Moda flame GF101301 User Manual page 5

2. Mount the mounting bar unit to the wall using screws, and wall plugs.
3. Attach the fireplace body onto the mounting bar unit. Follow the arrows:
4. Place the burner into the burning chamber of the fireplace body.
WARNING: Risk of fire, Minimum 1.8 cm air space clearance to insulation and
building materials (the back wall) must be maintained.
OPERATION INSTRUCTIONS
Step 1: Open the cover of the burner reservoir completely by using the control
tool. Fill the burner with the ethanol, pay attention to the "Max" line.
5 Moda Flame Faro Wall Mounted Ethanol Fireplace©
Instruction Manual
