- Page 1 MAP Series Audio Mixer Installation Guide Model: iFlex 620 Firmware Rev: 2.065 IP Address: 192.168.0.150 Subnet Mask: 256.256.256.0 Serial Number: 2051A306D2 Date: 5/12/2014 Time: 11:27:14...
-
Page 2: Front Panel Display
To navigate through the display screens, swipe either left or right using the touch-screen**. The Ivie splash screen is the default screen on system boot-up. This is a low intensity display for low-light environments. -
Page 3: Rear Panel
Rear Panel - MAP 6L AC Mains The AC Mains input is a switching power supply that will accept 100V to 240V, and 50/60Hz. Receptacle is fused with a 5X20MM, 1A 250VAC Slo-Blo fuse. Spare fuse included. RS232 The serial port allows 3rd-party controllers to configure/control/monitor the MAP unit. This port also is also capable of sending data (in Decimal, Hexidecimal, ASCII, Binary, BYTES, etc.) to control 3rd-party devices. - Page 4 USB. Logic I/O The Logic I/O ports on the rear panel of a MAP unit are RS-485 communication ports for Ivie SmartControls © as well as physical controls, such as potentiometers, contact closures, and LED outputs. Any Ivie SmartCon-...
- Page 5 Control Inputs Each control port can support either RS485 smart controls, or 1 analog switch, 1 analog potentiometer, and 1 logic output. The number of analog controls, and logic outputs can be dramatically increased by the use of an RMPC I/O expander. RMPC expanders allow a 4, 8, or 12 fold expansion of the number of analog controls, and logic outputs, and combine them into a smart control with a single CAT5E or better cable back to the MAP device control port.
- Page 6 Selectors Analog selector controls are wired with pin 3 being the reference voltage (+10V), pin 2 being the wiper, and pin 7 or 8 being the ground. A resistance ladder is added with the value of the resistors being recommended at 2.2kOhms.
- Page 7 Audio cable connections are made via euro-block (or Phoenix) pluggable connectors (supplied with the MAP unit). Inputs can be either 2 or 3 wire connections as shown below. Unbalanced inputs (2 wire) should have a jumper installed between the sheild pin and the negative pin of the connector to reduce noise. Balanced outputs (3 wire) should not connect the shield at the receiving device.
