R e v i s i o n 1 . 0 ( 1 5
h
Ma y 2 0 1 4 )

Advertisement

loading
Need help?

Need help?

Do you have a question about the SPARTACUS Y6 and is the answer not in the manual?

Questions and answers

Summary of Contents for AerialFreaks SPARTACUS Y6

  • Page 1 R e v i s i o n 1 . 0 ( 1 5 Ma y 2 0 1 4 )
  • Page 2 SPARTACUS Y6 Manufactured from high quality CNC aluminum and high performance carbon fiber, our design is both strong and light the complete frame weights only 478 grams. The motor arms and landing gear fold for easy transport. Our Y6 is particularly suited to aerial photograph, surveillance, remote sensing, mapping, airborne reconnaissance, fire observation, cable line patrol, construction monitoring, farm monitoring, and other high performance requirements.
  • Page 3 SPARTACUS Y6 Carbon tube 16x326.75mm Y6_015 Socket head cap screw M3x28mm Y6_026 Motor mount upper and lower Y6_012 Tube lock ring Y6_035 CF head motor Motor bolt supplied mount with motors Y6_011 Boom lock Y6_018 Nylon Nut M3 Y6_027 Motor...
  • Page 4 SPARTACUS Y6 Boom clamp_1 Y6_004 Carbon tube fixed sets 1 Y6_019 Button head cap screw M3x5mm Y6_030 Boom clamp_2 Y6_005 Button head cap screw M3x5mm Y6_030 Button head cap screw M3x8mm Y6_038 Socket head cap screw Note: Apply a light M2.5 x 20mm...
  • Page 5 SPARTACUS Y6 Rubber Shoulder socket screw M2.5x28 washer Y6_036 Socket head cap screw M3x28mm main Y6_026 Column 22mm Y6_021 Y6_007 Special screw M2.5x8mm Aluminum damping Y6_025 bracket Y6_001 CF main frame Y6_008 Carbon tube fixed sets 2 Y6_020 Aluminum pipe clamps...
  • Page 6 SPARTACUS Y6 Flat screw M2.5x5mm Y6_028 Battery tray Y6_009 Gimbal mount Y6_024 Carbo tube 10x220mm NOTE: Y6_016 After unscrewing the three CNC Boom Clamps (Y6_002) from the landing gear they can be folded up. The two movable booms can be un-clipped and folded for transport.

  • Page 7: Spare Parts List

    SPARTACUS Y6 SPARE PARTS LIST Aluminum damping Boom Clamp_4 Boom Clamp_3 AT_Bulon M8 bracket Boom Clamp_1 Boom Clamp_2 Column 25mm Column 22mm Y6_002 Y6_003 AT_001 Y6_001 Y6_004 Y6_005 Y6_006 Y6_007 Carbon tube CF Motor mount AT_Nut M8 Power Board CF main frame...
  • Page 8 w w w . a e r i a l f r e a k s . c o m...
