Summary of Contents for hoxter ABRA 6
- Page 1 Installation and operating instruction ABRA 6...
-
Page 2: Table Of Contents
CONTENT INTRODUCTION Page 3 DESCRIPTION OF THE DEVICE Electronical control unit Page 4 Display Page 5 Door sensor Page 5 Air inlet flap Page 5 Hightemperature sensor Page 5 Power source adapter Page 5 INSTALLATION Door sensor intallation Page 6 Hightemperature sensor installation Page 6 Air inlet flap installation Page 7 Electronical unit connection Page 7 SETTINGS Setting of device and communication channel Page 8 Setting for UNI-product Page 9 OPERATING Informations on display Page 10 Alarms and warnings Page 11 Power source shortage Page 11 TROUBLESHOOTING Page 12... -
Page 3: Introduction
INTRODUCTION We would like to thank you for purchasing electronical fireburning control ABRA 6. Based on the temperature in the burning chamber this fireburning control optimizes combustion by precise dosage of inlet air. The installation of this product must be carried out by specialist – stove maker – only. Before you start using the device we would like to invite you to read this manual and follow the instruction inside. -
Page 4: Description Of The Device
DESCRIPTION OF THE DEVICE ELECTRONICAL FIREBURNING CONTROL UNIT • Power source adapter 12V • Electronical unit includes 9V backup battery • Heat resistance max 40°C / 104°F Description of inputs and control diode • Connector input • Connector input for door sensor for hightemperature sensor • Control diode signals closed position of the door 12V DC • Connector input S1 TK T1 12V DC for power supply • Connector input adapter... -
Page 5: Display
• Signal range between electronical control unit and display max 50m / 164 ft. • (more instruction for display unit in chapter „OPERATION“ on page 10) DOOR SENSOR • Sensor with connecting cable, lenght 4 m / 13 ft., heat resistence of the cable 180°C / 356°F (A) • Magnetic counterpart (B) • Steel hitch (only compatible with HOXTER products) (C) AIR INLET FLAP • Heat resistence of the stainless steel flap and its components max 50 °C / 122 °F • Lenght of the cable 4m / 13 ft., heat resistence of the cable 180 °C / 356 °F HIGHTEMPERATURE SENSOR • Range 0°C - 1200°C / 32°F - 2192°F • Heat resistence of the hightemperature sensor and ceramical cover max 1200 °C / 2192°F • Heat resistence of the cable 400 °C / 752°F, lenght of the cable 5 m / 16,4 ft. • Assembly lenght of the sensor is adjustable 140-160mm / 5.5 – 6.3 In. 140 - 160 mm POWER SUPPLY ADAPTER • Input 110-230V... -
Page 6: Installation
INSTALLATION DOOR SENSOR INSTALLATION Break out the indicated opening in the steel hitch (B), pull the door sensor through this hole (A) and fasten with the distance barrel (C) and a nut (D). Fasten the steel hitch with the door sensor on designed place at the frame (E). Enclose the magnetic counterpart on the bottom edge of the doors. Both the door sensor and the magnetic counterpart must be placed in the common axis. The distance between those parts must be 2-12mm / 0.08-0.47 in. (F) In case the distance between these part is too big, underlay the magnetic counterpart with the distance barrel. The magnetic counterpart is strong enough to held on place. For the fixation use 2-12 mm enclosed screws (G). -
Page 7: Air Inlet Flap Installation
HIGHTEMPERATURE SENSOR INSTALLATION Screw the hightemperature sensor on fireplace insert or stove doors to the designed place. min. Minimal lenght for correct measurment 20 mm is 20mm / 0.8 in at its end (H). AIR INLET FLAP INSTALLATION Connect the air inlet flap by alu pipe with the fireplace insert or stove doors. The connection between the air inlet flap and the product must be tight enough. When installing into closed-in build, the air inlet flap must be placed outside the hightemperature place. The heat resistence of the air inlet flap is max 50°C / 122°C. CONTROL UNIT CONNECTION Connect all the components and power supply adapter with the control unit. After that plug the power supply adapter to the power feed. 12V DC For complete instruction how to set-up the control unit follow the instruction stated in the chapter „SET-UP“... -
Page 8: Setting Of Device And Communication Channel
SET-UP SETTING UP THE PRODUCT AND COMMUNICATING CHANNEL There is a red control diode RUN flashing. Press the SET button on the control unit until the red control diode turns off. Remove the strip between the battery and the contact in the display. It prevents the batteries to power the display. In case, the display is already powered, remove and after short moment put back inside all the batteries. The first number from the product codes appears on the display (list of product codes on page 13). Scroll to the required number by short presses of the SET button. To confirm the selection hold the SET button for 5 sec. Now the last two numbers from the product codes are active. Scroll to the required number by short presses of the SET button. To confirm the selection hold the SET button for 5 sec. Now the number of the communicating channel is active. Confirm by holding the SET button. In case there is another fireburning control installed or another source interfering the communication, repeat the SET-UP process and choose different channel. Set message appears on the display to confirm the set-up proces was finished succesfully. After a while the fireburning control turns itself into operating mode. 12V DC SHORT PRESS TO CHANGE VALUE. HOLD TO CONFIRM THE CHOICE. -
Page 9: Setting For Uni-Product
