USER'S INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVR82-ENG-V.2 H.264 and is the answer not in the manual?

Questions and answers

Summary of Contents for Xtreme DVR82-ENG-V.2 H.264

  • Page 1 USER’S INSTRUCTIONS...

  • Page 3: Table Of Contents

    Contents CONTENTS ABOUT THIS MANUAL ..........................6 1.UNPACKING ............................DVR (D ..............TAND ALONE IGITAL IDEO ECORDER 2.FEATURES .............................. 8 3.WHAT TO DO AT THE TIME OF INSTALLATION ..................9 4.SPECIFICATIONS ..........................5.HDD FIRST INSTALLATION ........................5-1. H DVR ..................OW TO NSTALL THE 5-2.
  • Page 4 Instruction Manual Stand-alone DVR 7-4. P ........................OWER 7-4.1. POWER ON ..........................7-4.2. POWER OFF ..........................7-5. M ........................INDOW 7-6. D ........................ISPLAY CREEN 7-6.1. FULL SCREEN ........................... 7-6.2. SPLIT SCREENS ........................7-7. LIVE ............................ 7-7.1. FULL SCREEN ........................... 7-7.2.
  • Page 5 7-10.2.4. Disappearance of Replay control buttons ................7-11. COPY ..........................7-11.1. Copying devices ........................7-11.2. Set the Copy Start Time (Copying extent) ................. 7-11.3. Set the Copy End Time (Copying extent) .................. 7-11.4. Copying the recorded data during replaying ................7-12.
  • Page 6 Instruction Manual Stand-alone DVR 8-6. RECORD ..........................8-6.1. Record ICON Display ........................8-6.2. All Manual / Timer recording button ..................... 94 8-6.3. All Motion ON / OFF, Sensitivity Setting ..................94 8-6.4. All Sensors ON / OFF........................95 8-6.5. Size (Recording Resolution) ....................... 96 8-6.6.
  • Page 7 9-4.4. REPLAY ............................ 124 9-4.5. COPY ............................9-4.6. Speaker / Microphone ....................... 9-4.7. Access mode………………………………………………………………………………….129 9-4.8 E-Map………………………………………………………………………………………….130 9-5. PLAYER ..........................10.INSTALLATION OF ADDITIONAL HDDS ................... 10-1. HDD (H ) INSTALLATION ................ 141 RIVE 10-2. I HDD ................142 NSTALLATION OF AN ADDITIONAL APPENDIX ..............................

  • Page 8: About This Manual

    About this manual This Manual describes how to install and operate the Stand-Alone DVR and provides specifications and features. Please read this manual thoroughly and follow the installation process before using Stand-alone DVR (Note: Be sure to correctly follow step 3. What to do at the time of installation). Contact our dealers when you have any queries.

  • Page 9: Stand-Alone Dvr (Digital Video Recorder) Unit

    Stand-alone DVR (Digital Video Recorder) Unit DVR82XX is the most reliable and functional embedded DVR system available today. The system displays 16 channels of live images in Real Time speed, compresses data digitally and records them to the Hard Disk Drive, which can be replayed and searched easily any time. The DVR82XX supports easy back up via USB port, DVD R/W, CD R/W and networking in both static &...

  • Page 10: Features

    Features ▶ Multi Functional Record -Powerful, multiple Record Modes available: Manual (Continuous), Timer, and Motion Detection Recording. ▶ User friendly GUI -A few simple buttons for Easy control. ▶ Automatic System Recovery -Automatic and Complete System recovery within 10 seconds. ▶Easy PTZ control via RS port -No need to use PTZ controller -PTZ control from remote PC...

  • Page 11: What To Do At The Time Of Installation

    What to do at the time of Install ation Stand-alone DVR should be installed in the following order; 1. Make sure all the required hardware is available. Stand-alone DVR unit (including HDD) Up to 16 cameras (including power source) CCTV or VGA monitor (or TV set) Network cable if connecting to a PC 2.

  • Page 12: Specifications

    Specifications ITEM D ES CRIPTION VIDE O SIGNAL Tele visio n System NTSC PA L VIDE O FE ATU RES Live (Re a l tim e d isp la y) 4 8 0 f/ s d isp la y wit h 16 c h 4 00 f / s d ispla y w ith 1 6 ch Zo o m 2 t im es d igi ta l...

  • Page 13: Hdd First Installation

    HDD First Installation 5-1. How to Install the HDD to DVR Set up the jumper of HDD as a “Master”. (Refer to the instruction of how to set up to jumper from the top part of HDD.) Connect the primary slot of HDD cable (IDE cable) and power cable to HDD. If the connection is done, connect the power adaptor to turn on the power.

  • Page 14: Firmware Upgrade

    Instruction Manual Stand-alone DVR 5-3. Firmware Upgrade When Formatting the HDD is done, the following screen shows up for the firmware upgrade. Firmware upgrade There are two ways to upgrade the firmware 1) Firmware upgrade thru the host viewer. If you choose “NETWORK CONFIG”, the network configuration window shows up. [NETWORK CONFIG] Button NETWORK window...
  • Page 15 5. HDD First Installation Before you connect the DVR from host viewer, you need to set up the network of DVR first. For the instruction of network setup or host viewer, refer to the user manual of DVR in the If the network setup is done, execute the host viewer in PC and try to connect to the DVR.
  • Page 16 Instruction Manual Stand-alone DVR Press the “Firmware update” button on “Config Dialog” window. Config Dialog [Firmware Update] If you see the message window saying “Do you want to update a firmware?”, Press “Yes” button.
  • Page 17 5. HDD First Installation From the following window, select the folder where the firmware is located and press “Open” button. If you see the message window saying “Shall I update firmware?”, press OK button.
  • Page 18 Instruction Manual Stand-alone DVR Then, the downloading the installing the firmware would be started. If the installation is done, reboot the system.
  • Page 19 5. HDD First Installation 2) Firmware upgrade thru “USB/CD-RW/DVD”. Copy the firmware in USB, CDRW or DVD. Connect the any media(USB,CD-RW/DVD)where the firmware is contained to DVR, Then choose “USB/CDRW/DVD” menu from the screen of DVR. If the firmware in the media is detected, it shows the name of firmware in the button.
  • Page 20 Instruction Manual Stand-alone DVR If you press the “[Firmware Update]” button, The firmware upgrade is proceeded, then reboot the system when the firmware upgrade is done.

