Summary of Contents for DVO Emerald DH

  • Page 2 Register Your Product Log on to www.dvosuspension.com and click Register. DVO Suspension wants you to achieve the highest level of performance out of your suspension. Let us know which products you have so we can keep you updated with the latest set up and tuning information.
  • Page 3 VOIDS the warranty of your fork.  DVO Suspension forks are designed for the usage by a single rider only. DO NOT use DVO Suspension products on any motorized bicycle, motorized vehicle or tandem bicycles. ...

  • Page 4: Intended Use

    INTENDED USE WARNING! DVO Emerald DH fork is designed for Downhill use ONLY. Any other use of the suspension could result in fork failure and an accident. BEFORE EACH RIDE WARNING!  Do not ride your bicycle, if any one of the following test criteria is not passed! Riding your bike without eliminating any defect or carrying out the necessary adjustments can result in an accident, serious injury or even death.

  • Page 5: Fork Installation

    INSTALLATION INSTRUCTIONS WARNING! All DVO Suspension forks come with a threadless steer tube. Do not add a thread to it! DVO Suspension fork steer tubes are for one-time press fit only which cannot be removed. Do not try to replace the steer tube with a threaded steer tube. This will void the warranty of your fork and result in a failure of the product or cause serious injuries or even death to the rider.

  • Page 6: Tire Clearance

    7 N.m / 62 in.lbf. TIRE CLEARANCE DVO Suspension forks are designed around both 26” and 27.5” tires; make sure you have the correct wheel size for your fork model. Each tire and manufacturer has a different outer diameter (tire width and height).
  • Page 7 FORK CONTROLS and ADJUSTMENTS AIR SPRING The DVO Suspension Emerald DH is an air sprung fork. Increasing air pressure will create a stiffer feeling fork. Decreasing air pressure will create a softer feeling fork. Please refer to the air pressure...

  • Page 8: Maintenance

    WARNING! Failure to properly maintain your fork will result in an accident, personal injury or death. We recommend all DVO Suspension service should be performed by a qualified bicycle mechanic. Service information and instructions can be obtained at www.dvosuspension.com or by contacting your local DVO Suspension dealer or distributor.
  • Page 9 Recommended Maintenance Schedule Maintenance Interval Clean Stanchion Tubes Every ride Check Air Pressure Every ride Inspect Stanchion Tube for Scratches Every ride Check Torque Settings 25 hours Service Air Spring 100 hours Service Damper Unit 100 hours Recommended Max Torque Specifications Part Torque Specification Top Crown...
  • Page 10 Limited Two Year Warranty (the “Agreement”), the defective component will be repaired or replaced, at the option of DVO Suspension free of charge, within thirty (30) days after receipt of the Suspension product by an authorized DVO Suspension dealer, freight prepaid, together with the original retail invoice or other evidence of the date of purchase.
