Industrial 10/100BaseTX to 100BaseFX Media Converter RUE-111 RUE-113 (multimode) (singlemode) User Manual Rev. 2.00 15-September-2006... -
Page 2: Fcc Warning
FCC Warning This Equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 3: Table Of Contents
Contents Introduction............1 Features ..............1 Package Contents............ 2 Hardware Description ......... 3 Physical Dimension..........3 Front Panel............... 3 Bottom View ............. 4 Ports................. 4 Cabling ..............6 LED Indicators............7 DIP-switch ..............8 Wiring the Power Inputs ......... 10 Wiring the Fault Alarm Contact ...... - Page 4 Troubleshooting..........18 Technical Specifications........19...
-
Page 5: Introduction
Introduction The Industrial 10/100BaseTX to 100BaseFX Media Converter is a cost- effective solution for the converting 10/100Base-TX (Auto MDI/MDIX) to 100Base-FX cabling. It provides two power inputs that can be connected simultaneously to two DC power sources. If one power input fails, the other one acts as a backup. -
Page 6: Package Contents
Package Contents Please refer to the package content list below to verify them against the checklist. Industrial 10/100BaseTX to 100BaseFX Media Converter One DIN-Rail (screwed on the converter) One wall mount plate and six screws User manual Industrial 10/100BaseTX to 100BaseFX User Manual Media Converter Wall Mount Plate... -
Page 7: Hardware Description
Hardware Description In this paragraph, we will introduce the Industrial media converter’s hardware spec, port, cabling information, and wiring installation. Physical Dimension Industrial 10/100BaseTX to 100BaseFX Media Converter dimensions (W x H x D) are 54mm x 135mm x 105mm Front Panel The Front Panel of the Industrial 10/100BaseTX to 100BaseFX Media Converter is showed below. -
Page 8: Bottom View
Bottom View The bottom view of the Industrial 10/100BaseTX to 100BaseFX Media Converter consists one terminal block connector within two DC power inputs and one DC IN power jack. Bottom Panel of Industrial 10/100BaseTX to 100BaseFX Media Converter Ports RJ-45 Port The UTP ports will auto-sense for 10Base-T or 100Base-TX connections. - Page 9 [NOTE] “+” and “-” signs represent the polarity of the wires that make up each wire pair. All UTP ports on this Industrial media converter support automatic MDI/MDI-X operation, you can use straight-through cables (See Figure) for all network connections to PCs or servers, or to other switches or hubs. In straight-through cable, pins 1, 2, 3, and 6, at one end of the cable, are connected straight through to pins 1, 2, 3 and 6 at the other end of the cable.
-
Page 10: Cabling
Fiber Port This port is for 100Base-FX connections. We provide SC fiber connector in multi mode (2Km) or single mode (30Km) for different model number. When you connect the fiber port to another fiber port, please follow the below Figure D to connect it. Wrong connection will cause the port cannot work normally. -
Page 11: Led Indicators
long. The Fiber segment using the single-mode connector type must use a 8/125 or 9/125 um single-mode fiber cable. You can connect two devices up to 30 Kilometers (Available on single mode fiber model only). The Fiber segment using a multi-mode connector type must use 50 or 62.5/125 um multi-mode fiber cables. -
Page 12: Dip-Switch
The port is linking with its link Green partner. LNK/ACT The port is transmitting or receiving (Fiber) Blinks packets from the FX device. No device attached The port is operating in full-duplex Orange mode. FDX (Fiber) Half-duplex mode or no device attached Green In 100Mbps transmitting speed... - Page 13 DIP Switch No Status Description Enable Port Alarm. If the port’s link fails, the fault LED will light up. Disable Port Alarm LLF Enable LLF Disable 100Base-FX Half Duplex mode 100Base-FX Full Duplex mode 100Base-TX Full Duplex mode UTP Auto-Negotiation Link Loss Forwarding: When LLF is enabling, allow UTP link failures to be reported to the fiber side and also allow Fiber link failure to be reported to the UTP side.
-
Page 14: Wiring The Power Inputs
Wiring the Power Inputs Please follow below steps to insert the power wire. V- V+ V- V+ 1. Insert the positive and negative wires into the V+ and V- connector on the terminal block connector. 2. Tighten the wire-clamp screws for preventing the DC wires from loosening. -
Page 15: Wiring The Fault Alarm Contact
Wiring the Fault Alarm Contact The fault alarm contact is in the middle of terminal block connector as below figure shows. By inserting the wires and set the DIPswitch at “ON” status, it will detect when power is failure or port link failure and form an open circuit. -
Page 16: Mounting Installation
Mounting Installation DIN-Rail Mounting The DIN-Rail is screwed on converter when out of factory. If the DIN-Rail is not screwed on the converter, please see the following Figure F to screw the DIN-Rail on the converter. Follow the below steps to hang the converter. - Page 17 First, insert the top of DIN-Rail into the track. Then, lightly push the button of DIN-Rail into the track. Check the DIN-Rail is tightly on the track. To remove the converter from the track, reverse step 2 and step1 above.
-
Page 18: Wall Mount Plate Mounting
Wall Mount Plate Mounting Follow the below steps to mount the Industrial media converter with wall mount plate. 1. Remove the DIN-Rail from the Industrial media converter; loose the screws to remove the DIN-Rail. 2. Place the wall mount plate on the bottom side of the Industrial media converter. -
Page 19: Hardware Installation
Hardware Installation In this section, we will describe how to install the 10/100BaseTX to 100BaseFX Media Converter and the installation points for the attention. In Figure, it is an example application for the Industrial converter. Installation Steps 1. Unpacked the Industrial media converter. 2. - Page 20 Mount Plate Mounting section for wall mount plate installation. 3. To insert the Industrial media converter into the track or hang on the wall, please refer to the Mounting Installation section. 4. Power on the Industrial media converter. How to wire the power; please refer to the Wiring the Power Inputs section.
- Page 21 connected. Please refer to the LED Indicators section for LED light meaning. 8. When all connections are all set and LED lights all show in normal, the installation is complete.
-
Page 22: Troubleshooting
Troubleshooting Verify that you are using the right power cord/adapter (DC 12-48V). Do not use a power adapter with DC output larger than 48V, or it will damage the device. Check the configuration of the DIP-switch. It must be sett in the same operation mode with the link partner. -
Page 23: Technical Specifications
Technical Specifications Industrial 10/100BaseTX to 100BaseFX Media Converter technical specification are following. IEEE802.3 10BASE-T Standard IEEE802.3u 100BASE-TX/100BASE-FX IEEE802.3x Flow Control and Back pressure Fiber: SC (Multi-Mode model), SC (Single-mode model, 30Km) Connector RJ-45 Socket: CAT-3/5 (10/100Mbps) Twisted Pair cable Auto MDI/MDI-X and Auto-Negotiation Function Support Switch Store and Forward... - Page 24 Fiber: If TX port link down, the media converter will force Fiber port to link down Link Lost Forward Fiber TX: If Fiber port link down, the media converter will force TX port to link down. DIP Switch 1: ON: Enables Port Alarm OFF: Disables Port Alarm DIP Switch 2: ON: Enables LLF (Link Lose Forwarding)
- Page 25 Overload current Present protection Operation 0 to 60°C (32 to 140°F) Temperature Storage -40 to 85°C Temperature Ambient Relative 5 to 90%(non-condensing) Humidity Dimension 54 mm (W) x 135 mm (H) x 105mm (D) FCC Class A, CE EN6100-4-2, CE EN6100-4-3, CE EN-6100-4-4, CE EN6100-4-5, CE EN6100-4-6 Safety...