UNI PRODUCTS SETTING This settings is defined for individual fireplaces or to adjust the time of active burning out phase. UNI setting is available in three different options for starting temperatures (T ) - pro 80°C, 250°C or 400°C. The choice for the start correct starting temperature depends on the place where the hightemperature sensor is installed – in burning chamber, or in the accumulating system. When setting the UNI system, follow the step 1-5 as in the chapter „Setting up the product and communicating channel“. After confirmation of the UNI product code, the option for temperature T5 appears on the display. When this temperature is reached, the air inlet flap is closing completely, the phase of active burning ends and phase of hot coal is starting. By default the temperature T5 is set on the 65% value of the temperature T4. For adjusting applies: Values higher than 65% shortens the phase of active burning Values lower than 65% extends the phase of active burning To confirm the choice hold the SET button. After that continue with the option for communicating channel. -
Page 10: Operating
OPERATING INFORMATIONS ON DISPLAY Informations on the display are beeing updated each 8 second. For instant update or to activate the backlight push the display in the upper part. During common operation the display shows four basic values: Current temperature in the burning chambre Temperature measured by the hightemperature sensor Time of burning The period starts when the doors sensor contact is interrupted (opened doors) and ends when the combustion stops . The fireburning control is now in phase 0, the hightemperature sensor measures temperature lower than 50°C. Strenght of signal The marks in the lower part of the display are showing the strenght of the signal between the display and the electronical control unit. It shows seven marks when the signal is full, when the signal is too weak, the display shows SIG warning message. Stage or phase of the burning Because of different conditions of each burning (humidity, firewood quantity, thrust of the chimney) the fireburning control unit ABRA 6 doesn’t control the combustion by fixed time intervals for each phase. The period and process of... -
Page 11: Alarms And Warnings
St1 - first phase. This stage begins with opening and closing of the doors and ends when the starting temperature is reached. Starting temperature is start determined with the choice of product during the set-up process. St2 - second phase. Second phase starts after the temperature t is reached start and continues for at least 15 min. During this stage the maximal temperature t is reached. St3 - third phase is the stage of active burning. St4 - fourth phase is the stage of active burning out, the air inlet flap lets in only minimal possible air required for combustion. - fifth phase is the stage of hot coals, the air inlet flap is closed completelly. St0 phase zero - non-active phase, when the temperature in the burning chamber is lower than 50°C. Fireburning control automatically wents in saving mode. ALARMS AND WARNING MESSAGES SiG warning message - the signal strenght beween display and control unit is too weak. bAt warning message - the voltage of the batteries in the display is too low. Replace the batteries. Alarm - Alarm is signaled by beeps and flashing of the display. AL-1 Power supply of the electronical control unit failure. For security reason the backup battery allows to open the air inlet flap and the fireburning controls turns itself off. Check the power supply feed. AL-2 Power supply of the electronical control unit failure and also weak backup battery in the electronical control unit. Replace the backup battery in the electronical control unit and check the power supply feed. AL-3 Bad heating. All of following conditions occured. The time period of the first burning phase was longer than 30min, the temperature in the burning chamber didn’t reach 90°C and decreased of more than 10°C. The fireburning control... -
Page 12: Troubleshooting
TROUBLESHOOTING Failure Cause Solution Electronical fireburning Remove and put back Control diode RUN control unit is in set-up batteries from the doesn’t flash. mode. display. Finish the set-up process. Electronical fireburning Check the connection Sig is showing on the control unit is not feeded between electronical display, control diode from the power supply fireburning control unit feed. and the power supply PWR is off. feed. Electronical fireburning Remove and put back Display is showing SiG, control unit is in set-up batteries from the control diode PWR is... -
Page 13: List Of Products
LIST OF PRODUCTS HOXTER 1.01 HAKA 37/50 1.02 HAKA 63/51 1.03 HAKA 67/51h 1.04 HAKA 89/45h 1.05 ECKA 67/45/51h 1.06 ECKA 90/40/40h 1.07 HAKA 37/50W 1.08 HAKA 63/51W 1.09 HAKA 63/51WT 1.10 HAKA 67/38W 1.11 HAKA 67/51W 1.12 HAKA 89/45Wh 1.13 ECKA 67/45/51Wh UNIVERSAL 2.01 UNI - 80°C 2.02 UNI - 250°C 2.03 UNI - 400°C... -
Page 14: Warranty
WARRANTY Warranty for the electronical fireburning control ABRA 6 and its componenst is 24 months. The warranty doesn’t apply on mechanical damage. The warranty also doesn’t apply if the damaged products were exposed to temperatures higher than the defined maximal values. Installation of the electronical fireburning control ABRA 6 must be done by specialist – stove maker. For warranty and post-warranty service contact please the company that installed the product. Date of the installation: Company / Stove maker: Address: Phone:... - Page 15 NOTES...
- Page 16 HOXTER a.s. HOXTER gmbh Kirchgasse 1 Mlýnská 326/13 602 00 Brno 91217 Hersbruck Czech republic Germany Tel.: +420 518 777 701 Tel.: +49 (0)9151 8659 163 info@hoxter.eu info@hoxter.de www.hoxter.de www.hoxter.eu...