  • Page 21: Installation

    Installation 6-1. Controls and Connectors (For 4ch, 8Ch & 16Ch DVR) 6-1-1: Front Panel 1 Channel(FULL Screen) 2 Channel(FULL Screen), UP Key 3 Channel(FULL Screen) 4 Channel(FULL Screen) 5 Channel(FULL Screen), LEFT Key 6 Channel(FULL Screen), ENTER Key 7 Channel(FULL Screen), RIGHT Key 8 Channel(FULL Screen) 9 Channel(FULL Screen) 10 Channel(FULL Screen), DOWN Key...
  • Page 22 Instruction Manual Stand-alone DVR a. Display (Full / Split) b. Emergency Record c. Zoom d. Quick Replay e. OSD On/Off Audio g. Stop (ESC) h. PTZ 6-1-2: Rear Pan...

  • Page 23: Note For Installation

    6. Installation 6-2. Note for Installation Install the system according to the instructions described in this manual. This product is designed for indoor use and should not be used outdoors. Avoid any area with high humidity or dust which can shorten lifetime of the unit. Choose a well ventilated area and keep minimum of 10”...

  • Page 24: System Connection

    Instruction Manual Stand-alone DVR 6-3. System Connection [Fig 6-3. System Connection]...

  • Page 25: Installation

    6. Installation 6-4. Installation 6-4.1. Camera Connection ▫ Connection of Normal Cameras Connect the cameras to the Video Input (BNC connector) on the back of the unit as shown above [Fig. 6-3 System Connection]. ▫ Connection of Loop Output The Camera or video output is available from the Video Output (Loop Output) on the back of the unit.

  • Page 26: 6-4.3. Monitor Connection

    Instruction Manual Stand-alone DVR 6-4.3. Monitor Connection ▫ Connection of Main Monitor Connect the composite monitor to "Main" on the upper part of BNC connector ▫ Connection of Auxiliary Monitor Connect the auxiliary monitor to "Aux" on the lower part of BNC connector. The output of auxiliary monitor port is the same as the main monitor.

  • Page 27: 6-4.4. Sensor Connection And Relay In &Out

    6. Installation 6-4.4. Sensor Connection and RELAY IN &OUT ▫ SENSOR Connection (SENSOR IN) Connect the sensor to ALM (SENSOR) IN. The Sensor should be a contactor type and support NO (Normal Open). Refer to for connection. [Fig. 6-6 SENSOR IN/OUT PIN] [Fig 6-6.
  • Page 28 Instruction Manual Stand-alone DVR 6-4.5.PAN/TILT Connection ▫ Connect the cable to the “RS232C PORT” on the rear of the unit. Specification of the RS232C connector is standard for “DSUB9” The Maximum Length of cable is 45 ft. When you want to use a longer distance, use “RS323 to RS422”...

  • Page 29: 6-4.6 Connection To An Ethernet (Optional) Network

    6. Installation 6-4.6 Connection to an Ethernet (Optional) Network ▫ Connecting the cable to Ethernet. Our Ethernet connector is a RJ45 type. The maximum cable length is 300 ft. When you want to use a longer cable, we suggest using repeater. Refer to for connector pin configuration.

  • Page 30: 6-4.7. Power Connection

    Instruction Manual Stand-alone DVR 6-4.7. POWER CONNECTION Select proper voltage (see fig 6-12) and connect to a reliable power source. It should not be shared with other electrical equipment on the same line. Poor performance can occur if the connected voltage is more than 10% plus or minus the required voltage.

  • Page 31: How To Operate

    How to operate 7-1. General Information ▫ You can operate all functions of the system by use of the 28 buttons located on the front panel, remote controller and a mouse. Additionally, you can remotely control this unit via RS422C or the Ethernet port located on the back of the unit. ▫...

  • Page 32: Ir Remote Controller

    Instruction Manual Stand-alone DVR 7-3. IR Remote Controller 1. RECORD 2. QUICK REPLAY 3. ZOOM 4. SEARCH FOR REPALYING 5. UP 6. RIGH 7. DOWN 8. SYSTEM STATUS 9. OSD ON/OFF OSD 10. POWER ON/OFF 11. DISPLAY FORMAT (SPLIT) 12. MENU (SETUP) 13.

  • Page 33: Power On/Off

    7. How to Operate 7-4. Power On/Off 7-4.1. POWER ON On the front panel or the remote controller: Press the POWER button on the front panel for approx. 3 seconds until the LED lights are turned on or just press the POWER button on the remote controller. 7-4.2.

  • Page 34: Menu Window

    Instruction Manual Stand-alone DVR 7-5. Menu Window Right-click on the screen in the LIVE or the RECORD mode and the MENU window will be appeared. Click the (EXIT) button to return to the LIVE Mode. CLICK CLICK [Fig.7-4 Main window]...

  • Page 35: Display Screen

    7. How to Operate 7-6. Display Screen 7-6.1. FULL SCREEN...

  • Page 36: 7-6.2. Split Screens

    Instruction Manual Stand-alone DVR 7-6.2. SPLIT SCREENS FULL SCREEN SEQUENCING SCREEN [4B] QUAD SCREEN [4A] QUAD SCREEN [4D] QUAD SCREEN [4C] QUAD SCREEN...
  • Page 37 7. How to Operate [6] QUAD SCREEN [8] SCREEN [16] SCREEN [9] SCREEN...

  • Page 38: Live

    Instruction Manual Stand-alone DVR 7-7. LIVE 7-7.1. FULL SCREEN ▫ Full SCREEN is available in the LIVE mode or the RECORD mode. ▫ Click on a certain camera’s screen in the LIVE mode or in the RECORD mode, and a FULL SCREEN will be displayed.

  • Page 39: 7-7.3. Sequencing Screens

    7. How to Operate 7-7.3. SEQUENCING SCREENS ▫ Displaying the cameras in SEQUENCE is available in the LIVE mode or the RECORD mode. Each of the channels will be displayed in sequence and the dwell time can be adjusted in the camera set up menu (Refer to 8-4.7). ▫...

  • Page 40: 7-7.4. Live Audio

    Instruction Manual Stand-alone DVR 7-7.4. LIVE AUDIO ▫ Set-up LIVE AUDIO is available in the OSD ON mode and the system is not connected through the DvrViewer(Client Host Program or Internet Explorer). ▫ If cameras (up to 16 cameras) have audio function, it will sound in the live mode. ▫...
  • Page 41 7. How to Operate...

  • Page 42: 7-7.5. Zoom

    Instruction Manual Stand-alone DVR 7-7.5. ZOOM The image on the screen will be zoomed up to 2 times when the ZOOM button is clicked in the LIVE mode (This function is available on the full screen mode only). ▫ Click the ZOOM button on the MENU window in the LIVE mode. ▫...

