Evantair EV2075CF Instruction Manual

Ceiling Fan: Model EV2075CF
INSTRUCTION MANUAL – IMPORTANT INSTRUCTIONS RETAIN FOR
FUTURE USE - READ FULLY BEFORE USE
Pictures or product specifications may vary slightly from those indicated due to ongoing product improvement.
________________________________________________

Safety Instructions

WARNING! A suitably qualified person - connection to the mains supply required, must install this fan.
This fan and associated equipment must be installed by a person who is suitably qualified to install electrical equipment that is
permanently connected to the mains 230V mains power system as a condition of warranty. No responsibility will be taken for any
damage or physical harm caused by incorrect installation.
Carefully read this manual in full before using this electric fan.
Ensure that you know how the fan functions and how to operate it. Maintain the fan in accordance with the instructions to ensure that it
functions properly. Keep this manual with the fan. If the fan is to be used by a third party, this instruction manual must be supplied with
it. The safety instructions do not by themselves eliminate any danger completely and proper accident prevention measures must always
be used. No liability can be accepted for any damage caused by non -compliance with these instructions or any other improper
use or mishandling.

Package Contents

1 x Instruction Manual
1 x Fan Motor Assembly
1 x Set Fan Blades (4)
1 x Extension Tube
1 x Ceiling Base Plate Assembly
1 x Pack Blade Brackets (4)
1 x Pack Screws - Screw pack contains
4 Ceiling Base fixing screw / 4 split washer / 4 washer
12 Blade bracket fixing short bolt / 12 washer / 12 nut (1 set spare)
CAUTION. Confirm all parts before disposing of packaging. Safely dispose of all plastic bags and
other packaging components. They may be potentially dangerous to children.

Assembly and Installation

Unpack and confirm all components.
This fan should be connected to a 10amp circuit controlled by a dedicated isolating switch, suitable means for
disconnection must be incorporated in the fixed wiring circuit and all work is to be completed in accordance with the
current wiring rules. There is an OFF position on the pull cord switch located on the motor assembly however this does
not disconnect the fan from the mains supply permanently.
WARNING! Ensure the power is OFF before connecting to the mains supply.
Step 1. Fit blade bracket to each blade. Note. Blade decorative screen should face downwards on finished product. Attach blade bracket
to the blade as shown in fig 1 and fig 2.
Step 2. Attach blades to motor assembly as shown in fig 3.
Step 3. Remove base cover from base plate.
Step 4. Screw base plate to ceiling using the screws supplied.
Step 5. Connect mains supply wires to terminal block (P - N - E). Warning. Ensure power is OFF. This appliance must be earthed.
Step 6. Place ceiling base cover over motor wires as shown in fig 4.
Step 7. Remove the fixing bolt and cir-clip from the lower end of the extension tube.
Step 8. Place the extension tube carefully over the fan motor wires, pull fully out the top of the tube and attach the extension tube to
the motor assembly. Fit the cir-clip to the securing bolt as shown in fig 4.
Step 9. Connect the fan motor wiring to the terminal block. Ensure all earth wires are securely connected.
