USER MANUAL
_________________________________________________________________________________
Before connecting, operating or adjusting this product,
AD DISPLAY
FP1921
(LANG: ENGLISH)
please read these instructions completely.
Please keep this manual for future reference
(All pictures used in this manual are only for illustration purposes.
Those pictures may be different from the actual.)
Advertisement
Table of Contents
Related Manuals for Rell Healthcare FP1921 rellhealthcare
Summary of Contents for Rell Healthcare FP1921 rellhealthcare
- Page 1 USER MANUAL AD DISPLAY _________________________________________________________________________________ FP1921 (LANG: ENGLISH) Before connecting, operating or adjusting this product, please read these instructions completely. Please keep this manual for future reference (All pictures used in this manual are only for illustration purposes. Those pictures may be different from the actual.) ...
- Page 3 Important Information Please do not open or remove the cover plate because it may generate a high voltage shocking or other dangers. Please do not precede the maintenance or repairing of this unit by yourself. Carefully read the instruction manual before use, and keep the manual for future reference. Please read and comply with all warnings, cautions, and the manual thoroughly. You might lose your warranty if you modify or revise this item in such as manner not approved by this manual. AC cords enclosed in this product are for 110V or 220V. If any liquid or solid objects fall inside the cabinet, unplug the set immediately and have it checked by qualified service personnel before operating it again. Never add any attachments and/or equipments without approval of the manufacturer. Such additions can increase the risk of fire, electric shock, or other personal injury. Important Warnings and Safety Precautions Read instructions‐ all the safety and operating instructions should be read before the product is operated. Keep the safety and operating instructions for future reference. Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short‐out parts that could result in fire or electric shock. Never spill liquid of any kind on the product. Do not remove/insert the plug into the socket with wet hands in order to prevent electric shock. Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock. Do not attempt to service this product by yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all services to qualified service personnel. The manufacturer will not be responsible for any injuries or damage caused to the product. AC cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, pay attention particularly to cords at plugs, convenience receptacles, and the points where they exit from the product. Unplug the unit from the wall outlet before cleaning. Use a damp cloth; do not use liquid or aerosol cleaners. Please refer to the cleaning instruction. Do not place the product on an unstable cart, stand, tripod, bracket, or table where it may fall. A falling unit can cause serious injury to a child or adult and serious damage to the appliance. Follow the manufacturer’s ...
-
Page 5: Table Of Contents
Contents 1. INTRODUCTION ......................... 1 Product Description ........................1 Product Features ........................... 1 Package Contents ........................... 1 2. SYSTEM SETUP ........................... 2 Top Panel & Remote Control Function ..................2 Remote Control Function ....................... 3 Input / Output Signal Connections ....................4 3. ... -
Page 7: Introduction
1. INTRODUCTION Product Description FP‐1921 is an Advertizing Display that incorporates the LCD Screen with a DMP‐3 Media Player to play back HD image JPEG files as well as video files by scaler for video up conversion for 1080i quality. Product Features HD component output for 720p/1080i JPEG display. Scaler for video up‐conversion to 720p/1080i. MPEG‐4 simple profile video support. Support file format: Ware, AAC, MP3, WMA, BMP, TIFF, PNG, GIG JPEG, Progressive JPEG, Motion JPEG, MPEG‐1, MPEG‐2, MPEG‐4. Built‐in remote receiver, easy operation. Firmware can by upgraded by using flash memory card. NTSC/PAL encode with three video DACs for composite, YPbPr and RGB video output. Power‐on play: automatically play. Package Contents Please check the package to make sure is contains the following items Main device Remote controller AC power cable User Manual Page 1 ... -