  • Page 43: 7-7.6. Osd On / Off

    7. How to Operate 7-7.6. OSD ON / OFF OSD ON /OFF is possible in the LIVE mode or RECORD mode. ▫ Click the OSD button on the MENU window to turn the OSD (On Screen Display) ON or OFF. When the OSD is in OFF position, all the texts on the screen will be disappeared. CAM04 CAM03 CAM05...

  • Page 44: 7-7.7. Pan / Tilt

    Instruction Manual Stand-alone DVR 7-7.7. PAN / TILT ▫ Click the PAN/TILT button on the MENU window in the LIVE mode to access the PAN/TILT cameras. ▫ Click the (EXIT) button to return to the MENU window. [Fig.7-14 PAN/TILT button] [Fig.7-15 PAN/TILT window]...
  • Page 45 7. How to Operate [Fig.7-16 PAN/TILT CONTROL window] ▫ Channel Selection and Screen Conversion To change a channel, press the CHANNEL button on the front panel or click the CHANNEL It will be converted a full screen. button on the [Fig.7-16 PAN /TILT CONTROL window].

  • Page 46: 7-7.8. System Status

    Instruction Manual Stand-alone DVR 7-7.8. SYSTEM STATUS ▫ Click the SYSTEM STATUS button on the MENU window to see the system status as shown below (Fig.7-17). ▫ Click the (EXIT) button to return to the MENU window. [Fig.7-17 SYSTEM STATUS button] [Fig.7-18 SYSTEM STATUS window]...

  • Page 47: 7-7.9. Power Loss Lists

    7. How to Operate 7-7.9. POWER LOSS LISTS The list indicates the time/date when the system power is turned OFF. ▫ Click the POWER LOSS LISTS button on the SYSTEM STATUS window to view the POWER LOSS LISTS. ▫ Each of the pages contains 10 lists. You can search the pages by clicking the UP/DOWN button.
  • Page 48 Instruction Manual Stand-alone DVR ▫ CLEAR LISTS button Click the CLEAR LISTS button to clear the lists, you will be prompted to confirm changes. When you click the OK button, the POWER LOSS LISTS will be deleted. To cancel, click the CANCEL button [Fig.7-20 POWER LOSS LISTS Message]...

  • Page 49: 7-7.10. Video Loss List

    7. How to Operate 7-7.10. VIDEO LOSS LIST The list indicates the video loss channel and the time/date when the video signal is disconnected. ▫ Click the VIDEO LOSS LISTS button on the SYSTEM STATUS window to view the VIDEO LOSS LISTS.
  • Page 50 Instruction Manual Stand-alone DVR ▫ CLEAR LISTS button Click the CLEAR LISTS button to clear the lists, you will be prompted to confirm changes. When you click the OK button, the VIDEO LOSS LISTS will be deleted. To cancel, click the CANCEL button [Fig.7-23 VIDEO LOSS LISTS Message window]...

  • Page 51: Video Enhance

    7. How to Operate 7-8. VIDEO ENHANCE ▫ Click the DISPLAY button in the MENU window to control to Contrast / Brightness of Each Camera Input or Control to Contrast / Brightness / Saturation of VGA Output. The VIDEO ENHANCE menu will show up (See Fig.7-25). ▫...

  • Page 52: 7-8.1. Camera Input Config (Contrast / Brightness)

    Instruction Manual Stand-alone DVR 7-8.1. CAMERA INPUT CONFIG (CONTRAST / BRIGHTNESS) ▫ Click on an INPUT button in the CAMERA ENHANCE menu. ▫ The CONTRAST and BRIGHTNESS sliders will be displayed along with camera picture as shown in Fig.7-26. ▫ Adjust Contrast and Brightness with the sliders by clicking the mouse. ▫...

  • Page 53: 7-8.2. Vga Output Config (Contrast / Brightness / Saturation)

    7. How to Operate 7-8.2. VGA OUTPUT CONFIG (CONTRAST / BRIGHTNESS / SATURATION) ▫ To Setup the CONTRAST / BRIGHTNESS / SATURATION of VGA Output, Select the VGA OUTPUT button with KEY or Mouse on VIDEO CONTROL. It will show the [Fig.

  • Page 54: Record

    Instruction Manual Stand-alone DVR 7-9. Record This system provides Watchdog function. When power goes off during recording and the power turns on, the system will automatically start to record. 7-9.1. Manual (Continuous) recording ▫ Click the SETUP icon on the MENU window in the LIVE mode. ▫...

  • Page 55: 7-9.3. Timer Recording

    7. How to Operate MANUAL RECORDING ( ) on the CAM 1 through CAM 16. The MOTION ( ) and SENSOR ( ) as shown in Fig.7-29 should be turned ON in this recording mode. ▫ Press the RECORD button on the front panel or click the RECORD icon on the MENU window.

  • Page 56: 7-9.4. Timer Event Recording

    Instruction Manual Stand-alone DVR 7-9.4. Timer Event Recording ▫ Click the SETUP icon on the MENU window in the LIVE mode. ▫ Click the RECORD button in the SETUP menu and the RECORD window will be displayed. ▫ Select the TIMER RECORDING ( ) between the MANUAL RECORDING ( ) and the TIMER RECORDING (...

  • Page 57: 7-9.5. Recording Icons

    7. How to Operate 7-9.5. Recording Icons The Recording Icons depends on recording modes are displayed on the upper left hand corner of the screen. ▫ To turn the Recording Icon OFF, click the DISPLAY ON in the RECORD menu and then it will be turned OFF.

  • Page 58: Replay

    Instruction Manual Stand-alone DVR 7-10. REPLAY 7-10.1. QUICK REPLAY It is available only by pressing the PLAY button on the front panel or the QICK SEARCH button on the remote controller. ▫ Press the PLAY button, and the recent recorded list will be played. 7-10.2.

  • Page 59: 7-10.2.1. Playback Devices

    7. How to Operate 7-10.2.1. Playback Devices In order to payback, plug the USB devices such as external USB HDD, USB memory to the USB port or insert a recorded media (CD-R/W or DVD-R/W) into the DVD-R/W drive. When the devices are ready to playback, the Ready on the corresponding devices will be displayed in shown in Fig.7-35.
  • Page 60 Instruction Manual Stand-alone DVR ▫ Select the hour on the Start Time Select Window (See Fig.7-37) by clicking the mouse on the Hour (0 – 23 hour) you wish to start to play. The green active buttons indicate the HOUR that recorded data exists, and the red active buttons indicate the selected Start HOUR.

