Page 1
CONGRATULATIONS! You are now the owner of an AERO AE-1 wireless controller! The AERO lets you control the parameters and presets of existing and future Aalberg Audio effects pedals. Like the EK-1 EKKO Delay Pedal, RO-1 ROM Reverb Pedal or the TR-1 TRYM Tremolo Pedal (purchased separately).
Included in this package: AERO AE-1 Wireless Controller Quick start guide USB charging cable Velcro pads - 1 black, 1 transparent Surface cleaner sachet Mounting clip GETTING STARTED You can attach the AERO to your guitar strap or belt using the included clip with Velcro.
Page 3
CONTROLS ON/OFF Turn the power on/off PRESETS Store/recall your favorite settings including: parameter levels, bypass status for pedal (on/off), active parameter for wireless control (FX- SELECT) STORE: Press and hold one of the three preset buttons (‘I’,’II’ or ‘III’) for 2 seconds (Pedal will light up for one second to indicate that the preset has been stored) RECALL: Press one of the preset buttons to recall the previously stored preset...
Page 4
for 2 seconds to toogle between bypass ON and OFF (*The pedal with an active parameter lit up) USB INPUT Use the attached USB-cable to charge your AERO’s rechargeable battery using a standard 5V cell phone charger or one of the USB ports on your computer...
SPECIFICATIONS Power 5V rechargeable Lithium-ion polymer battery, 200 mAh (typical) Battery life Up to 30 hours Battery charging time Approx. 2 hours Range (wireless transmission) Up to 30 meters (98 feet) Connector USB input (micro USB) for battery charging Controls Presets (I, II, and III), prev/next parameter, power ON/OFF, rotary knob, rotary know pushbutton Led Indicator...
Page 7
BATTERY The AERO uses a 5V rechargeable Lithium-ion polymer battery. We recommend that you charge the battery fully before first time use. The charging time is approx. 2 hours. You can charge it through the USB-input found on the back of the AERO using a standard micro- USB cable (included in the AERO package).
3. Download the app on your mobile device and launch the app. 4. The Aalberg Audio device set to update mode will now show up in a list in the AALBERG UPDATER, and you can check the current revision of the software found on the device.
WIRELESS CONTROL – PAIRING CURRENTLY: ONE AERO-ONE PEDAL COMMUNICATION ONLY! ONE AERO – MULTIPLE PEDALS READY AFTER SUMMER 2015 In order to control your Aalberg effects pedal using the AERO wireless controller (optional) you need to pair the devices. Below is a step-by-step guide: 1.
Page 10
iv. Next to lowermost LED in mid row lights up when AERO in pairing mode is detected v. Repeat step i-iv for any additional Aalberg effects pedals 2. Confirm pairing: a. When you have repeated the above steps for all of your Aalberg pedals, you need to press and hold the rotary knob button for 3 seconds, then release button.
DISCLAIMERS All use of our products is undertaken at your own risk and expense and Aalberg Audio cannot be held liable for any direct or indirect losses or cost incurred through use, default or malfunction of our products. Repair or replacement of defective units under our warranty provisions serve as the sole remedy in the unlikely event that our products does not comply with product specifications.
Page 12
If the product is altered or repaired by someone unauthorized by Aalberg Audio the warranty is no longer valid. Stores and distributors must always check products before sending them to Aalberg Audio for repairs. Please...
Page 13
Five years later, after lots of testing and prototyping we are proud to introduce the world’s first EKKO EK-1 Delay Pedal with the AERO AE-1 Wireless Controller. (Below you can see the different prototyping stages (from left to right): “The...
Page 14
Aalberg Audio accept and follow these regulations and directives. ABOUT AALBERG AUDIO Aalberg Audio AS is located in Trondheim, Norway. We produce wireless guitar effects with accompanying hardware and software. Please don't hesitate to contact us if you have any...
