Page 1
25 mm Lever standard) (0.9 Kg) The Henry Tool Co., Manufactured by Henry Tools 498 So. Belvoir Blvd., South Euclid, OH 44121 U.S.A. Ph: (216) 291-1011 or (800) 826-5257 ● Fax: (216) 291-5949 or (800) 303-2800 Email: daviidh@msn.com ● Website: www.Henrytools.com...
Page 2
General Operators Instructions and Service Manual MODELS 47 GL 47 GLS 47 GLSK www.HenryTools.com | Page 143 Revised 04/24/10 For additional product information visit our website.
Page 3
General Operators Instructions and Service Manual MODELS 47 GL 47 GLS 47 GLSK PART NUMBER DESCRIPTION PART NUMBER DESCRIPTION 400-G-4-GL ALUM. GOV. BACKHEAD 1100-075 3/4” WRENCH 400-G-4-GLS STEEL GOV. BACKHEAD GOVERNORS 400-G-11 FRONT BEARING PART DESCRIPTION 400-G-14-TSG GOVERNED SPINDLE AA-400-70 GOV.ASSY.
Page 4
General Operators Instructions and Service Manual MODELS 47 GL 47 GLS 47 GLSK PART NUMBER DESCRIPTION Slide front endplate (400-7) over spindle and 510075 REPAIR KIT : Includes (1)400- onto front bearing (400-G-11). G-11 Bearing, (1)400-9 Secure motor assembly into vise vertically Bearing, (5)400-6 Blades, with output in the downward direction.
Page 5
General Operators Instructions and Service Manual MODELS 47 GL 47 GLS 47 GLSK After mounting a wheel or other abrasive acces- sory, the Grinder shall be run in a protected enclosure, at gradually increasing speed, for at least 60 seconds.
