Summary of Contents for Clarity CCE3066
-
Page 2: Table Of Contents
Page CONTENTS Contents Safety Instruction Installation Using the detachable front panel Wring Connection Operation General Operations Radio Operations RDS (Radio Data System) Operations CD Operations Disc Notes Specifications Trouble Shooting... -
Page 3: Safety Instruction
Safety Instructions CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE ANY COVERS. NO USER-SERVICEABLE PARTS INSIDE, REFER ANY SERVICING TO QUALIFIED SERVICE PERSONNEL. IMPORTANT SAFETY INSTRUCTIONS • Read and keep these instructions available for future reference. • The unit must only be connected to a 12 Volt D.C. -
Page 4: Installation
Take Out Screw Before Installation Installation Before install the unit, please remove the two screws. Notes: - Choose the mounting location where the unit will not interfere with the normal driving function of the driver. - Before finally installing the unit, connect the wiring temporarily and make sure it is all connected up properly and the unit and the 1. - Page 5 6. Mount the sleeve by inserting the sleeve 10. Reconnect the cable to the vehicle into the opening of the dashboard and bend battery's negative (-) terminal. Then open the tabs located around the sleeve replace the outer trim ring and install the with a screwdriver.
-
Page 6: Using The Detachable Front Panel
Using The Detachable Front Panel DIN REAR-MOUNT (Method B) REMOVING AND PROTECTING If your vehicle is a Nissan, Toyota, follow DETACHABLE FRONT PANEL this mounting instruction. Use the screw The front panel of the unit may be removed holes marked T (Toyota), N (Nissan) as a theft deterrent. - Page 7 Wiring Diagram FOR 4X15W SYSTEM WARNING： Be sure to keep speaker wiring isolated/not grounding and pay attention to particular wiring configurations in VW, Audi and Vauxhall vehicles When connecting！...
-
Page 8: Operation
Operations Location and function of keys Front panel : The car radio after removing the front panel: 12. AF button 1. Volume knob (when rotate) 13. EQ/TA button SEL button 14. 6 button 2. Liquid crystal display 15. 5 button 3. -
Page 9: General Operations
General Operations BASIC OPERATION station with traffic announcements. TURNING ON/OFF THE UNIT TA ALARM: No automatic station Press /MUTE button (22) to switch on search. The unit sounds a beep the unit. When system is on, press and tone if no traffic information is received and hold /MUTE button (22) to turn off the NO TP/TA is displayed. -
Page 10: Radio Operations
9) REG ON/OFF ESP FUNCTION Use the volume knob (1) to set REG The unit can be shockproof about ten ON or OFF. seconds. AUXILIARY INPUT Some stations split their programs at The unit can be connected to a portable certain times into regional programs audio player through the auxiliary input jack with different contents. -
Page 11: Rds (Radio Data System) Operations
Press for several seconds until “MANUAL” - Using PTY to Select Program appears on the display, the manual tuning Press PTY button (11) once to mode is selected. If both buttons have not select the PTY group. Then rotate been pressed for several seconds, they will the volume knob (1) to select the return to seek tuning mode and “AUTO”... -
Page 12: Cd Operations
CD Operations PLAYING TRACKS IN RANDOM Press SHF button (16) to play all tracks on SWITCHING TO CD MODE CD in random order. Press again to cancel If there is no CD disc inserted in the driver: the function. Gently insert the disc with the printed side When playing CD disc, press and hold uppermost into the CD compartment until SHF button (16) to play all tracks in... - Page 13 3. Depending on the recording status, conditions disc equipment used for the recording, some CD-Rs/CD-RWs may not be played on this unit. (see *1) *1: To have more reliable play back, please see following recommendations: a: Use CD-RWs with speed 1x to 4x and write with speed 1x to 2x.
-
Page 14: Specifications
Specifications GENERAL Power Supply Requirements : DC 12 Volts, Negative Ground Chassis Dimensions : 178 (W) x 160 (D) x 50 (H) Tone Controls Bass (at 100 Hz) : ±10 dB Treble (at 10 kHz) : ±10 dB Maximum Output Power : 4x15 watts Current Drain : 5 Ampere (max.) -
Page 15: Trouble Shooting
Trouble Shooting Before going through the checklist, check wiring connection. If any of the problems persist after checklist has been made, consult your nearest service dealer. Symptom Cause Solution The car ignition switch is If the power supply is No power. not on.