Page 8: System Setup
2. SYSTEM SETUP Top Panel & Remote Control Function Button Name Function LEFT / VOL‐ Decrease volume; use for decrement value in function adjustment. Display the screen controller main menu on screen; use to go to the MENU previous level of OSD. Increase volume; use for increment value in function adjustment; use to VOL+ / RIGHT go to the next level of OSD. “Power stand by” ‐ ON / OFF POWER CH‐ ▼ For screen OSD down navigation key CH+ ▲ For screen OSD up navigation key LED Red Stand‐by / Green Active IR Remote IR Sensor (Receive IR signal from remote Control) LED Blue Active IR Remote IR Sensor (Receive IR signal from remote Control) Note: remove the cover of CF card first, could use the remote controller to operating the media player. Page 2 ... -
Page 9: Remote Control Function
Remote Control Function No Key name Description Monitor Remote Control Unit 1 Turn off volume LEFT / MENU For screen controller OSD 2 / RIGHT / EXIT navigation key 3 Output Change video out mode / / / For media player OSD 4 navigation key 5 Previous file 6 Power standby on or off 7 Setup No function Adjust volume up / down 8 VOL + / ‐ For screen controller OSD up / down navigation key 9 ... -
Page 10: Input / Output Signal Connections
Input / Output Signal Connections No. Terminal 1. DC out (supply to media player power) 2. HDMI input 3. VGA input 4. S‐Video input 5. CVBS Video input 6. Audio Input (YPbPr / S‐Video / CVBS) 7. VGA Audio input 8. Headphone output 9. Component video input (YPbPr) Page 4 ... -
Page 11: On Screen Display Operating Instructions
3. ON SCREEN DISPLAY OPERATING INSTRUCTIONS ~~ Media Player OSD ~~ a. Main Screen Plug‐in CF card and turns on power, 6 function icons will be displayed for selection. Click arrow key◄/▲/►/▼of remote control to select auto power‐on play. Note: Pressing the arrow key◄/▲/►/▼during looping will interrupt the play mode. To retrieve the mode please turn off the power and reboot again. Use arrow key◄/▲/►/▼for the selection movement. Use enter key to enter / confirm the selection. Note: When on CF card detected, you can only execute “Setup”. (All other functions will be disabled.) Page 5 ... -
Page 12: Photo Operate Screen
b. Photo operate screen Information Row and Help Row display subject to the setting of OSD. Please use arrow key /▲/ /▼as movement, Use enter key as confirmation. When cursor is at first menu photo, press arrow key will link to action button row。 This screen will not be displayed if there is no photo file format in you CF card. c. Music operate screen Page 6 ... -
Page 13: Video Operate Screen
d. Video operate screen e. File operate screen Device operate screen Non‐active screen of user. Page 7 ... -
Page 14: Setup Screen
g. Setup screen Photo setup operating instructions PHOTO SETUP – THUMBNAIL DIGEST Level 1 Level 2 Level 3/Function PHOTO SETUP THUMBNAIL DIGEST AUDIO SETUP PHOTO DISPLAY SIZE ON / ZOOM /OFF VIDEO SETUP SLIDESHOW MODE PREFERENCES INTERVAL TIME Icon set up EXIT TRANSITION ON: Reduce the icon into smaller MAIN PAGE size ZOOM: Reduce in 4:3 proportions. OFF: Remain the icon size as it is. Note: about the remote control key operate, is suitable for the following explanation. 1. Use ▲/▼/ ►/ ◄ for movement among selection. 2. Use as enter / confirmation. ... - Page 15 PHOTO SETUP – PHOTO DISPLAY SIZE Level 1 Level 2 Level 3/Function PHOTO SETUP THUMBNAIL DIGEST AUDIO SETUP PHOTO DISPLAY SIZE BEST FIT / DEFAULT VIDEO SETUP SLIDESHOW MODE PREFERENCES INTERVAL TIME Photo setup EXIT TRANSITION BEST FIT: Regardless photo size and MAIN PAGE adjust to best fit of screen. DEFAULT: Display as original photo size. PHOTO SETUP – SLIDESHOW MODE Level 1 Level 2 Level 3/Function ...
