Summary of Contents for Audiopole M6
- Page 1 6 CHANNEL MIC/LINE MIXER USER’S MANUAL MIC/LINE MIXER TRIM TRIM ...
-
Page 2: Important Safety Instructions
Important Safety Instructions This symbol, wherever used, alerts you to the presence of un-insulated and dangerous voltages within the product enclosure. These are voltages that may be sufficient to constitute the risk of electric shock or death. This symbol, wherever used, alerts you to important operating and maintenance instructions. POWER SUPPLY Ensure that the insource voltage (AC outlet) matches the voltage rating of the product. -
Page 3: Table Of Contents
Index 1. Introduction ……………………………………………………………………….. 2. Features …………………………………………………………………………… 3. Controls ………………..………………………………………………………….. 4. Installation Tips …………………………………………………………………… 5. Appendix ……………………………………………………………………..….… 6. Preset List……………………………………………………….……...…………. 7. Hookup Diagram………………………………………………………………….. 8. Wire Connections ……………………………………………………………….… 11 9. Technical Specifications………………………………………….…………..…… 12 10. Block Diagram ………………………………………………………………..…… 13 11. Warranty …………………………………………………………………………… 14 12. ... -
Page 4: Introduction
Introduction Thank you for purchasing the AUDIOPOLE M6 Mic/Line mixer with 24 bit digital multi-effect. The M6 is a remarkable compact mixing desk that does not find many equal in the market today. With 2 microphone and 2 stereo Mine-level inputs for small live performances, small studio recording and general PA applications, M6 also includes a 24-bit digital multi-effect with 16 factory Presets and separate level for digital reverb. -
Page 5: Controls
FRONT PANEL 1 - MIC INPUT The M6 is equipped with 2 ultra low-noise pre-amps featuring a 60 dB gain range and 115 dB of S/N ratio. A 48V phantom power is available for condenser or electret microphones. The phantom power must be switched off when using dynamic microphones. - Page 6 Controls 8 - MAIN OUT This stereo output is controlled by the Main Mix Level on Master section and will send the audio signal to an amplifier or a pair of active speakers. The output level can be varied from -∝ et +15 dB. 9 - 2 TRACK IN Use this input to connect a CD, Tape, DAT, MP3 player or any other line-level source.
- Page 7 16 - PEAK This red LED will let you know about the status of the signals processed into M6. Connect a microphone or an instrument to M6 and sing/play at normal volume. Set the level control of that channel so that the PEAK LED lights-up only occasionally.
-
Page 8: Installation Tips
Your M6 includes a quite unique and innovative multi-effects with 24-bit resolution and high dynamic range. Unlike other multi-effects where the presets are available in a sequence and vice a single control, M6 multi- effect unit is organized with 16 presets control and relative Level control for vibrato and modulation control such as Chorus and Flanger. -
Page 9: Appendix
When your M6 leaves the factory, the AUX bus of all input channel is wired post-fader. In this way, the Aux bus can be used for the internal or external multi-effect. -
Page 10: Hookup Diagram
Hookup Diagram SMALL GIG Effect Processor Mics Stage Monitors CD Player MIC/LINE MIXER Recorder Drum Machine Keyboards Powered Speakers BAR, RESTAURANT Headphones Wireless Mics Powered Speakers Video Mics CD Player MIC/LINE MIXER Recorder Drum Machine Guitar Powered Speakers DI Box 10 ... -
Page 11: Wire Connections
Wire Connections Either 1/4’’ TRS phone jack or XLR connector can be wired in balanced and unbalanced modes, which will be determined by the actual application status, please wire your system as the following wiring examples: For ¼’’ Phone jack TRS Type Balanced TS Type Unbalanced TRS Type Unbalanced... -
Page 12: Technical Specifications
Technical Specifications Mono Mic input Elect. balanced Frequency response 10 Hz - 55 kHz, +/- 3 dB Distortion (THD & N) 0,005% @ 4 dBu, 1 kHz Gain 0 dB - 60 dB (MIC) 115 dB Inputs Line input Elect. -
Page 13: Block Diagram
Block Diagram 13 ... -
Page 14: Warranty
2. The device was not diverted from its destination, either voluntary or accidental, and suffered no deterioration or modification other than those described here or explicitly authorized by AUDIOPOLE. 3. All modifications or repairs have been carried out by an authorized service station. -
Page 15: Notes
Notes 15 ... - Page 16 22, rue Édouard Buffard, Z.A.C. de la Charbonnière, Montévrain - 77771 Marne-la-Vallée Cedex 4 - France Tél : + 33 (0)1 60 54 32 00 - Fax : + 33 (0) 1 60 54 31 90 - www.audiopole-pa.com - www.audiopole.fr...