  • Page 61: 7-10.2.3. Replaying

    7. How to Operate 7-10.2.3. Replaying Replaying start time set-up can be possible within a recording time extent. ▫ Replay buttons (NORMAL / MOTION / SENSOR) NORMAL PLAY: Click the button to play all the recorded data. MOTION PLAY: Click the button to play the recorded data by MOTION only. SENSOR PLAY: Click the button to play the recorded data by SENSOR only.

  • Page 62: 7-10.2.4. Disappearance Of Replay Control Buttons

    Instruction Manual Stand-alone DVR Click the button to replay when in the pause mode. ③ REW/FF During replaying, press the button, or turn the shuttle ring on the front panel for fast rewinding and fast forwarding up to 128 times. Keep pressing the button to accelerate the speed up to 128 times.
  • Page 63 7. How to Operate - Click the mouse on one out of channels during replaying to view a full screen. Click the mouse on the full screen during replaying to return to the split screen. [Fig.7-41 SPLIT screen during replaying] [Fig.7-42 FULL screen during replaying]...

  • Page 64: Copy

    Instruction Manual Stand-alone DVR 7-11. COPY ▫ Click the COPY icon on the MENU window, and the COPY window as shown in Fig.7-43 will be displayed. ▫ Click the (EXIT) button to return to the previous mode. [Fig.7-43 COPY window] 7-11.1.
  • Page 65 7. How to Operate follows, but the Medias such as CD-R/W and DVD-R/W don’t need to format.

  • Page 66: 7-11.2. Set The Copy Start Time (Copying Extent)

    Instruction Manual Stand-alone DVR ▫ Connect the USB devices to the DVR ▫ Click the SETUP icon on the MENU window, and the SETUP menu will be displayed. ▫ Click the DISK MANAGER in the SETUP menu, and the DISK MENAGER will be displayed. ▫...
  • Page 67 7. How to Operate [Fig.7-45 Copy Start time and Channel Selection window] ① All channels, HOUR selection button. Click the arrow button on the upper left corner as shown in Fig.7-45 to set the full extent of the recording and all the channels simultaneously. ②...

  • Page 68: 7-11.3. Set The Copy End Time (Copying Extent)

    Instruction Manual Stand-alone DVR [Fig.7-46 Copy Start/End setup buttons] By using the Start/End set-up bar: The starting time to copy can also be set by clicking the slider on the bar and dragging it or just click the bar. [Fig.7-47 Copy Start/End setup bar] 7-11.3.

  • Page 69: 7-11.4. Copying The Recorded Data During Replaying

    7. How to Operate 7-11.4. copying the recorded data during replaying The system, DVR82XX allows users to copy the recorded data during replaying. ▫ Start replaying (See section 7-10). ▫ Right-click on the replaying screen, and the COPY DATA screen will be displayed (See Fig.7-48).
  • Page 70 Instruction Manual Stand-alone DVR [Fig.7-49 End Copy Time Setup window] ▫ Choose one among NETWORK, USB, CD and DVD which are ready to copy (See section 7-11.1). Select COPY Mode Only when the devices and medias are ready to copy, the Ready on the corresponding devices and medias will be displayed.
  • Page 71 7. How to Operate DVD-RW COPY Save the recorded data on DVD-R/W Medias. Click the DVD-R/W button to start copy. ▫ As soon as one of the above button is clicked , copying will start along with displaying the icon shown in Fig.7-50. The following icon indicates that copying is in process.

  • Page 72: Log In / Log Out

    Instruction Manual Stand-alone DVR 7-12. LOG IN / LOG OUT ▫ related to manipulating the system LOG IN / LOG OUT to control the button. ▫ LOG OUT setting the initial state. ▫ LOG IN / LOG OUT Set password information about 8-2.4. PASSWORD see part. [Fig 7-51.

  • Page 73: Setup

    SETUP 8-1. SETUP [Fig.8-1 Setup Icon on MENU window] It is possible to set up the menus in the LIVE mode and partly in the RECORD mode. ▫ Click the “SETUP” button on the MENU window and the SETUP menu will be displayed. ▫...

  • Page 74: System

    Instruction Manual Stand-alone DVR 8-2. SYSTEM ▫ Click the “SYSTEM” button in the SETUP menu, and the SYSTEM menu shown in Fig.8-3 will be displayed. ▫ Click the “EXIT” button to return to the SETUP menu. [Fig.8-3 SYSTEM menu] 8-2.1. LANGUAGE ▫...

  • Page 75: 8-2.2. Time / Date

    8. Setup 8-2.2. TIME / DATE ▫ Click the “TIME/DATE” button in the SYSTEM menu, and the TIME/DATE menu will be displayed (See Fig.8-5). Click the “EXIT” button to return to the SYSTEM menu. [Fig.8-5 TIME / DATE menu] ▫ TIME FORMAT Click the mouse on the TIME FORMAT button to change and then select 24 HOUR or 12 HOUR by clicking the mouse.
  • Page 76 Instruction Manual Stand-alone DVR ▫ DATE FORMAT There are three formats to display the time and date as follow. • MM / DD / YYYY: For U.S.A. • YYYY / MM / DD: For Asian countries. • DD / MM / YYYY: For European countries. Click the DATE FORMAT button and select one among YYYY/MM/DD, DD/MM/YYYY and MM/DD/YYYY by clicking the mouse.

  • Page 77: 8-2.3. System Config

    8. Setup 8-2.3. SYSTEM CONFIG ▫ Click the “SYSTEM CONFIG” button in the SYSTEM menu, and the SYSTEM CONFIG menu will be displayed (See Fig.8-11). ▫ Click the “EXIT” button to return to the SYSTEM menu. [Fig.8-11 SYSTEM CONFIG] 8-2.3.1. FACTORY DEFAULT ▫...

  • Page 78: 8-2.3.2. Load Config / Backup Config

    Instruction Manual Stand-alone DVR [Fig.8-13 Confirmation window of Factory Default] 8-2.3.2. LOAD CONFIG / BACKUP CONFIG You can save up to four different settings in the BACKUP CONFIG and load the files in the LOAD CONFIG to change the settings to the system. ▫...
  • Page 79 8. Setup [Fig.8-15 LOAD CONFIG window] ▫ BACKUP CONFIG This function is to save the current settings to load the settings to the system. Save the current settings in the BACKUP CONFIG in order to load it to the system in the near future whenever you change the settings.