-
Page 16: Photo Setup Operating Instructions
Photo setup operating instructions AUDIO SETUP – SPDIF OUTPUT Level 1 Level 2 Level 3/Function PHOTO SETUP SPDIF OUTPUT AUDIO SETUP MAIN PAGE OFF / SPDIF/RAW / SPDIF/PCM VIDEO SETUP PREFERENCES Non‐active screen of user. EXIT Page 10 ... -
Page 17: Photo Setup Operating Instructions
Photo setup operating instructions VIDEO SETUP – VIDEO OUTPUT Level 1 Level 2 Level 3/Function PHOTO SETUP VIDEO OUTPUT AUDIO SETUP TV MODE YPbPr / RGB VIDEO SETUP VIDEO FULL SCREEN PREFERENCES DIVX SUBTITLE Video output set up EXIT SUBTITLE LANGUAGE MAIN PAGE VIDEO SETUP – TV MODE Level 1 Level 2 Level 3/Function PHOTO SETUP VIDEO OUTPUT AUDIO SETUP ... - Page 18 VIDEO SETUP – SUBTITLE LANGUAGE Level 1 Level 2 Level 3/Function PHOTO SETUP VIDEO OUTPUT ENGLISH / 中文 AUDIO SETUP TV MODE VIDEO SETUP VIDEO FULL SCREEN PREFERENCES DIVX SUBTITLE Select language subtitle of DIVX video format. EXIT SUBTITLE LANGUAGE MAIN PAGE Page 12 ...
-
Page 19: Photo Setup Operating Instructions
Photo setup operating instructions PREFERENCES PAGE – OSD LANGUAGE Level 1 Level 2 Level 3/Function PHOTO SETUP OSD LANGUAGE AUDIO SETUP INFORMATION ROW ENGLISH VIDEO SETUP HELP ROW PREFERENCES FILE EDITING Setting OSD Language EXIT FILE SORTING AUTO START SETUP VALUES MAIN PAGE PREFERENCES PAGE ‐ INFORMATION ROW Level 1 Level 2 Level 3/Function ... - Page 20 PREFERENCES PAGE – FILE EDITING Level 1 Level 2 Level 3/Function PHOTO SETUP OSD LANGUAGE AUDIO SETUP INFORMATION ROW ON / OFF VIDEO SETUP HELP ROW PREFERENCES FILE EDITING Non‐active screen for user. EXIT FILE SORTING AUTO START SETUP VALUES MAIN PAGE PREFERENCES PAGE – FILE SORTING Level 1 Level 2 Level 3/Function ...
-
Page 21: Screen Controller Osd
~~ Screen Controller OSD ~~ a. OSD Menu Level 1 illustration definition PICTURE SOUND SOURCE SYSTEM Picture operating instructions PICTURE – PICTURE MODE Level 1 Level 2 Level 3/Function PICTURE MODE PERSONAL Use the LEFT/RIGHT button to select CONTRAST STANDARD the desired picture quality. BRIGHTNESS DYNAMIC HUE SOFT Press MENU button to return. Press EXIT button to exit. SATURATION Use VOL ▲+/‐▼ button to move SHARPNESS between the options. NR ... - Page 22 PICTURE – BRIGHTNESS Level 1 Level 2 Level 3/Function PICTURE MODE Use the LEFT/RIGHT button to adjust CONTRAST the brightness level. BRIGHTNESS Press MENU button to return. HUE Press EXIT button to exit. SATURATION Use VOL ▲+/‐▼ button to move SHARPNESS between the options. NR COLOR TONE SCALE PICTURE – SATURATION ...
- Page 23 PICTURE – NR (Noise Reduction) Level 1 Level 2 Level 3/Function PICTURE MODE Use the LEFT/RIGHT button to adjust CONTRAST the parameter of noise reduction. BRIGHTNESS Press MENU button to return. HUE Press EXIT button to exit. SATURATION Use VOL ▲+/‐▼ button to move SHARPNESS between the options. NR COLOR TONE SCALE PICTURE – COLOR TONE ...
-
Page 24: Sound Operating Instructions
Sound operating instructions SOUND – SOUND MODE Level 1 Level 2 Level 3/Function SOUND MODE STANDARD Use the LEFT/RIGHT button to select BASS NEWS the type of scheme. TREBLE MUSIC BALANCE PERSONAL Press MENU button to return. Press EXIT button to exit. AVC Use VOL ▲+/‐▼ button to move between the options. SOUND – BASS Level 1 Level 2 ... - Page 25 SOUND – AVC Level 1 Level 2 Level 3/Function SOUND MODE OFF Use the LEFT/RIGHT button to turn BASS ON on/off auto volume control. TREBLE Press MENU button to return. BALANCE Press EXIT button to exit. AVC Use VOL ▲+/‐▼ button to move between the options. Page 19 ...
