Chefmate
14 in. Portable
Charcoal Grill
dpci # 009-07-0776
stock # CBT1414T
>> assembly instructions
WARNING
FOR YOUR SAFETY:
For Outdoor Use Only
(outside any enclosure)
®
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION. PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
If you are assembling this unit for someone else, give this
manual to him or her to read and save for future reference.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for BlueRhino Chefmate
Summary of Contents for BlueRhino Chefmate
-
Page 1: Charcoal Grill
Chefmate ® 14 in. Portable Charcoal Grill dpci # 009-07-0776 stock # CBT1414T >> assembly instructions WARNING THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FOR YOUR SAFETY: FUTURE REFERENCE. For Outdoor Use Only If you are assembling this unit for someone else, give this (outside any enclosure) manual to him or her to read and save for future reference. - Page 2 Congratulations on your latest Target purchase. Now what? Don’t start sweating over this box of parts. This will be easy. We did the hard work for you. All you need to do is follow our simple instructions and you’ll be on your way to transforming your backyard in no time. Good luck—though we’re confident you won’t need it.
-
Page 3: Table Of Contents
table of contents important safeguards ........3 cleaning and care . - Page 4 important safeguards W Minimum clearance from sides and back of unit to combustible construction is 36 inches (91.4 cm). Do NOT use this appliance under any type of overhang or roof. W Do NOT use gasoline, kerosene or alcohol for lighting. W Do NOT use in an explosive atmosphere.
- Page 5 important safeguards W Always open grill lid carefully and slowly as heat and steam trapped within grill can severely burn you. W If grill has not been cleaned, a grease fire can occur that may damage the product. W Do NOT place empty cooking vessels on the appliance while in operation. W Use caution when placing anything on the grill while the appliance is in operation.
-
Page 6: Before You Begin
before you begin 1. Check for damaged or missing parts. Call 800.762.1142 to order missing parts. 2. Use the carton as a working surface to prevent product damage during assembly. 3. Gather all tools prior to assembly. tools needed (Not included) QUESTIONS? Just call 800.762.1142 for parts and service. -
Page 7: Parts
parts Re-order Item Description Number Handle 55-09-052 Air Vent 55-14-794 55-24-597 Cooking Grid 55-09-056 Lock 55-09-537 Cooking Grid Support 55-24-598 Bottom Bowl 55-24-599 Charcoal Grid 55-24-358 55-24-362 Brand Plate* 55-24-585 * Pre-assembled QUESTIONS? Just call 800.762.1142 for parts and service. For faster service, have the DPCI number ready when calling. -
Page 8: Hardware
hardware (A) x 8 (B) x 3 (C) x 8 (D) x 2 (E) x 5 Screw Screw Wing Nut Wing Nut Washer M4x10 Nickel Plated M6x25 Nickel Plated M4 Nickel Plated M6 Nickel Plated ø6 Nickel Plated Phillips Truss Head Phillips Truss Head (F) x 2 (G) x 2... -
Page 9: Assembly Instructions
step 1 DO NOT RETURN TO PLACE OF PURCHASE. For assistance, call 1.800.762.1142 toll-free. Please have your owner’s manual and DPCI number available for reference. For Easiest Assembly: • Select an area where you will assemble this product. To protect components, choose a smooth surface that’s free of cracks or openings. •... - Page 10 step 2 (A) x 1 (C) x 1 Screw Wing Nut M4x10 Nickel M4 Nickel Plated Plated Phillips Truss Head QUESTIONS? Just call 800.762.1142 for parts and service. For faster service, have the DPCI number ready when calling.
- Page 11 step 3 (D) x 2 (E) x 2 (F) x 2 (G) x 2 Wing Nut Washer Washer Lock Washer M6 Nickel Plated ø6 Nickel Plated ø6 Heat Resistant ø6 Nickel Plated QUESTIONS? Just call 800.762.1142 for parts and service. For faster service, have the DPCI number ready when calling.
- Page 12 step 4 (B) x 3 (E) x 3 Screw Washer M6x25 Nickel ø6 Nickel Plated Plated Phillips Truss Head QUESTIONS? Just call 800.762.1142 for parts and service. For faster service, have the DPCI number ready when calling.
- Page 13 step 5 (A) x 7 (C) x 7 Screw Wing Nut M4x10 Nickel M4 Nickel Plated Plated Phillips Truss Head QUESTIONS? Just call 800.762.1142 for parts and service. For faster service, have the DPCI number ready when calling.
- Page 14 step 6 QUESTIONS? Just call 800.762.1142 for parts and service. For faster service, have the DPCI number ready when calling.
- Page 15 step 7 To Lock Lid To Unlock Lid Note: Lid must be locked before transporting grill. Note: Always unlock and open lid before lighting grill. QUESTIONS? Just call 800.762.1142 for parts and service. For faster service, have the DPCI number ready when calling.
-
Page 16: Operating Instructions
operating instructions W Caution: Never use charcoal that has been pre-treated with lighter fluid. Use only a high grade plain charcoal, charcoal/wood mixture, lump charcoal or cooking wood. W CAUTION: Never add more than 2 lbs. (0.9 kg.) of charcoal. First Use 1. -
Page 17: Controlling Flare-Ups
operating instructions Turning Off 1. Allow charcoal to completely extinguish itself. W WARNING: Do NOT use water to extinguish. This can be dangerous and cause damage. 2. Dispose of the ashes in a proper location. Controlling Flare-ups: W CAUTION: Do NOT use water on a grease fire. This can cause the grease to splatter and could result in serious burns, bodily harm or other damage. -
Page 18: Cleaning And Care
cleaning and care W Caution: 1. All cleaning and maintenance should be done when grill is cool and with the ashes properly disposed. 2. Do NOT clean any grill part in a self-cleaning oven. The extreme heat will damage the finish. Notices 1. -
Page 19: Product Registration
Product Registration For faster warranty service, register your product immediately at BlueRhino.com/warranty or by calling 1.800.762.1142. Replacement Parts Replacement parts can be found at parts.BlueRhino.com or by calling 1.800.762.1142. QUESTIONS? Just call 800.762.1142 for parts and service. For faster service, have the DPCI number ready when calling. -
Page 20: Limited Warranty
Limited Warranty Blue Rhino Global Sourcing, Inc. (“Blue Rhino”) warrants to the original retail purchaser of this product, and to no other person, that if this product is assembled, maintained, and operated in accordance with the printed instructions accompanying it, then for a period of one (1) year from the date of purchase, all parts in such product shall be free from defects in material and workmanship. - Page 21 QUESTIONS? Just call 800.762.1142 for parts and service. For faster service, have the DPCI number ready when calling.
- Page 22 QUESTIONS? Just call 800.762.1142 for parts and service. For faster service, have the DPCI number ready when calling.
- Page 23 QUESTIONS? Just call 800.762.1142 for parts and service. For faster service, have the DPCI number ready when calling.
- Page 24 © Target. The Bullseye Design is a trademark of Target Brands, Inc. All rights reserved. CBT1414T-OM-102 E...
