Summary of Contents for arcutroni AMX32FE

  • Page 1 AMX32...
  • Page 2 Access Multiplexer with Fast Ethernet User Manual AMX32FE – Access Multiplexer with Fast Ethernet USER GUIDE...
  • Page 3: Table Of Contents

    Access Multiplexer with Fast Ethernet User Manual Table of Contents History ..............................3 Chapter 1 Overview ............................. 4 Chapter 2 System General Description ......................5 2. 1. System Schematic Diagram ......................6 2. 2. Equipment Features ........................6 2. 3. Operating Principles ........................
  • Page 4: History

    Access Multiplexer with Fast Ethernet User Manual Chapter 11 Management Manual of HyperTerminal Network ..............42 11. 1. Utilization of HyperTerminal at CONSOLE interface on the front panel ......42 11. 2. Utilization of HyperTerminal of CON interface on the front panel ........49 Chapter 12 Typical Networking Scheme ....................
  • Page 5: Chapter 1 Overview

    User Manual Access Multiplexer with Fast Ethernet Chapter 1 Overview AMX32FE is a new product series of modular optical transmission equipment released by our company in adoption of modularized structure, supported with the company’s independently developed universal software platform, and in use of high-performance processor and bus technology, etc.
  • Page 6: Chapter 2 System General Description

    Chapter 2 System General Description e AMX32FE is created with 16E1+100M full speed Ethernet capacity of transmission interfaces. The equipment also provides various interface modules for voice, data and video services in cities and industrial districts.
  • Page 7: System Schematic Diagram

    2. 2. Equipment Features e AMX32FE is created with optical path interoperability, flexible structure and modular design. Its function modules are independent of each other but easy for assembly, which enables it to derive a series of optical multiplexer products with multiservice interfaces. The equipment is furnished with four modular slots.
  • Page 8: Operating Principles

    (RS232, and Ethernet Interface, etc.), and alarm output terminal module, etc. available. 2. 3. Operating Principles e AMX32FE adopts plug-in board structure and can be functionally divided into five general parts, including: A. Compound unit of 4/8/12/16-channel E1 or V.35 B. Optical interface C.
  • Page 9 Access Multiplexer with Fast Ethernet User Manual A, B and E are the three basic components. Unit A is used for completing reversible conversion from 4/8/12/16 2048kbit/s signals to laser signals. The function of Unit B is to perform framing and deframing of photoelectric signals and E3/E6 optical switch.
  • Page 10 Access Multiplexer with Fast Ethernet User Manual certain period of time when active pass is resumed to normal condition); When the equipment is started, it is preferential to have both local end and remote end operating with the A optical interface. ALS (Automatic Laser Shutdown/Automatic Laser Reduction) function: When a fiber disconnection in this optical pass is detected, the average output power at the optical transmitting end is reduced by more...
  • Page 11: Chapter 3 Description About Modules

    It supports hot swap of power supply. Chapter 3 Description about Modules A basic AMX32FE consists of a motherboard, four slots for optional pluggable interface boards, a power switch module and a user interface card. Order wire module, network management module, and alarm output module are also prepared for user selection.
  • Page 12: Service Interface Cards

    Access Multiplexer with Fast Ethernet User Manual (6) To indicate various alarming messages (7) To indicate various status 3. 2. Service Interface Cards  G.703 Interface Card 4 channels of G.703 interface available DB37 Interface, to provide corresponding external interface through adapter Fully compliant with ITU-T G.703 recommended standards Interface Code Type: HDB3...
  • Page 13: Chapter 4 Technical Specifications