  • Page 80: 8-2.4. Password

    Instruction Manual Stand-alone DVR [Fig.8-17 BACKUP CONFIG window] 8-2.4. PASSWORD ▫ ON/OFF Select ON or OFF by clicking the mouse. If the ON is selected, the password has to be entered to get into the SETUP mode, RECORD mode, COPY mode, REPLAY mode, and when trying to connect the network through the DvrViewer.
  • Page 81 8. Setup ▫If you broke EXIT button ( )Click. ▫ ON/OFF When set to ON SETUP, REPLAY, RECORD DvrViewer or when connected to the DVR PASSWORD set to enter the action. ▫ PASSWORD 입력 'OFF' button is pressed for entering PASSWORD [Figure 7-18. PASSWORD Window keyboard] appears. PASSWORD seed (FACTORY DEFAULT) is "11111111"...
  • Page 82 Instruction Manual Stand-alone DVR ▫Setting PASSWORD Moves such as the following Password page. ○ ○ ○ ○ [Figure 8-19. PASSWORD setting window] ① Active login settings of the setting or OFF ON SETUP, REPLAY, RECORD DVR to access when I DvrViewer PASSWORD to enter into action to make sure that the portion control.
  • Page 83 8. Setup ○ Function buttons each, depending on the user to set a portion of restricting access. Click below to check the box, you can choose whether to use features. Supervisor Common User Guest ○ Auto Logout: If you do not automatically use the time schedule for the Log Out feature that all ows you to maintain security.

  • Page 84: 8-2.5. Ir Remote Id

    Instruction Manual Stand-alone DVR 8-2.5. IR REMOTE ID Up to 16 DVR systems can be controlled by only one remote controller we provided, but IDs should be assigned on each of the systems. You don’t have to assign any ID on the single unit and you can control the system with the provided remote controller without IR REMOTE ID, which is in the OFF mode (Skip this section).

  • Page 85: 8-2.6. Firmware Update

    8. Setup 8-2.6. FIRMWARE UPDATE There are two ways to update the firmware through USB memory and the DvrViewer (GUI). We recommend users to update the firmware only in the LIVE mode. ▫ By USB memory - Format the USB with your computer and save the firmware file on it (not including folder).

  • Page 86: Disk Manager

    Instruction Manual Stand-alone DVR 8-3. DISK MANAGER ▫ Click the “ ” button in the SETUP menu and the DISK MANAGER window will be displayed (See Fig.8-24). ▫ Click the (EXIT) button to return to the SETUP menu. ▫ A DVD R/W and 3 Hard Disk Drives can be installed, and all information in regards to the drives will automatically display on the DISK MANAGER window.

  • Page 87: 8-3.2. Hdd Overwrite

    8. Setup 8-3.2. HDD OVERWRITE ▫ Click the mouse on the OVERWRITE button to select the ON or the OFF. If the ON is selected, the system continues recording by overwriting start from the first index of the recorded file even though the space of HDD is in full. If the OFF is selected, the system will stop recording when the space of HDD is in full.

  • Page 88: Camera

    Instruction Manual Stand-alone DVR 8-4. CAMERA ▫ Click the “CAMERA” button in the SETUP menu and the CAMERA menu will be displayed (See Fig.8-28). To change the settings in the CAMERA menu, stop recording by clicking the RECORD icon on the MENU window. It is possible only in the LIVE mode. ▫...

  • Page 89: 8-4.2. Camera Name (Camera Title)

    8. Setup 8-4.2. Camera Name (Camera Title) ▫ Click the NAME (Camera Title) button in the CAMERA menu and the On Screen Keyboard will be displayed as shown in Fig.8-30. ▫ Delete the existing NAME (Camera Title) with the button on the On Screen Keyboard. ▫...

  • Page 90: 8-4.3. Buzzer

    Instruction Manual Stand-alone DVR 8-4.3. Buzzer In order to alert users, the Buzzer will sound at that time video signal lost. ▫ Click on each of the channels you wish to turn the buzzer “ON” or “OFF”. If the “O” is selected, the buzzer will sound when video signal lost and if the “X”...

  • Page 91: 8-4.5. Pan/Tilt Settings

    8. Setup 8-4.5. Pan/Tilt Settings ▫ Click the PAN/TILT button on the corresponding channels in the CAMERA menu and the PAN/TILT window will be displayed as shown in Fig.8-35. ▫ Click the (EXIT) button to return to the CAMERA menu. [Fig.8-34 PAN/TILT button] [Fig.8-35 PAN/TILT window]...
  • Page 92 Instruction Manual Stand-alone DVR ▫ Pan/Tilt Vendor select Click the “PAN/TILT & REMOTE” button in the PAN/TILT window and the vendor lists will show up. Select a vendor on the vendor lists by clicking the mouse. [Fig.8-36 PAN/TILT & REMOTE] [Fig.8-37 PAN/TILT Vendor lists] ▫...
  • Page 93 8. Setup ▫ Baud rate Click the “BAUD RATE” button in the PAN/TILT window and choose a value among 1200bps, 2400bps, 4800bps, 9600bps, 19200bps, 38400bps, 57600bps and 115200bps on the Baud Rate pop-up window by clicking the mouse. [Fig.8-40 BAUDRATE button] [Fig.8-41 Baud Rate pop-up window] ▫...

  • Page 94: 8-4.6 Display

    Instruction Manual Stand-alone DVR ▫ Stop Bits Click the “STOP BITS” button in the PAN/TILT window and select 1 or 2 on the Stop Bits pop-up window by clicking the mouse. [Fig.8-44 STOP BITS button] [Fig.8-45 Stop Bits pop-up window] ▫...

  • Page 95: 8-4.7 Sequencing Dwell Time

    8. Setup If the “OFF” is selected, the camera name (camera title) in the LIVE mode won’t be displayed. [Fig.8-48 Display ON/OFF button] 8-4.7 Sequencing dwell time ▫ Click the “SEQUENCING DWELL” button in the CAMERA menu and choose a value among 1, 2, 3, 4 and 5seconds on the dwell time pop-up window by clicking the mouse.

  • Page 96: Audio

    Instruction Manual Stand-alone DVR 8-5. AUDIO ▫ Click on the AUDIO button in the SETUP menu and the AUDIO menu will be displayed on the screen. ▫ Click the or the button, and then scroll the page. Each of the pages contains 8 channel.

  • Page 97: Record

    8. Setup 8-6. RECORD ▫ Click the “RECORD” button in the SETUP menu and the RECORD menu will be displayed as shown in Fig.8-53. ▫ Click the or the button, and then scroll the page. Each of the pages contains 8 channel. (1 PAGE : 1 ~ 8 CHANNEL, 2 PAGE : 9 ~ 16 CHANNEL) ▫...

