- Page 1 Symmetry EN-7530 Installation Guide...
-
Page 2: Information To User
INFORMATION TO USER CAUTION RISK OF ELECTRIC SHOCK, DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol is intended to alert the user to the presence of un-insulated “dangerous voltage”... -
Page 3: Table Of Contents
Symmetry EN-7500 Series EN-7530 Installation Guide Table of Contents 1. FEATURES ......................4 2. PACKAGE CONTENTS ..................5 3. PART NAMES ....................6 3.1.Internal View ........................6 4. INSTALLATION ....................7 4.1. Installation Template ...................... 8 4.2. Manual adjustment for 3-axis movements ..............9 4.3. -
Page 4: Features
Symmetry EN-7500 Series EN-7530 Installation Guide 1. FEATURES Camera Indoor/Outdoor Fixed Dome IP Camera (Vandal Proof) High Quality Compression in real time streaming Sony 1/3” Super HAD CCD & High Quality SS-HQ1 Full Kit Chip Set Sony 1/3" Vertical Double Density Color CCD (Optional) ... -
Page 5: Package Contents
Symmetry EN-7500 Series EN-7530 Installation Guide 2. PACKAGE CONTENTS Unpack carefully and handle the equipment with care. The packaging contains: Camera DC power adaptor Extension cable (for LAN and power connector) 11 Pin terminal block Hex wrench driver Screws and Anchor blocks... -
Page 6: Part Names
Symmetry EN-7500 Series EN-7530 Installation Guide 3. PART NAMES 3.1. Internal View ④ ③ ② ① * Models herein and their appearance are subject to change ⑤ ⑥ without any prior notice. 1. 11 pin terminal block for D/I, D/O, audio, and serial communication 11 pin terminal block for D/I, D/O, Audio In /Out and serial communication. -
Page 7: Installation
Symmetry EN-7500 Series EN-7530 Installation Guide 4. INSTALLATION Connect the LAN cable, power supply cable, and the video loop out cable with the camera. Place the installation template on the ceiling. Drill three holes on the template and insert anchor blocks into the holes. -
Page 8: Installation Template
Symmetry EN-7500 Series EN-7530 Installation Guide The camera may fall off the ceiling even after the proper installation and mounting. To prevent any accident, make sure the ceiling is firm and Caution stable enough to support the camera. If any reinforcement is needed, consult with your safety personnel and proceed with the installation. -
Page 9: Manual Adjustment For 3-Axis Movements
Attribute Setting. Brightness, contrast, hue, saturation and sharpness can be adjusted. 4.4. Operating the OSD Menu To operate the OSD of camera, refer to the ”EN-7530 OSD Menu Control Manual” on the CD supplied with your manual. 9600-0545 Issue 1.1... -
Page 10: Connections
Symmetry EN-7500 Series EN-7530 Installation Guide 5. CONNECTIONS 5.1. Connectors Audio In / Out The camera has a mono audio input and a mono audio output. As the output power for the audio is low, an amplifier is needed (Do not use a headphone or earphone directly to the camera). - Page 11 Symmetry EN-7500 Series EN-7530 Installation Guide Internal Internal Output of Output of Sensor Sensor Relay Type Voltage Type Alarm (DO) connection This is a relay type output, with a maximum rating of 24VAC 500mA or 12VDC 1A Do not exceed the maximum relay rating.
- Page 12 Symmetry EN-7500 Series EN-7530 Installation Guide RS-485 The RS-485 serial port consists of TRX+(RX+) and TRX-(RX-) as shown below: 485 Device RS-485 Connection 9600-0545 Issue 1.1 Page 12 of 21...
-
Page 13: Configuration
Symmetry EN-7500 Series EN-7530 Installation Guide 6. CONFIGURATION 6.1. Set up network environment The default IP address of your IP device is 192.168.XXX.XXX. You can find the available IP address from the MAC address of your device. Please make sure the device and your PC are on the same network segment before running the installation. - Page 14 Symmetry EN-7500 Series EN-7530 Installation Guide To use the IPAdminTool and view the live video on a web page: 1. Start IPAdminTool. Names and info of currently activated devices appear as a list. 2. Right-click on the desired device and select Web view.
- Page 15 Symmetry EN-7500 Series EN-7530 Installation Guide 5. Wait for a few seconds while the web page loads. Then the live video is displayed on the main page of the web browser. 6. If the live video is not displayed and “Can not Create XMLDOMDocument Install MSXML4.0”...
-
Page 16: View Video Using Ip Address
Symmetry EN-7500 Series EN-7530 Installation Guide 6.2.2. View video using IP address View the live video on a web page using your IP device and its IP address. To have the correct IP address ready and use it on a web page: 1. -
Page 17: Appendix A: Specifications
Symmetry EN-7500 Series EN-7530 Installation Guide APPENDIX A: SPECIFICATIONS Summary Camera Module Sony 1/3” Super HAD CCD, 410K Pixel Image Sensor NTSC: 768(H) x 494(V) Effective Pixels PAL: 752(H) x 582(V) Size 1/3 inch interline transfer CCD Scanning 2:1 Interlace system NTSC: 15.734 KHz (H) 59.94 Hz(V) -
Page 18: Electrical Characteristics
Symmetry EN-7500 Series EN-7530 Installation Guide Function Digital Input/output 1/1 channel RS-485 Supported Network 10/100 Base-T Power over Ethernet Supported TCP/IP, UDP/IP, HTTP, RTSP, RTCP, RTP/UDP, RTP/TCP, Protocol SNTP, mDNS, UPnP, SMTP, SOCK, IGMP, DHCP, FTP, DDNS, SSL v2/v3, IEEE 802.1X, SSH... -
Page 19: Analytics
Symmetry EN-7500 Series EN-7530 Installation Guide Analytics Intelligent Detection (Included as Standard) High Performance Advanced Tracking Algorithm, Low False Alarm Rate Easy to Use Intuitive Web Browser Interface Detection Zones Multi-segment Polygons and Lines On-screen Display Real-time Display of Tracking Data and Events Stream or Analog video out (※Analog video out support can vary depending on the... -
Page 20: Appendix B: Power Over Ethernet
Symmetry EN-7500 Series EN-7530 Installation Guide APPENDIX POWER OVER ETHERNET The Power over Ethernet(PoE) is designed to extract power from a conventional twisted pair Category 5 Ethernet cable, conforming to the IEEE 802.3af Power-over- Ethernet (PoE) standard. IEEE 802.3af allows for two power options for Category 5 cables. -
Page 21: Appendix C: Dimensions
Symmetry EN-7500 Series EN-7530 Installation Guide APPENDIX C: DIMENSIONS (Unit: mm) 9600-0545 Issue 1.1 Page 21 of 21...
