; 6. When installation apps, player loss power unexpected and cant boot up.
  • Page 19 RKM MK802IIIS/MK802 IV User Manual 14.2 Connect the mini pc with computer. 1. Prepare an USB cable (Micro USB to USB cable); insert the normal USB port to computer usb host. 2. Prepare a thin metal stick; press the recover button by the stick according below method.
  • Page 20 RKM MK802IIIS/MK802 IV User Manual Select “next” Choose the options as picture display, then click browse, find out , then click “next” to install. After installation finished, below window will pop out, click “finish”. Page19...
  • Page 21 RKM MK802IIIS/MK802 IV User Manual After finished driver installation,pls refer to step 14.4 to proceed recovery or upgrade. 14.3.2 Install driver on WIN7 system. After connecting the Mini PC to the computer whilst holding the recovery button down, open device manager.
  • Page 22 RKM MK802IIIS/MK802 IV User Manual Press update driver,Click browse for driver software on your computer. And choose the correct driver. If your computer is WIN7 32bit, choose x86--win7; if it is WIN7 64bit, choose x64--win7. Press “next”, below screen will pop out, click ”install” to install.
  • Page 23 RKM MK802IIIS/MK802 IV User Manual Then please wait for installation till below screen appear, that means driver installation finished, press “close”. 14.4 Recovery/Upgrade instruciton After successful installation, the batch tool will connect the mini pc automatically, the “connect device” icon...
  • Page 24 RKM MK802IIIS/MK802 IV User Manual Then Click “upgrade” or “restore” to update/recovery,(recommend “restore”) as below. This procedure will take around 3 minutes, please wait patiently, during recovery/upgrade, don’t remove the USB cable. Page23...
  • Page 25 RKM MK802IIIS/MK802 IV User Manual When this above prompt window appears, then means recovery is successful, pull out USB cable, total process is finished. Notice: 1. Don’t power off during updating or recovering. 2. Same computer just need install driver for one time 3.
