Summary of Contents for Lloyd LGS808NS
- Page 1 INSTRUCTION BOOK MULTIFUNCTION GARMENT STEAMER MODEL:LGS808NS...
- Page 2 Congratulations on being the proud owner of Lloyd Garment Steamer. Your Garment Steamer comes with a Lloyd Guarantee of Quality. Lloyd takes great pride in providing its customers with perfect products that adheres to international quality standards. Lloyd is committed to provide the ultimate customer satisfaction as nothing brings us greater joy than having satisfied customers of Lloyd.
- Page 3 CATALOG 1. Product profile 2.Product features 3.Operating instructions 4.Clean and storage 5.Safety instructions 6.Technical standards 7.Trouble shooting...
-
Page 4: Product Profile
PRODUCT PROFILE With the lifestyle of the people changing rapidly, the importance of appearance of people and hence, of clothes has increased. However, with lifestyle of the people, especially in the cities has become so fast. This in turn, has made a daily household chore like ironing a very tedious and time consuming job. -
Page 5: Operating Instructions
3.OPERATING INSTRUCTIONS 1)Parts name Brush head Steam nozzle and clothes hook Magic hanger How to assemble the hanger Telescopic aluminum pole Steam hoses Telescopic pole lock button Steam hoses fixed twist Water tanks Switch with lamp Steam main outlet Water wheel Boiler cleaning knob. - Page 6 2)Installation method A.inspect product and all parts Open the box, check all the parts and accessories, make sure there are no missing parts in the box. Name Steam hoses Telescopic alum pole Brush head Magic hanger Hook Water tank Instruction book Steam host Quantity B.Installation Step...
- Page 7 4 Open the lock button (see Figure (3)), pull up retractable lever, adjust to the appropriate place and then, press the button to lock it.(see Figure (4)) Figure(3) Figure(4) Insert the steam hose to the host as Figure (5) and rotate clockwise Tighten the hose fixing button.
- Page 8 Turn in water tank cover and put the water tank into the water channel as figure(7). Figure(7) Turn on the power ,turn the switch clockwisely to the position of silk ,the indicator is to be on and emerge the steam .With different material of cloth ,adjust the knob. When the ironing is finished ,turn off the switch and pull off the power plug.
-
Page 9: Clean And Storage
3.IRONING METHOD of the garment. DO NOT allow kinks to form in the hose at any time. 4.CLEAN AND STORAGE 1)Turn off the power switch and unplug the power cord. 2)Once the machine is completely cooled (at least 30 minutes). 3) Remove the water tank, open the water tank knob, pour out water from the water tank, wash it and place the water tank to it's position. -
Page 10: Safety Instructions
5.SAFETY INSTRUCTIONS Use the correct power supply voltage and frequency 220-240v~50Hz Do not share with other high-power electrical home appliance. Do not immerse the machine, power cord and plug in the water. Before using the machine, first pour the cold water, never add hot water otherwise water tank would be deformed, always pay attention for it’s water level when you use. - Page 11 6.TECHNIQUE SPECIFICATIONS Rated voltage:220V-240V Rated frequency:50Hz Rated power:1800W Capacity:1.6L Nozzle steam temperature:98 F Out of steam:36g/min Continuous outlet time:45 minutes CIRCUIT DIAGRAM thermal protection switch 240¡ switches heating pipes thermostats...
-
Page 12: Trouble Shooting 1
7.TROUBLE SHOOTING Usual problem Reason Treatment Whe ther the power plug Insert the power plug is inserted or not With out steam(The Thermal cut-off damaged Ask professional personnel or not for check and maintenance indicate lamp is off) Whether the internal wires Ask professional personnel Are off or not for check and maintenance...