-
Page 26: System Operating Instructions
System operating instructions SYSTEM – OSD LANGUAGE Level 1 Level 2 Level 3/Function OSD LANGUAGE ENGLISH Use the LEFT/RIGHT button to select TTX LANGUAGE DEUTSCH your desired language. H‐POSITION FRANCAIS Press MENU button to return. V‐POSITION ESPANOL Press EXIT button to exit. DURATION ITALIANO Use VOL ▲+/‐▼ button to move HALFTONE DUTCH between the options. SLEEP PORTUGUESE INFORMATION MEMORY RECALL ... - Page 27 SYSTEM – V‐POSITION Level 1 Level 2 Level 3/Function OSD LANGUAGE Use the LEFT/RIGHT button to adjust TTX LANGUAGE the vertical position of the OSD display H‐POSITION on screen. V‐POSITION Press MENU button to return. DURATION Press EXIT button to exit. HALFTONE Use VOL ▲+/‐▼ button to move SLEEP between the options. INFORMATION MEMORY RECALL ...
- Page 28 SYSTEM – SLEEP Level 1 Level 2 Level 3/Function OSD LANGUAGE Use the LEFT/RIGHT button to adjust TTX LANGUAGE the sleep timer within the range "off / H‐POSITION 15 / 30 / 45 / 60 / 90 / 120" minutes. V‐POSITION Press MENU button to return. DURATION Press EXIT button to exit. HALFTONE Use VOL ▲+/‐▼ button to move SLEEP between the options. INFORMATION MEMORY RECALL ...
-
Page 29: Source Operating Instruction
Source operating instruction Source Level 1 Function Press RIGHT to select desired input PC 1. Computer input signal. signal. HDMI 2. HDMI input signal. Press MENU button to return. AV 3. AV input signal. Press EXIT button to exit. SVIDEO 4. S‐Video input signal. Use VOL ▲+/‐▼ button to move YPBPR 5. Component video input signal. between the options. Page 23 ... -
Page 30: Reference
4. REFERENCE Cleaning LCD Monitor 1. Please make sure that you have turned off this machine. 2. Do not expose liquid of any kind on the LCD Monitor or plastic box. Please NOTE when cleaning the LCD monitor. 1. Gently wipe the screen with a clean, soft, lint‐free cloth to remove dust or other particles that can scratch the screen. 2. To clean the tough areas, use a soft, lint‐free cloth with a few drops of water to remove the stubborn dirt. 3. Do not apply pressure to the surface of the TFT‐LCD When you clean the housing 1. Use a soft, dry cloth to clean housing. 2. To clean tough areas, use a soft, lint‐free cloth with a few drops of water to remove the stubborn dirt. Page 24 ... -
Page 31: Appendix
5. APPENDIX Troubleshooting Please use the following table to resolve the most common possible causes of the problem before calling service personnel. A minor adjustment may eliminate the problem and restore your TV reception. Symptom Corrective Actions Check that power is turned on. Adjust brightness and contrast. No picture screen Check input signal of TFT‐LCD. Check the power connection to the unit with screen. Check Main Display selection. Check that Video cable is plugged in. Picture is not clear Refer to the Picture Adjustments Menu in the OPERATING INSTRUCTIONS. The power could be failing, try connecting the unit to another power outlet. Move unit a way from the magnetic equipment, such as Wireless Receiver, AC Image is fuzzy Transformer, …etc. Refer to the Picture Adjustment Procedure Menu in the OPERATING INSTRUCTIONS. Colors are distorted Check that the Video cable is plugged in securely. Check Video input range (V‐sync：Max. 75Hz, H‐sync：Max.48.08KHz) Screen bounces or has wavy oscillations Make sure Video cable connections are secure. Check speaker line connections. No sound Sound might be muted, try adjusting the volume. Check audio wire connections with source device. Only one speaker operates Check the unit’s speaker wires are securely connected. Check for light or obstacle interference with remote control signal and move unit to another location. Remote Control inoperative Batteries are dead; replace batteries with new ones.
