Summary of Contents for Alees Rush 750

Page 1 Revision 1...
Page 2: Warranty & Safety
Neither AleeS Inc nor its affiliated groups or sellers have any control over the assembly, maintenance, and use of this product. Therefore, no responsibility can be traced back to the manufacturer. By assembling and flying this product, you hereby agree to release AleeS Inc., its Distributors, Dealers, and Affiliates from any responsibility or liability arising from the use of this product.
Page 3: Mechanical Features
- 23T CNC counter gear modulus 1; - 24T bevel gears modulus 1; - AleeS all-new, industry's first "TDD" Drive System (patent pending; more details to come); - Field replaceable bevel and counter gears; - Dual ball bearing supported one-way hub assembly with sprag style clutch bearing;...
Page 5 (Part # 102-0003) ... QTY 1 Cap Screw Shouldered M4 x 22mm ..x1 Use thread lock compound on all screws noted by Color: Lock Nut M4 Blue = Medium - Red = Strong ..x1 Copyright 2014 AleeS Inc. All rights reserved.
Page 6 Use thread lock compound on all screws noted by Color: Blue = Medium - Red = Strong Grooves are Apply Bearing Grease! inside Small notch notes left hand thread end Thrust Bearing 10x18x5.5mm (F10-18M) Copyright 2014 AleeS Inc. All rights reserved.
Page 7: Swash Plate
Color: Blue = Medium - Red = Strong Linkage Ball Long M3 (Part # 100-0010 ..QTY 4 AR Ball x2 -- Lower Cup (Part # 101-0013) ... QTY 1 x2 -- Upper Cup Copyright 2014 AleeS Inc. All rights reserved.
Page 8: Battery Tray
CF Battery Tray Matte Finish (Part # 202-0044) ...QTY 1 Use thread lock compound on all screws noted by Color: Blue = Medium - Red = Strong Set Screw M3 x 12mm ..x7 Copyright 2014 AleeS Inc. All rights reserved...
Page 9: Tray Assemblies
CF Gyro Tray Matte Finish (Part # 202-0054) ...QTY 1 Use thread lock compound on all screws noted by Color: Button Head Screw M3 x 6mm Blue = Medium - Red = Strong ..x10 Copyright 2014 AleeS Inc. All rights reserved.
Page 10: Bearing Assemblies
Bearing Block (Part # 200-0003) ... QTY 1 ..x1 Use thread lock compound on all screws noted by Color: Button Head Screw M3 x 6mm Blue = Medium - Red = Strong ..x8 Copyright 2014 AleeS Inc. All rights reserved.
Page 11 Bearing Spacer (Part # 300-0022) ..QTY 1 Use thread lock compound on all screws noted by Color: Blue = Medium - Red = Strong Counter Shaft Bearing Bottom Mount (Part # 200-0059-B) ...QTY 1 Copyright 2014 AleeS Inc. All rights reserved.
Page 12 Button Head Screw Pin M3 x 4.5mm ..x2 Button Head Screw M3 x 6mm Use thread lock compound on all ..x4 screws noted by Color: Blue = Medium - Red = Strong Cap Screw M3 x 8mm ..x2 Copyright 2014 AleeS Inc. All rights reserved.
Page 13: Frame Assembly
(Part # CS3X10) ...QTY 4 Cap Screw M3 x 8mm Use thread lock compound on all ..x3 screws noted by Color: Blue = Medium - Red = Strong Cap Screw M3 x 10mm ..x4 Copyright 2014 AleeS Inc. All rights reserved.
Page 14 Button Head Screw M3 x 6mm ..x1 Cap Screw M3 x 6mm ..x7 Use thread lock compound on all screws noted by Color: Blue = Medium - Red = Strong Cap Screw M3 x 8mm ..x1 Copyright 2014 AleeS Inc. All rights reserved...
Page 15 Button Head Screw M3 x 6mm ..x1 Cap Screw M3 x 6mm ..x1 Use thread lock compound on all screws noted by Color: Cap Screw M3 x 8mm Blue = Medium - Red = Strong ..x1 Copyright 2014 AleeS Inc. All rights reserved...
Page 16 Cap Screw M4 x 8mm apply thread lock to screws. Temporarily install Use thread lock compound on all ..x4 screws noted by Color: Blue = Medium - Red = Strong Set Screw M4 x 4mm ..x2 Copyright 2014 AleeS Inc. All rights reserved.
Page 17 Cap Screw M3 x 8mm (Part # CS3X8) ...QTY 10 Use thread lock compound on all screws noted by Color: Blue = Medium - Red = Strong Cap Screw M3 x 8mm ..x10 Copyright 2014 AleeS Inc. All rights reserved.
Page 18 ...QTY 4 CF Left Frame Matte Finish (Part # 202-0042) ...QTY 1 Use thread lock compound on all screws noted by Color: Blue = Medium - Red = Strong Special Phillips Screw ..x 4 Copyright 2014 AleeS Inc. All rights reserved...
Page 19 (Part # CS3X8) ...QTY 6 Center Washer (Part # 200-0023) ...QTY 4 Use thread lock compound on all screws noted by Color: Blue = Medium - Red = Strong Cap Screw M3 x 6mm ..x6 Copyright 2014 AleeS Inc. All rights reserved.