    Access Multiplexer with Fast Ethernet User Manual FXS interface card: to provide 4-channel or 8-channel FXS interface connected with ordinary telephone sets. Supports display of incoming calls. Supports billing function of inverted polarity.  RS232 Interface Card Physical interface: RJ45 Four RS232 transmission channels available Transmission Speed: 110~115.2K bps Transmission Mode: Full-Duplex...
  • Page 14 Access Multiplexer with Fast Ethernet User Manual Jitter 100kHz ≥ 0.2UI Max. Output Jitter LF limit f1~f4 < 0.25UI HF limit f3~f4 < 0.05UI Jitter Shifting Property 400Hz < 0.1UI 51.2kHz~102.4kHz ≥ 12dB Reflecting Attenuation 102.4kHz~2048kHz ≥ 18dB 2048kHz~3072kHz ≥ 14dB 4E1 Interface Adapter: For standard DB37 female interface, refer to Appendix 1 for pin definitions.
  • Page 15 Access Multiplexer with Fast Ethernet User Manual Refer to Appendix 1 for pin definitions. Dual V.35 Interface Card: (Each card contains two V.35 interfaces: 2xV.35) Interface Bit Rate: 2.048Mbit/s Interface Electric Level: In compliance with CCITT V.35 standard Kk EE AA W S M H C ⊙⊙⊙⊙⊙⊙⊙⊙...
  • Page 16 Access Multiplexer with Fast Ethernet User Manual front panel respectively. Provided that 2×V.35 card is plugged in the slot II on the mainboard, the lower V.35 channel and the upper V.35 channel may correspond to 5th and 6th indicators on the front panel respectively.
  • Page 17 Access Multiplexer with Fast Ethernet User Manual The interface under double-layer female DB37 interface card is the 1 and 2 channels of V.35, and the interface above is the 3 and 4 channels of V.35. Different pins of DM34 (Needle Type) Interface and DB37 (Cellular Type) are defined as follows:...
  • Page 18 Access Multiplexer with Fast Ethernet User Manual Pin No. of DB37 Cellular Type Pin No. (Upper/Lower Layer) of DM34 Circuit Signal Function Cellular Direction Type Channel Channel of V35 of V35 Timing for sending code DCE→DTE element of signal (B) Timing for terminal sending DTE→DCE code element of signal (B)
  • Page 19 Access Multiplexer with Fast Ethernet User Manual DCE→DTE Receiving line signal test Signal ground or public loop Attentions: (1) The corresponding relationships of pins for upper and lower two layers of DB37 are the same, of which 37 core of the lower layer corresponds to the 1 and 2 channels of V35, and that of the...
  • Page 20 Access Multiplexer with Fast Ethernet User Manual Sending Clock B (From DCE) Receiving Clock A (From DCE) Receiving Clock B (From DCE) (3) When maintaining the equipment, the fault can be determined by loop-back. The detailed definition of loop-back is as follows: Local loop Fiber V.35...
  • Page 21 Access Multiplexer with Fast Ethernet User Manual The making method of V.35 self-loop connector with straight DB37-M: The 1 channel of V.35 self loop: 23-2 shorted 4-21 shorted 22-6 shorted 3-25 shorted The 2nd channel of V.35 self loop: 14-30 shorted 32-12 shorted 13-34 shorted 31-16 shorted...
  • Page 22 Access Multiplexer with Fast Ethernet User Manual confirmed that there is already a clock provided by device in the line, then all the rest devices shall be set into line clocks, while if it cannot be confirmed that if there is already clock provided by device in the line, then it is to be set as internal clock.
  • Page 23 Access Multiplexer with Fast Ethernet User Manual Lower RJ45 1,2 The 1 Loop Audio 3,4 The 2 Loop Audio 5,6 The 3 Loop Audio 7,8 The 4 Loop Audio 8,7,6,5,4,3,2,1 1,2,3,4,5,6,7,8 Upper RJ45 1,2 The 5 Loop Audio 3,4 The 6 Loop Audio 5,6 The 7 Loop Audio...
  • Page 24: Optical Interface

    Access Multiplexer with Fast Ethernet User Manual RS-485 Interface: 6, 7 shorted as B; 5, 8 shorted as A. Transmitting Speed: 110~115.2 kbps Transmitting Mode: Full Duplex / Half Duplex 4. 2. Optical Interface Optical Source: Speed of optical interface: 155Mbps Quantity of interface: 2(work and protection)
  • Page 25: Physical Parameters

    No corrosive and solvent gas, and free from flying dust and magnetic-field interference. Chapter 6 Function Description The peripheral interfaces of the AMX32FE can be divided into optical interface, electrical interface, monitor interface and order wire interface etc based on different functions.
  • Page 26: Description Of Optical Interface

    Access Multiplexer with Fast Ethernet User Manual 6. 1. Description of optical interface There are two 1+1 standby optical interfaces on the left of the front panel, optical interfaces A and B. The two optical interfaces can be switched as parallel optical interfaces, or the optical interface A can be set as the main optical interface.
  • Page 27: Description Of Lcd Keys

    Access Multiplexer with Fast Ethernet User Manual 1LINK: Green, indicating the normal connection of the 1st Ethernet interface chain. 1DPX: Green, indicating full duplex or half duplex of the 1st Ethernet interface chain. Light on refers to full duplex, off refers to half duplex. 1SPD: Green, indicating the rate of the 1st Ethernet interface chain to be 10M or 100 M.
  • Page 28 Access Multiplexer with Fast Ethernet User Manual RJ45 8,7,6,5,4,3,2,1 5 GND The typical configuration description of the data format of RS232: Bit rate: below 19200bps auto-negotiating Data bit: 8, 7, 6 and 5 auto-negotiating Stop bit: 1, 1.5 and 2 auto-negotiating Check bit: auto-negotiating Flow control: no/software Alarm Output Terminal Interface (Optional):...
  • Page 29: Hyperterminal(Console/Con)