  • Page 98: 8-6.2. All Manual / Timer Recording Button

    Instruction Manual Stand-alone DVR [Fig.8-54 Record ICON Display button] 8-6.2. All Manual / Timer recording button ▫ Click the All Manual / Timer recording button in the RECORD menu and the All Manual / Timer recording button will be displayed as shown in Fig.8-55. ▫...

  • Page 99: 8-6.4. All Sensors On / Off

    8. Setup ▫ By clicking the mouse, select the on the pop-up window (See Fig.8-58) and choose one of the sensitivity among LOW, 1, 2, 3 and HIGH for all the channels with the mouse’s wheel, and then click it to save. ▫...

  • Page 100: 8-6.5. Size (Recording Resolution)

    Instruction Manual Stand-alone DVR ▫ By clicking the mouse, select the on the pop-up window (See Fig.8-61) to disable the system to start recording by Sensor (Passive Infrared sensor) for all the channels. [Fig.8-60 All Sensor Setup button] [Fig.8-61 All Sensor Setup pop-up window] 8-6.5.
  • Page 101 8. Setup pop-up window by clicking the mouse. ▫ If the AUTO is selected on all the channels, the Recording Speed on all the channels should be the same. If the OFF is selected, the corresponding channel won’t be recording. [Fig.8-64 Record Speed button] [Fig.8-65 Record Speed pop-up window]...

  • Page 102: 8-6.7. Recording Quality

    Instruction Manual Stand-alone DVR NTSC [Fig.8-66 Recording Speed for each channel] 8-6.7. Recording Quality ▫ Click the QUALITY button on each of the channels in the RECORD menu and the QUALITY pop-up window will be displayed as shown in Fig.8-68. ▫...

  • Page 103: 8-6.8. Recording Mode

    8. Setup Recording Mode 8-6.8. The factory default setting for Recording is the Manual Recording (or called Continuous Recording), which keeps recording continuously if the OVERWRITE is set ON in the DISK MANAGE menu. This Manual Recording mode is not only one of the most popular Recording modes for users, but also one of the most convenient Recording modes to use.
  • Page 104 Instruction Manual Stand-alone DVR ▫ ON/OFF The system will start to record when MOTION is detected and the ON is selected in the MOTION menu by clicking the mouse. If the OFF is selected, the system won’t be recording. [Fig.8-70 MOTION ON/OFF button]...
  • Page 105 8. Setup ▫ Pre-Alarm Time Setup Allows you to record a section of video just prior to Motion or Sensor activation. Click the mouse on the PRE in the MOTION menu and choose one of the values among 0, 1, 2, 3, 4 and 5 seconds with the mouse’s wheel, and then click it to save.
  • Page 106 Instruction Manual Stand-alone DVR ▫ Region The Motion Detection Area displays in blue on the screen, and it turns to doubly-box when the motion is detected. The white color on the screen represents none of detection area. There are three kinds of REGION settings as follows. Click the button in the MOTION menu and the Motion Detect Area Setting window will be displayed as shown in Fig.8-74...
  • Page 107 8. Setup By All Set Right-click on the Motion Detect Area Setting window (Fig. 8-74), and the Motion Detect Area Setting pop-up window will be displayed (Fig. 8-75). By clicking the mouse, Select the button on the Motion Detect Area Setting pop-up window. Motion Detect Area displays in blue on the screen as shown in Fig.
  • Page 108 Instruction Manual Stand-alone DVR - All Clear Right-click on the Motion Detect Area Setting window (Fig. 8-74), and the Motion Detect Area Setting pop-up window will be displayed (Fig. 8-75). By clicking the mouse, Select the button on the Motion Detect Area Setting pop-up window in order to clear the Motion Detect Area.
  • Page 109 8. Setup By Window Set Right-click on the Motion Detect Area Setting window (Fig. 8-74), and the Motion Detect Area Setting pop-up window will be displayed (Fig. 8-75). By clicking the mouse, Select the button on the Motion Detect Area Setting pop-up window. click one of cells for the starting point of the area which you would like to designate, and then click the other one of cells for the ending point of area until the motion detection area is the size you want it to be.
  • Page 110 Instruction Manual Stand-alone DVR - Window Clear Right-click on the Motion Detect Area Setting window (Fig. 8-74), and the Motion Detect Area Setting pop-up window will be displayed (Fig. 8-75). By clicking the mouse, Select the button on the Motion Detect Area Setting pop-up window in order to clear the Motion Detection Area, and the window you already created the motion detection area will be displayed.
  • Page 111 8. Setup By Each Cell Right-click on the Motion Detect Area Setting window (Fig. 8-74), and the Motion Detect Area Setting pop-up window will be displayed (Fig. 8-75). By clicking the mouse, Select the button on the Motion Detect Area Setting pop-up window. Click the mouse on each of the cells as much as you would like to designate the Motion Detection Area.

  • Page 112: 8-6.10. Recording By Sensor (Pir Sensor)

    Instruction Manual Stand-alone DVR 8-6.10. Recording by Sensor (PIR Sensor) ▫ Click the mouse on the button for each of the channels in the RECORD menu and the SENSOR menu will be displayed on the screen as shown in Fig. 8-82. ▫...
  • Page 113 8. Setup...
  • Page 114 Instruction Manual Stand-alone DVR ▫ Pre-Alarm Time Setup Allows you to record a section of video just prior to Sensor activation. Click the mouse on the PRE in the SENSOR menu and choose one of the values among 0, 1, 2, 3, 4 and 5 seconds with the mouse’s wheel, and then click it to save.

  • Page 115: Network

    8. Setup 8-7. NETWORK ▫ Click the “NETWORK” button in the SETUP menu and the NETWORK menu will be displayed on the screen as shown in Fig.8-87. ▫ Click the (EXIT) button to return to the SETUP menu. [Fig.8-87 NETWORK menu] 8-7.1.

  • Page 116: 8-7.2. Gateway, Subnet, Ip Address

    Instruction Manual Stand-alone DVR [Fig.8-88 IP Mode button] [Fig.8-89 IP Mode pop-up window] 8-7.2. GATEWAY, SUBNET, IP ADDRESS ▫ Click the GATEWAY / SUBNET / IP ADDRESS button in the STATIC IP MODE and the On Screen Keyboard will appear. ▫...

  • Page 117: 8-7.3. Port

    8. Setup 8-7.3. Port ▫ PORT is the TCP address of the program, which is used to connect to the network viewer. It can be set from 1 to 65535 values. ▫ Click the PORT button and the On Screen Keyboard will show up. ▫...

