  • Page 2 The Red Pawz CMR280 comes configured for FPV Racing. Configuration as follows: 1. A fully built and tested CMR280 frame made from CNC cut 3K carbon fiber. 2. Modular and removable 32-BIT. MultiWii flight control pre-programmed. 3. 4 x Red Pawz 2204-2300kv motor 4.
  • Page 3 Optional spare parts: 1. 3D FPV Goggles + battery 2. Lipo: Gens ace 2200mah 3S 25C Lipo pack 3. RC TX/RX: The RTF frame does not come with a RC transmitter or RX. Any 2.4 Transmitter/RX or even LRS will work. 4.

  • Page 4: Table Of Contents

    NEVER walk back to the pilot area with a powered-up quad......... 16 POSITION the launch and landing zone..............16 ALWAY Swarn in-air pilots before powering up a quad...........16 Looking after your CMR280......................17 Snow and Water........................17 The Sun.............................17 Dirt..............................18...

  • Page 5: Disclaim

    ,when you are working on a quad with the battery connected,it is highly recommended to remove all props. Any product damage cause by not doing so, Red Pawz will not be liable. If you find the product is damaged when you received it, please contact reseller first, they will replace or repair the product.

  • Page 6: The Description Of Cmr280

    The Description of CMR280 Red Pawz CMR280, hereinafter referred to: "CMR280". The default configuration is designed for FPV racing . This is just a basic characteristics of the design, The greatest charm is offer a completely open source platform to the players, professionals and those who do not have enough equipment but wisdom enough.

  • Page 7: Highly Integrated Independent Pcba

    Highly integrated independent PCBA Highly integrated PCBA with modular ESCs and flight controller for convenient maintenance. This PCBA will be the heart of our future 250 and 300 quad also.

  • Page 8: Flight Controller

    Flight Controller The Flight control is optimized for Multiwii. It can be flashing to the latest MWC firmware, but you must be able to understand the program .If you want to take advantage of optimizing for the best flight experience. R/C Transmitter Control Modes Mode 1 - Europe Mode 2 - USA...

  • Page 9: Flight Modes

    Flight Modes Five flight modes are configured . The default mode is Horiz . There modes are as follows: ANGLE: Stable mode if the PID values are correctly adjusted and the gyro and the accelerometers have been calibrated and trimmed. According to MultiWii developers ANGLE MODE is virtually obsolete, HORIZON MODE is preferable in most cases.

  • Page 10: Multiwii Configurator Connection

    Holds the pilots 2D perspective as reference, MAG does not, both give a drift free tail. Multiwii Configurator Connection Hook up a computer via a standard Micro USB cable , to the connector on the side of CMR280 . Then open the MultiWii Configurator .

  • Page 11: Simonk Escs

    20A SimonK ESCs 1. What is “Firmware”? Generally speaking, firmware is code program built into the micro controller unit (MCU) of electronic products. After the micro controller unit is powered up, the firmware will control MCU’s signals. Since the factory will download the firmware to the MCU’s Flash memory, many people call this process “Flashing”.
  • Page 12 For modelers who do not have any knowledge about MCU, the flashing process is difficult. Or some model flyers just need their models fly well and do not care about flashes. If you are in one of them, you can choose Red Pawz already flashed ESC. 6. Install your ESCs We believe it is easy for you to install ESCs to multi-rotor platform.
  • Page 13 8. How to do throttle calibration Normally, you do not need to do throttle calibration for new multicopter ESCs. However, in some special cases, you still need to do it. Remove your props, and disconnect the battery. Push your radio throttle to maximum, connect the flight battery, wait for the 3 beeps(di da di), wait for 1s, you will hear a short beep(di).

