Micro Seven CD 15 Operator's Manual

Caller-id receiver
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
1
OPERATOR'S MANUAL
MICRO SEVEN, Inc. ® ®
MODEL CD15
CALLER-ID RECEIVER
Micro Seven, Inc.
P.O. Box 5597
Beaverton, OR
97006
U.S.A.
phone: 503-693-6982
fax: 503-693-9742
http://www.microseveninc.com
e-mail: support@microseveninc.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CD 15 and is the answer not in the manual?

Questions and answers

Summary of Contents for Micro Seven CD 15

  • Page 1 OPERATOR’S MANUAL MICRO SEVEN, Inc. ® ® MODEL CD15 CALLER-ID RECEIVER Micro Seven, Inc. P.O. Box 5597 Beaverton, OR 97006 U.S.A. phone: 503-693-6982 fax: 503-693-9742 http://www.microseveninc.com e-mail: support@microseveninc.com...
  • Page 2 Copyright, ©2003 by Micro Seven, Inc. All right reserved. Contents of this publication may not be reproduced in any form without the written permission of Micro Seven, Inc. All requests for repairs should be directed to the factory. There will be no warranty when the instrument is misused, or when the factory seal on the instrument is broken.

  • Page 3: Table Of Contents

    CONTENTS SECTION 1 INTRODUCTION SECTION 2 SPECIFICATIONS SECTION 3 OPERATIONS 3.1 AC/DC Adapter and External DC Input Operations 3.2 Front-panel Description 3.3 Rear-Panel Description 3.4 First-time operation and Initialization Procedure 3.5 CD15 Control Register 3.5.1 Bellcore/ETS standard, CD15 Control Register bit 2 position of bit 7-0. 3.5.2 No control character modes, CD15 Control Register bit 1 position of bit 7-0 3.5.3 Telephone number only format, CD15 Control Register bit 0 position of bit 7-0 3.5.4 How to read and write CD15 Control Register...

  • Page 4: Introduction

    INTRODUCTION Micro Seven model CD15, caller-ID receiver receives caller-ID FSK signals on telephone lines, and converts to ASCII signals for outputs at RS232C interface to PC. It provides decoding of caller-ID signals for both Bellcore (American) and ETS (European) standards that are associated with ring signals.

  • Page 5: Specifications

    SECTION 2 SPECIFICATIONS Input signal requirement: Input sensitivity: -13 dBm nominal, -23 dBm minimum Ringer equivalency number: REN=1 Caller-ID compatibility: Caller-ID on-hook delivery associated with ring signal ETS-standard: CD15 Control Register-bit 2 off Bellcore standard: CD15 Control Register-bit 2 on RS232C interface: 9-pin D-sub connector Baud-rate: 1200 Stop bit: 1...
  • Page 6 Warranty/Service: 6 months limited warranty. No warranty if any factory seal is broken. Service is performed at the factory, usually within 5 working days. Micro Seven assumes no liability for loss of property, money, or human lives by application of CD15, caller-ID receivers.

  • Page 7: Operations

    SECTION 3 OPERATION 3.1 AC/DC Adapter and External DC Input Operations The CD15 is operated with AC/DC Adapter or external DC source. The standard AC/DC Adapter for CD15 inputs 117V-AC power. The 230V version of AC/DC Adapter is available as an option.

  • Page 9: First-Time Operation And Initialization Procedure

    3.4 First-time operation and Initialization Procedure Connect AC/DC power adapter to rear panel connector. Connect 9-pin RS232C cable that is provided with CD15. Turn on the power switch of CD15. In Window-type PC, go to Hyperterminal modes. And select as follows: Select 1200 baud, one stop bit, and no parity.

  • Page 10: How To Read And Write Cd15 Control Register

    When the bit 0 of CD15 is on, telephone numbers are output at RS232C interface. 3.5.4 How to read and write CD15 Control Register The CD15 Control Register is written by the following command: M4B(n1)(n2), where n1 and n2 forms a 8-bit bytes. When it is written, CD15 sends "C" to signal that it has been written into the non-volatile memory.

  • Page 11: Character Echo Method From Pc

    When bit 3 among bit 7-0 is on, hardware handshake using RTS/CTS is disabled. The written command is M3D18 to select non-hardware handshake mode and character echo method. 3.6.3 Character echo method from PC When bit 4 of CD15 interface register is on, character (13 decimal) input to CD15 is required to transmit a next character from CD15 to PC.
  • Page 12 SECTION 4 FCC RULES, PART-15 Warning This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instruction manual, may cause interference to radio communications. It has been tested and found to comply with the limits for a Class A computing device pursuant to Sub-part J of Part 15 of FCC Rules, which are designed to provide reasonable protection...