  • Page 118: 8-7.4. Mac Id

    Instruction Manual Stand-alone DVR ▫ Do not use the public port numbers. 8-7.4. MAC ID ▫ MAC ID is connecting address for Ethernet, every unit has 12 digit address (HEX 6 byte). MAC ID was already assigned with the factory default value. User can not change it. 8-7.5.
  • Page 119 8. Setup [Fig.8-95 DISABLE/ENABLE button]...
  • Page 120 Instruction Manual Stand-alone DVR ▫ IP ADDRESS / PORT DO NOT CHANGE THE IP ADDRESS AND PORT NUMBER IN THE MNS MENU IF YOU DON’T HAVE ANY SPECIAL SERVER TO ACCESS YOUR DVR WITH A DYNAMIC IP ADDRESS. IF YOU CHANGE THEM, YOU CAN’T NOT ONLY USE OUR MNS (MAC NAME SERVER), BUT ALSO YOUR NETWORKING WILL BE DISCONNECTED.

  • Page 121: 8-7.6. Ddns (Dynamic Domain Name System)

    8. Setup 8-7.6. DDNS (DYNAMIC DOMAIN NAME SYSTEM) ▫ Select the DDNS button in the NETWORK menu by clicking the mouse, pressing the buttons on the front panel or remote controller. The DDNS menu will show up as shown in Fig.

  • Page 122: 8-7.7. Same As Monitor

    Instruction Manual Stand-alone DVR Screen Keyboard. - After changing the values, click on the OK button. [Fig.8-100 HOST NAME button] ▫ USER ID - Click the USER ID in the DDNS menu and enter the USER ID that is registered to the DDNS service provider by using the On Screen Keyboard.

  • Page 123: Remote Host Program

    Remote Host Program 9-1. Remote Program Overview The Remote Host Program allows you to view live video, search archived video, control PTZ cameras and to set up the exact same menus as the DVR does. The DVR system can have up to 10 simultaneous Remote Connections. Each user can performs on the DVR system and will not affect the other users.

  • Page 124: Installing The Program To Pc

    Instruction Manual Stand-alone DVR 9-2. Installing the Program to PC Install the program into PC by using program CD (supplied) as follows. How to install the program 1. Start the operating system (Windows 2000/XP). 2. Insert the program CD into CD-ROM drive. 3.

  • Page 125: Internet Explorer

    9. Remote Host Program 9-3. Internet Explorer Setup same as Client viewer 9-4. Remote Host ① ② ③ ④ ⑤ ⑥ ⑦ ⑧⑨⑩ ⑪ ○ ○ ○ ○ [Fig.9-5 DvrViewer] ○...
  • Page 126 Instruction Manual Stand-alone DVR Table. Remote host program buttons ① Minimize button ② Close button ③ Current Time ④ Access button ⑤ Settings button ⑥ Players run button ⑦ Capture button ⑧ Multiplayer mode ⑨ Terminal mode ⑩ E-map button ⑪...

  • Page 127: 9-4.1. Setup

    9. Remote Host Program 9-4.1. Setup ① ② ③ ④ [Fig.9-6 HOST CONFIG window] ① Version number It represents the current version number of the Firmware. ② Copy Refer to Section 9-4.5 in regards to copying methods after selecting one between the Quick Copy and the Live + Copy.
  • Page 128 Instruction Manual Stand-alone DVR ③ Network Image ▫ Size Choose a Size (Resolution) among D1, Half D1 and CIF you wish to display on the DvrViewer by clicking the mouse. This setting does not affect the DVR. ▫ Quality Choose one among LOW, NORMAL, HIGH and BEST you wish to display on the DvrViewer by clicking the mouse.

  • Page 129: 9-4.2. Connection

    9. Remote Host Program 9-4.2. Connection There are two ways to access the DVR through the DvrViewer as follows. ▫ With Set Direct setting - Click the “CONNECT” button on the DvrViewer and the DvrViewer will be displayed. - Click the mouse on the “Set Direct” in the Connect Dialog menu and click the “EDIT” button and enter the IP address and Port number, which must be the same as DVR has.

  • Page 130: 9-4.3. Status Mode

    Instruction Manual Stand-alone DVR 9-4.3. STATUS MODE DVR STATUS window STATUS button [Fig.9-9 STATUS MODE] ▫ Click the button, and the CAMERA / SENSOR / RELAY status and storage space for each HDD being used in DVR will be displayed. (See Fig. 9-9, DVR STATUS window)

  • Page 131: 9-4.4. Replay

    9. Remote Host Program 9-4.4. REPLAY REPLAY time set-up window REPLAY button [Fig.9-10 REPLAY MODE] ▫ You to play the recorded image on DVR. ▫ Click the button, and REPLAY time set-up window that contains recorded start / end time for replay will be displayed. (See Fig. 9-10, REPLAY time set- up window) When you click the button, it will show the Play Time set-up window (See...
  • Page 132 Instruction Manual Stand-alone DVR ▫ Replay Control Replay control window [Fig.9-12 REPLAY CONTROL MODE] - PLAY / PAUSE Click the button to replay. - REW / FF During replaying, press the button, or turn the shuttle ring on the front panel for fast rewinding and fast forwarding up to 128 times.

  • Page 133: 9-4.5. Copy

    9. Remote Host Program 9-4.5. COPY COPY time set-up window COPY button [Fig.9-13 COPY MODE] ▫ You to copy the recorded data from DVR to remote PC. The Recorded data will be saved in the Backup Files (Open Windows Explorer – click My Computer –...
  • Page 134 Instruction Manual Stand-alone DVR...
  • Page 135 9. Remote Host Program ▫ Click the button to copy the recorded data. The DvrViewer will show the progressive status to copy (See Fig. 9-15, Progressive status to Copy) Click the button to copy close. STOP button Progressive status to Copy [Fig.9-15 Copying on the DvrViewer]...

  • Page 136: 9-4.6. Speaker / Microphone

    Instruction Manual Stand-alone DVR 9-4.6. Speaker / Microphone ① ② ③ ④ ⑤ [Fig.9-16 Speaker / Microphone] Buttons of Remote Host Program ① Audio Input channel selection: Select the same audio channel as the DVR has. ② PC Speaker ON/OFF: Turn the Speaker ON or OFF by clicking the mouse. ③...

  • Page 137: 9-4.7. Access Mode

    9. Remote Host Program 9-4.7. Access mode Access mode [Fig.9-17 CONNECT MODE] ▫ access mode is divided into Terminal mode and Multi mode. Multi Mode: DVR connected to the camera, respectively, for showing the video mode. Terminal Mode: DVR-screen monitors connected to the network, as viewers can also watch the mouse control mode.