  • Page 14: Camera

    Camera FPV Camera The default FPV camera is 620TVL low lux CCD Camera. Sensor Chip:1/3 inch HD Color CMOS Video Standards: PAL Effective Pixels: PAL=720(H)*576(V) Definition: 600TV Lines(HD) Lowest Lux: 0.01 Lux Video Output: 1.0Vp-p/75Ω Power consumption: 40MA ±10% Operating Voltage: DC5-15V ±10% Size: 21*21*28mm±0.5mm Operating Temperature: 0°C~45°C RH95% Max Weight: 15g...

  • Page 15: Hd Camera (Gopro/Mobius)

    HD Camera (GoPro/Mobius) HD Camera is optional accessory . There is special design on CMR280 allow you mounting HD action camera ,such as GoPro and Mobius .

  • Page 16: Dual Antennas

    Dual Antennas Powerful video transmission system using 5.8G 32 Channel transmitter . Dual antennas on the tail and bottom to enhance polarization for a stronger signal.

  • Page 17: Osd (On Screen Display)

    OSD (On Screen Display) The Welcome Screen ARMED...
  • Page 18 DISARMED Flight Status...
  • Page 19 Flight Data Statistics...

  • Page 20: Optional 3D Goggles

    Optional 3D Goggles. To get the ultimate FPV flying experience it is better to choose our 3D goggles. Its equipped with dual antennas, 32 frequency points for connection, and AV IN function.Inside with two displays ,adopt frequency hopping tech ,provide 3D flight feeling to the user . It also include a battery tray for NP-F330, NP-F530/F550/F570, NP-F730/F750/F770, NP-F930/F950/F960/F970.

  • Page 21: Connectors And Switches

    Connectors and Switches 1) USB Connector ,apply for configure the flight controller and upgrade the firmware. Note that to use the USB connector ,a battery must be connected also when you mapping the receiver , program motor parameter and etc . 2) OSD button, used to restart OSD 3) LED board button ,used to change video Tx frequency point ,and also to change video Tx band .
  • Page 22 , PPM receiver :CH1 GND +5V . Disable PPM input ,it will be change to PWM receiver . 7) XT-60 Battery Connector and special protection . The pre-installed XT60 plug is compatible with most batteries . CMR280 have a special design ,if large forces are applied to the plug, it will not damage the circuit board.

  • Page 23: Anti-Vibrations Rubber Ball

    Navigation LED lights Switch. Two Red LED lights under each of front arms to indicate the head . Two Green LED lights under each of behind arms. Anti-Vibrations Rubber Ball The PCBA and the fuselage are shock isolated. This helps with shock absorption and can also protect the PCBA when the aircraft crash.

  • Page 24: Specification

    Specification CMR280 Key Characteristics Endurance 18mins hover / Highly dependent upon battery and flying style Battery Suggest 2200mAh 3S 25C Weight And Measures 400g 280mm wheelbase Operating Temperature : -10°C to +50°C (You have to keep the IMU warm if you want to use it under low temperature, could be -10°C or...

  • Page 25: Channel Mapping And Arm Fc

    Channel Mapping and Arm FC The RTF frame does not come with a RC transmitter or RX. Any 2.4 Transmitter/RX or even LRS will work. Channel corresponding road map as follow : Mode 1 : Mode 2/3/4 : Brown wire - ELEV Violet wire - AILE White wire - THRO Orange wire - RUDD...

  • Page 27: Firmware Upgrades

    Firmware Upgrades...

  • Page 28: Flying With Competitors

    Flying with competitors If a few simple rules are followed, quad racing can be a lot of fun. 1) NEVER land near another pilot. This is an absolutely golden rule. Landing your quad near another pilot, especially one who is at a significant distance, is like screaming in the ear of someone listening to a whisper at the other side of a room.

  • Page 29: Looking After Your Cmr280

    Even though most of the PCBs in the CMR280 are coated with a conformal coating, which does offer some protection from water, it is not recommended to get the CMR280 wet, even if that water comes in the form of snow.

  • Page 30: Support

    Support First line of support is handled by the reseller. If you encounter any problems with your Red Pawz product please contact them first. they will replace or repair the product. Any user’s modifications and disassembly, Red Pawz will not be liable .
