  • Page 1 © Leitch Technology International Inc. 1999 The copyright in this document is the property of Leitch Technology International Inc and it may not be copied, reproduced, used for manufacture, nor the contents divulged without the express permission in writing of Leitch Technology International Inc.

  • Page 2: Safety Considerations

    This Leitch product is warranted against defects in materials and workmanship for a period of one year from the date of invoice. During the warranty period, Leitch will, at its option, either repair or replace products which prove to be defective.
  • Page 3 Before Applying Power Verify that the product is configured to match the available main power source per the input power configuration instructions provided in this manual. Servicing These servicing instructions are for use by qualified personnel only. To reduce the risk of electric shock, do not perform any servicing other than that contained in the Operating Instructions unless you are qualified to do so.
  • Page 4 CONTENTS 1. GENERAL DESCRIPTION ................... 6 2. INSTALLATION......................7 3. SPECIFICATION ......................8...

  • Page 5: General Description

    1. General Description The 6004T/C 4U chassis is designed to house up to sixteen vertically mounted Genesis cards. The unit is designed to be as versatile and comprehensive as possible. This encompasses the need for a modular platform to easily accommodate a wide variety of card and connector types and to be quickly configurable.
  • Page 6 2. Installation To install the 6004T/C the following items are needed:- 6004T/C 4U rack 6094C Power Supply Module IEC mains cable (10A 250Vac) Remove all packing material. Check that the correctly rated fuse is installed (6.3A slow blow 240Vac) in each IEC mains inlet.
  • Page 7 3. Specification Mechanical Height 178.00mm Width 440.00mm Depth 355.00mm Weight (6004T) 12.55Kg’s (6094C) 1.50Kg Operating Temp 0°C to 40°C Storage Temp -10°C to 60°C Electrical Fuse 6.3A Slow Blow 240Vac Power Cord Straight 3 Pin Female IEC 320 250Vac 10A 125Vac 10A Power Supply (6094C) Input Voltage...
  • Page 8 Top View of 6094C Power Supply Module Led: Green = Power Good Fuse Red = Over Temp Rear View of 6094C Power Supply Module 6094C PSU Rearconnector Pin Out Row d Pin Function Row z Pin Function Power Fail +6.5Vdc I2C Data -7.5Vdc I2C Clock...