  • Page 138: 9-4.8 E-Map

    Instruction Manual Stand-alone DVR 9-4.8 E-Map E-Map [Fig.9-18 E-Map MODE] ▫ E-Map mode is being used actual drawings (map), by placing the camera on a faster, more accurate, a feature that enables surveillance. 1. Map (drawings, maps) MORE Map of the mouse right button is pressed part of the pop-up menu appears. Add eMap cameras installed by pressing the actual drawings (map) to call.
  • Page 139 9. Remote Host Program Right-loaded map the name of the gorilla pressed to Rename from the pop-up menu and then change the name. (Map does not use the right mouse button to click pop-up menu and click the Delete eMap Map will be deleted.
  • Page 140 Instruction Manual Stand-alone DVR Use of the camera position display A small portion of the rectangular icon of the camera position. Live display screen connected to the camera position, and scale with the mouse to move the camera position, double-clicking on the Live screen icon look you can cover up.
  • Page 141 9. Remote Host Program 4. Removal of the location of the camera icon. Live camera's screen or the mouse to position the camera icon on the Map Screen Drag & Drop out of the c amera will be deleted. * Map to re-install the camera on the screen below "2. Map cameras placed on the screen, "Please repeat. [Fig.9-26 Delete Camera Icon and Live screen]...

  • Page 142: Player

    Instruction Manual Stand-alone DVR 9-5. PLAYER ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑫ ⑪ [Fig.9-27 Player] Chart. Button of Player Program ① Status window (Play mode, Date, Time) ② Calendar ③ Convert to AVI File ④ Search button for replaying ⑤...
  • Page 143 9. Remote Host Program ① Status window (Play mode, Date, Time) It indicates the play mode, date and time. [Fig.9-28 Status window] ② Calendar It shows the date currently being replayed. [Fig.9-29 Calendar] ③ Convert AVI File Convert the recorded files to AVI files. - Click the Convert AVI button on the Player and the Convert AVI window will be displayed (See Fig.9-20).
  • Page 144 Instruction Manual Stand-alone DVR [Fig.9-30 Convert AVI window] [Fig.9-32 DVR Rec Data by USB] [Fig.9-31 Backup Files by Networking]...
  • Page 145 9. Remote Host Program [Fig.9-33 Select one of the Channels] [Fig.9-34 Start Convert Button] How to play the AVI files By using Windows media player: - Click the OPEN button on the Convert AVI window and double click one of the AVI files to play. The AVI files will save in the AVI Files folder (Open Windows Explorer –...
  • Page 146 Instruction Manual Stand-alone DVR ④ Search button for Replaying - Click the Search button on the Player and the Browse for Folder will be displayed. - Select the folder that contains the recorded data and click the OK button on the Browser for Folder.
  • Page 147 9. Remote Host Program [Fig.9-35 Print command window] [Fig.9-36 Print image] ⑦ Division button Select one of the following divisions while replaying. Full Screen 4 Division Screen 9 Division Screen 16 Division Screen [Fig.9-37 Division button] ⑧ Playback (Replay) Speed Control Move the slider with the mouse to control the replaying speed.
  • Page 148 Instruction Manual Stand-alone DVR ⑨ Search slider for replaying The slider can be moved left and right by clicking the slider on the bar and dragging it or just click the bar to search the recorded data. [Fig.9-39 Replay Search Slider] ⑩...

  • Page 149: Installation Of Additional Hdds

    Installation of additional HDDs 10-1. HDD (Hard Disk Drive) INSTALLATION ▶ Three of internal Hard Disk Drives (HDD) and a CD R/W or DVD R/W can be installed in the system. DVR manufacturer already installed a 320GB of Hard Disk Drive (IDE) and a DVD R/W.

  • Page 150: Installation Of An Additional Hdd

    Instruction Manual Stand-alone DVR 10-2. Installation of an additional HDD ▶ Set the jumper setting to “Cable Select” position on the additional HDD. Be sure that the jumper setting is correct. If not, the system will not Note : recognize the additional HDD. ▶...

  • Page 151: Appendix

    APPENDIX Recording time table HDD: 300GB Recording Resolution: Half D1 (720 x 240) Based on 8 cameras HOURS Each 15 fps 10 fps 7 fps 5 fps 3 fps 2 fps 1 fps (Total) (120fps) (80fps) (56fps) (40fps) (24fps) (16fps) (8fps) 69.00 104.00...

  • Page 152: Factory Default Settings

    Instruction Manual Stand-alone DVR Factory default settings (1) LIVE SCREEN 16 SPLIT OSD ON (2) LIVE AUDIO AUDIO OFF VOLUME 5 (Max. 16) AUDIO 1CH (3) TIME / DATE TIME FORMAT : 24 HOUR DATE FORMAT : YYYY/MM/DD DISPLAY : ON (4) LOAD / BACKUP CONFIG NONE LISTS (5) USER ACCOUNT...
  • Page 153 (8) CAMERA ACTIVE : ALL ON NAME : CAM 01 ~ CAM 16 BUZZER : ALL ON RELAY : ALL OFF PAN/TILT VENDOR : PELCO DISPLAY : ON SEQ DISPLAY DWELL : 1 SEC (9) AUDIO ALL MIC 5 (Max. 16) (10) RECORD ICON DISPLAY : ON SIZE : ALL HALF D1 (704 X 240)
  • Page 154 Instruction Manual Stand-alone DVR - SENSOR ON/OFF : OFF PRE : 1 sec. HOLD : 10 sec. SPOT : OFF (11) NETWORK TYPE : DYNAMIC PORT : 113 - MNS SERVER 1 MODE : DISABLE SERVER 1 IP ADDRESS : 65.60.84.25 SERVER 1 PORT : 300 SERVER 2 MODE : DISABLE SERVER 2 IP ADDRESS : 221.149.149.117...

  • Page 155: Faq

    CONTENTS ..........................7 CANNOT LOGIN I cannot login ▶ Please check if the link LED of DVR and LAN port of PC are lit. ▶ Please check if the IP address on DVR and the PC is identical. Check SYSTEM STATUS by pressing STATUS button of DVR (Available on LIVE mode and RECORD mode.) MY IP : xxx.xxx.xxx.xxx Check Target IP Address by clicking CONF button of PC host program.
  • Page 156 Instruction Manual Stand-alone DVR ▶ Please check whether DVR is connected another PC. Check SYSTEM STATUS by pressing STATUS button. FROM : xxx.xxx.xxx.xxx : IP which is presently connected. MY IP : xxx.xxx.xxx.xxx : DVR is waiting for connection. ▶ Please check whether firewall is installed in the network. Ask the network administrator to reconfigure the firewall.

Table of Contents