Page 20 (Part # 200-0023) ...QTY 5 Cap Screw M3 x 6mm Use thread lock compound on all ..x 2 screws noted by Color: Blue = Medium - Red = Strong Cap Screw M3 x 8mm ..x 9 Copyright 2014 AleeS Inc. All rights reserved.
Page 21 Button Head Screw M3 x 6mm ..x2 Cap Screw M3 x 8mm Use thread lock compound on all ..x10 screws noted by Color: Blue = Medium - Red = Strong Cap Screw M3 x 10mm ..x4 Copyright 2014 AleeS Inc. All rights reserved...
Page 22 CF Base Tray Matte Finish Blue (Part # 202-0045) ...QTY 1 Use thread lock compound on all screws noted by Color: Blue = Medium - Red = Strong Button Head Screw M3 x 6mm ..x4 Copyright 2014 AleeS Inc. All rights reserved...
Page 23 CF Skid Plate Matte Finish (Part # 202-0048) ...QTY 2 Use thread lock compound on all screws noted by Color: Blue = Medium - Red = Strong Button Head Screw M3 x 10mm ..x8 Copyright 2014 AleeS Inc. All rights reserved.
Page 24 Cap Screw M3 x 8mm (Part # CS3X8) ...QTY 4 Use thread lock compound on all screws noted by Color: Blue = Medium - Red = Strong Cap Screw M3 x 8mm ..x 4 Copyright 2014 AleeS Inc. All rights reserved.
Page 25: Servo Installation
Tail servo output shaft to be located closest to Boom Mount Use thread lock compound on all screws noted by Color: Blue = Medium - Red = Strong Copyright 2014 AleeS Inc. All rights reserved.
Page 26: Main Drive Assembly
Button Head Screw M3 x 6mm ..x12 Button Head Screw M3 x 8mm ..x6 Clutch Bearing Use thread lock compound on all screws noted by Color: Blue = Medium - Red = Strong ..x1 Copyright 2014 AleeS Inc. All rights reserved.
Page 27: Head Installation
Shaft Retainer (Part # 200-0024) ... QTY 1 Aileron Linkage Rod M2.5 x 31mm Measurement Elevator Linkage Rod M2.5 x 42mm Measurement 58.25 mm (Approx.) 46.5 mm (Approx.) 12.5 mm (Approx.) 24.25 mm (Approx.) Copyright 2014 AleeS Inc. All rights reserved.
Page 28 ..x4 Button Head Screw M3 x 10mm ..x2 Ball Bearing 12 x 18 x 4mm ..x2 Use thread lock compound on all screws noted by Color: Blue = Medium - Red = Strong Copyright 2014 AleeS Inc. All rights reserved.
Page 29 Cap Screw M2.5 x 6mm ..x4 Cap Screw M2.5 x 6mm (Part # CS2.5X6) ... QTY 2 Use thread lock compound on all screws noted by Color: Blue = Medium - Red = Strong Copyright 2014 AleeS Inc. All rights reserved.
Page 30 90 degree relative to Arm Support. Allowing a Use thread lock compound on all preset hover pitch value to screws noted by Color: approx 8 degree Blue = Medium - Red = Strong Copyright 2014 AleeS Inc. All rights reserved.
Page 31 Screws once in place after install onto Boom then tighten until Rod guide will no longer move (do not over tighten) Use thread lock compound on all screws noted by Color: Blue = Medium - Red = Strong Copyright 2014 AleeS Inc. All rights reserved.
Page 32 Use thread lock compound on all screws noted by Color: Blue = Medium - Red = Strong Bearing Support (Part # ... QTY 4 300-0019 TT Shaft Spline (Part # ... QTY 2 300-0028 Copyright 2014 AleeS Inc. All rights reserved.
Page 34 Leave all rod guide screws loose for easy installation and setup. Tightening screws will be covered at a later point in instructions. Use thread lock compound on all screws noted by Color: Blue = Medium - Red = Strong Copyright 2014 AleeS Inc. All rights reserved.
Page 35 M3 x 4.5mm (Part # SP3X4.5) ... QTY 2 Remove from Temporary install and apply Thread Lock Compound. Use thread lock compound on all screws noted by Color: Blue = Medium - Red = Strong Copyright 2014 AleeS Inc. All rights reserved.
Page 36 (Part # W3X8X1) ... QTY 2 CF Tail Fin Matte Finish (Part # 202-0051) ... QTY 1 Use thread lock compound on all screws noted by Color: Blue = Medium - Red = Strong Copyright 2014 AleeS Inc. All rights reserved.
Page 37 Flat Washer M4 x 10 x 1mm ..x4 Cap Screw M4 x 12mm ..x2 Use thread lock compound on all screws noted by Color: Cap Screw M4 x 16mm Blue = Medium - Red = Strong ..x2 Copyright 2014 AleeS Inc. All rights reserved.
Page 38: Rotor Blades
(Not Included) Lock Nut M3 ..x2 Lock Nut M5 Foam Blade Holder Red (Part # 800-0001) ... QTY 1 ..x2 Cap Screw Shouldered M3 x 18mm ..x2 Cap Screw Shouldered M5 x 31mm ..x2 Copyright 2014 AleeS Inc. All rights reserved.
Page 39: Electronics Placement
Electronics Placement Gyro Gyro Controller, BEC Main Batteries 12s-14s Diagrams display optional electronics placement areas Gyro Gyro Controller, BEC Main Batteries 12s-14s Copyright 2014 AleeS Inc. All rights reserved.