    Access Multiplexer with Fast Ethernet User Manual there is no alarm, cut off the above connections. 6. 5. HyperTerminal(CONSOLE/CON) The dual-layer DB9 hole refers to the HyperTerminal interface of RS232 interface. The upper one is HyperTerminal of the equipment (CONSOLE), and the lower DB9 hole is the Hyper Terminal of network management (CON), as standby.
  • Page 30: Description Of Button

    Access Multiplexer with Fast Ethernet User Manual 6. 6. Description of button CONSOLE/NM-ETH is used to switch Hyper Terminal and Ethernet network management interface. Push it down to use HyperTerminal; release it to switch to Ethernet network management interface. 6. 7. PHONE at order wire phone interface (optional) The equipment can supply a line of order wire phone to facilitate the...
  • Page 31: Back Panel

    Access Multiplexer with Fast Ethernet User Manual 6. 10. Back panel Power supply: AC220V or DC48V, 1+1 redundant standby power supply, to be replaceable externally. Service slots: Four optional interface boards, I, II, III and IV. 6. 11. Bottom Board Preset Holes There is a 4-digit patch switch inside the 4 small rectangular holes on the bottom board of equipment.
  • Page 32 Access Multiplexer with Fast Ethernet User Manual 2 V.35 clocks in anti-phase 2 V.35 master clocks The 1 V.35 clock in anti-phase 2 V.35 external clocks The 2 V.35 clock in anti-phase Neither of the two V.35 OFF OFF OFF OFF 2 V.35 slave clocks clocks in anti-phase III) When 4×RS422/485 interface board is plugged in, the switch is used for option of RS422/RS485.
  • Page 33: Chapter 7 Installation Of Optical Multiplexer

    Access Multiplexer with Fast Ethernet User Manual 100M, Full-Duplex V) When other interface boards are plugged in, the 4-digit patch switch would possibly be invisible. Ⅰ Ⅱ Ⅲ Ⅳ Chapter 7 Installation of Optical Multiplexer 7. 1. Equipment Package and Appearance Check 1) After equipment arrives, first check if its external packing is damaged or not.
  • Page 34: Installation Of Equipment

    Access Multiplexer with Fast Ethernet User Manual 2) It should be in a dry, neat, and well ventilated surrounding environment. 3) Necessary anti-static measures shall be taken during installation, application, and maintenance of the equipment. Therefore, the casing should be grounded, to strengthen its anti-inference and thunder-proof capacity.
  • Page 35: Installation Precautions

    Access Multiplexer with Fast Ethernet User Manual 7. 4. Installation Precautions 1) Avoid intense vibration and mechanical damage with equipment during shipment and installation. 2) Pay attention to rational optical fiber arrangement inside the machine room, the radius of fiber curvature shall be ≥ 50mm. 4) Optical connectors are not to be polluted and fiber optic splices shall be gently scrubbed with alcohol prior to use;...
  • Page 36: Precautions Prior To Startup

    Access Multiplexer with Fast Ethernet User Manual 8. 2. Precautions Prior to Startup Based on the description in Chapter VII, after the optical multiplexer is installed, please carefully read the following three points before power on the equipment: 1) Prior startup, make sure...
  • Page 37: Maintenance Of Equipment

    Access Multiplexer with Fast Ethernet User Manual Avoid by all means to look directly into the fiber jack from a close distance. Connect with 2M signal line: open all the alarm signals of 8 bypasses, namely dial downward the MASK to set into not masking E1 Bypass Alarm.
  • Page 38 Access Multiplexer with Fast Ethernet User Manual Check the power supply The power supply does not for the conformance with comply with the requirement the requirement The power supply switch Switch power Abnormal has not been on supply switch Power power supply supply...
  • Page 39: Chapter 10 Operation Manual Of Lcd

