1
Connect Antennas
2
Connect WAN (Internet) Cable
FOR DSL WAN UPLINK:
Connect the DSL Cable to the "DSL" port.*
FOR NON-DSL WAN UPLINK:
Connect the Ethernet Cable to the "Omni" port.
* ONLY USE CABLES AND FILTERS PROVIDED BY YOUR ISP
3
Connect LAN Devices
Ethernet ports are ideal for Gaming Consoles and TV Devices.
Only connect ISP provided equipment to ports labeled "IPTV"
4
Connect Power Supply
Only use the provided 12VDC / 1.5A power supply.
Always use a surge protector.
M625N Installation Guide
Advertisement
Related Manuals for VisionNet M625N
Summary of Contents for VisionNet M625N
- Page 1 M625N Installation Guide Connect Antennas Connect WAN (Internet) Cable FOR DSL WAN UPLINK: Connect the DSL Cable to the “DSL” port.* FOR NON-DSL WAN UPLINK: Connect the Ethernet Cable to the “Omni” port. * ONLY USE CABLES AND FILTERS PROVIDED BY YOUR ISP Connect LAN Devices Ethernet ports are ideal for Gaming Consoles and TV Devices.
- Page 2 When Prompted: Enter the Network Security Key Security Key matches the Bottom Label Serial Number IF YOU EXPERIENCE INTERMITTENT WIFI ISSUES: Press the “WiFi Channel” button on the top of the M625N Wait 60 seconds. The M625N will select a new WiFi channel Attempt to reconnect...
