Summary of Contents for SAC AE0596
- Page 1 AE0596 SAC 60m HDMI over Single Cat5/5e/6/7 U S E R M A N U A L...
- Page 2 Thank you for purchasing this Extender. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual safe for future reference. The AE0596 Extender uses a cat 5/5E/6/7 cable up to 60 meters instead of using a Single HDMI cable to transmit high definition signal, cutting down cost.
- Page 3 Accessories 1、2 x 5V Power Adapter 2、1 x User manual Power Adaptor Physical Connection Picture： Figure 1.0 Front Panel Picture Cat: Use one cat to connect the sender and the receiver. Switcher: This button needs to be pressed if digital display cannot read EDID info Steps to use the Switcher button: 1.
- Page 4 Figure 1.1 Rear and side picture HDMI IN: Signal Source Input. HDMI OUT: To connect receiver to HDTV or other display. DC 5V: 5V DC-DC Power Adaptor Interface. Operating and Connecting： Connect one HDMI cable up to 15 meters between source device and TX Extender Connect one HDMI cable up to 15 meters between sink device and RX Extender Connect one cat5e/6/7(recommended cat6 or 7) to the sender and receiver, the cable can be up to 60m in length...
- Page 5 SPECIFICATIONS: AE0596 Length of CAT cable between Rx and TX…..……………….…………………….Up to 60 meters HDMI Input…..…………………..……24/50/60fps/1080p/1080i/720p/576p/576i/480p/480i Support audio format input..………..…DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD HDMI Output…..…………….…...…………24/50/60fps/1080p/1080i/720p/576p/576i/480p/480i Support audio format output...……. ……………………..………LPCM7.1/DTS/Dolby-AC3/DSD Max bandwidth……………………………………………………..…….……………………225MHz Max band rate……………….…….………………….……………...………………………6.75Gbps Input Video signal………….…………………………..…………..…………….… 0.5~1.5Volts p-p Output DDC signal ………………………………………………………………… 5Volts p-p (TT1L) Input/Output HDMI cable distance………….………………...≤15m AWG26 HDMI standard cable...
- Page 6 Notes: Please only use the machine in accordance with instructions to ensure the machine has a long life span. 1. The machine should always be placed in a position away from damp, hot, dusty and erosive environments. 2. All parts should be free from strong vibrations, impacts, and the possibility of falling. 3.
