Summary of Contents for Dorma M6D
- Page 1 DORMA Installation Manual Terminal M6D...
-
Page 3: Table Of Contents
1 .1 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 3 .1 External connections of the M6D . . . . . . . . . . . . . 15 1 .2 Intended use . -
Page 4: General
. quential damages due to incorrect or incomplete informa- DORMA does not provide any licences to its own or to third tion . party patents or other protected rights with this document . -
Page 5: Preface
1. General 1.1 Preface This installation manual is intended to assist you in con- necting and commissioning the M6D . 1.2 Intended use The device is used as a time recording and access control terminal . Further details are described in chapter 1 .6 . -
Page 6: Further Source Of Information
The data recorded are sent via an RS485 bus to a host ter- minal for evaluation . After they have been processed in the host, the result is sent via the RS485 to the M6D terminal and shown visually on a two-line display . -
Page 7: Components Supplied
1. General 1.7 Components supplied A M6D D 2 x Spax screws (4 .5 x 35 mm) B Assembly instructions E 2 x dowels (6 mm) C 1 x cable binder 1 x drilling template DORMA Installation Manual Terminal M6D 1.8 Assembly accessories (optional) -
Page 8: Assembly
2. Assembly 2.1 Terminal design The terminal consists of the top casing section and the bottom casing section . The models are explained in the next chapter . Top section Bottom section 2.2 Casing variants Contactless reader (PXL) Swipe reader (DZL) -
Page 9: Dimensions
2. Assembly 2.3 Dimensions 176,3 mm... -
Page 10: Opening And Closing The Terminal
2. Assembly 2.4 Opening and closing the terminal The unlocking mechanism is accessed through the hole on the underside of the terminal . If there is a lock in this hole, remove the lock first . To open the casing you need a rod-shaped tool (such as a screwdriver) which you insert through the unlocking hole . -
Page 11: Assembly Preparations
For each installation type, the relevant specifications on the position of the cable infeed and cable length must be observed . M6D terminal with contactless readers To prevent interference from both sides, the two devices with contactless readers may not be... -
Page 12: Assembly With Flush Cabling
Refer to the illustration so that the cable emerges from the Casing contour wall correctly at the knock-out section on the back side of the M6D . The box may not protrude above the contour of the underside of the casing . Underside of the casing... -
Page 13: Inclined Console
. Now the inclined console can be screwed onto the wall . Afterward, insert the cables into the opening in the rear panel of the terminal . Finally, the M6D can be screwed onto the inclined console with the screws included with delivery . -
Page 14: Inclined Console With 230 V Supply Voltage
2.8 Inclined console with 230 V supply voltage To power the M6D with 230 V supply voltage, the inclined console can be ordered with a built-in power supply unit . To create the connection, connect the phase and the neutral wire directly to the power supply unit . -
Page 15: Connection Variants
ST103 ST102 3.2 Power supply The power supply for the M6D is connected to terminal 24 V and 0 V of the ST102 . ST103 serves as the connec- If the M6D-terminal is supplied with tion for other bus devices . -
Page 16: Commissioning
If switch SW201/6 = on, the test mode is activated if no communication occurs at the RS485 interface after the M6D is switched on . If the M6D recognises communication at the RS485 interface, it switches into normal mode . -
Page 17: Connection Resistor
The bus connection resistors must be switched on if the M6D is the first or last bus device . 4.2 Tampering protection A light barrier for tampering protection is integrated into the M6D, which sends a signal to the higher level terminal if the casing is opened . -
Page 18: Reader Settings
Switch 6 is set ex works, and its position should not be changed . An incorrect setting can make the reader unusable! Configuration protection may only be deactivated if the "Load IdendAssembler" system parameter is activated in DORMA 2) Interface MATRIX . SW101 Interface... -
Page 19: Maintenance
5. Maintenance 5.1 Fuses In the event that the fuse (SI101 basic card) needs to be replaced, there is a spare fuse at the bottom right of the basic module . The fuse can be re-ordered using art . no .1900001797488 (Littlefuse 0154 .750 DRT, 750mA) . -
Page 20: Eu Declaration Of Conformity
EG Konformitätserklärung EC Declaration of Conformity CE Déclaration de conformité... - Page 21 EG Konformitätserklärung EC Declaration of Conformity CE Déclaration de conformité...
- Page 22 EG Konformitätserklärung EC Declaration of Conformity CE Déclaration de conformité...
- Page 23 Notes...
-
Page 24: Technical Data
DORMA Time + Access GmbH Postfach 21 01 85 • D-53156 Bonn • Mainzer Straße 36-52 • D-53179 Bonn Tel . +49 (0) 2 28/85 54-0 • Fax +49 (0) 2 28/85 84-1 75 • www .dorma-time-access .de DORMA GmbH + Co . KG Postfach 40 09 •...