    Access Multiplexer with Fast Ethernet User Manual transmission fiber-optic fails Self loop the two ends One end is normal, Replace the equipment respectively, one end is while optical loss or measure the optical normal, the other end alarm occurs at power, or contact with the emits an alarm, which the other end...
  • Page 40 Access Multiplexer with Fast Ethernet User Manual no key is pressed after 2 minutes and 25 seconds, the screen will go back to the uppest level of the menu system: “Fiber Opti Multi | MENU SYSTEM”. When the screen displays <***>| ***, press “ENTER” to enter for setting.
  • Page 41 Access Multiplexer with Fast Ethernet User Manual > MAIN SYS > < < OPT MODE > PARAMETER < AUTO > <LOOP-E1~1-16> SYSTEM E1 .:OFF <OPT SWIT GRADE> < ....PARAMETER *:ON < OPT ALS > < E1 MASK > AUTO >...
  • Page 42 Access Multiplexer with Fast Ethernet User Manual > > INT OSC < SYSTEM-TIMING> 1 FV.35 < < EXT CLK RECOVERY MODE:INT OSC PARAMETER > < > < > < < SYSTEM-TX CLK> NOMAL 2 FV.35 REVERSED NOMAL PARAMETER < SYSTEM-RX CLK> NOMAL REVERSED NOMAL...
  • Page 43: Chapter 11 Management Manual Of Hyperterminal Network

    Access Multiplexer with Fast Ethernet User Manual Press “R” to move the cursor to the right, and associatively use the key “U” or “D” to select “*” or “.”. “*” refers to select the time slot, “.” means not to select the time slot. Use “U” or “D” to switch between “*”...
  • Page 44 Access Multiplexer with Fast Ethernet User Manual I>. Notes for Application: All commands shall be described in small letters; Input the commands in strict accordance with the command format, including the spaces contained in the commands. In the case of wrong input when inputting a command in the HyperTerminal, press Enter to cancel and repeat the input, or use Backspace to erase.
  • Page 45 Access Multiplexer with Fast Ethernet User Manual 2. After enter HyperTerminal, open the menu (File) --------> Properties, the below window pops up. Set according to the window instruction, and enter “Confirm” reenter the HyperTerminal interface. III>. Usage of Commands a> Get information command 1....
  • Page 46 Access Multiplexer with Fast Ethernet User Manual E.g.: >setlmainsys lop o 01↙ to set the 1 channel of local 2M to loop back >setlmainsys lop f 01↙ to cancel the loopback of the 1 channel of local 2M >setrmainsys lop o 01↙ to set the 1 channel of remote 2M to loop back >setlmainsys lop o 01 03 12 06↙...
  • Page 47 Access Multiplexer with Fast Ethernet User Manual >setrmainsys als o↙ to set remote ALS function enabled >setrmainsys als f↙ to disable the remote ALS function setl(r)mainsys+space+f-b(compulsory optical interface B) E.g.: >setlmainsys f-b↙ >setrmainsys f-b↙ setl(r)mainsys+space+f-a(compulsory optical interface A) E.g.: >setlmainsys f-a↙ >setrmainsys f-a↙...
  • Page 48 Access Multiplexer with Fast Ethernet User Manual setl(r)mainsys+space+mut(mute) +o(f)( ON or OFF ) E.g.: >setlmainsys mut o↙ >setrmainsys mut o↙ setl(r)fv.35 + : to set the information of the local 4(2)xFV.35. Setl(r)fv.35+space+1-4 (1-4 pieces of plugged boards) +space+1-4 (1-4 channels of V.35) +clk(clock)+space+ mclk(sclk eclk) master clock (slave clock, external clock) rdcr(receiving data clock reversal) rdcp(receiving data clock positive)
  • Page 49 Access Multiplexer with Fast Ethernet User Manual as defaulted; 2. Basic frame transmission (i.e. PCM31, CCS): s0 timeslot is set as 1 (OFF), one or more other timeslots are selected; 3. Multiple frame transmission (i.e. PCM30, CAS): s0 timeslot is set as 0 (ON) and s16 timeslot is set as 1 (OFF).
  • Page 50: Utilization Of Hyperterminal Of Con Interface On The Front Panel

    Access Multiplexer with Fast Ethernet User Manual 0/1/2/3/4 Auto-negotiating/100M full duplex/100M half duplex /10M full duplex/10M half duplex Note: When using the command getl(r)info, the indicated Ethernet message shall be corresponding to this. 11. 2. Utilization of HyperTerminal of CON interface on the front panel Function: to configure the SNMP Ethernet interface (NM-ETH).
  • Page 51 Access Multiplexer with Fast Ethernet User Manual Knock on the key “ENTER” within 5-6 seconds to enter the 4. configuration interface, otherwise, linux will be started up to enter into the running state so that the configuration cannot be performed. 5....
  • Page 52 Access Multiplexer with Fast Ethernet User Manual monitoring PCs; setdevip –M[I] To modify the IP address of nine monitoring PCs, the parameter I can be applied to modify a single address. Note: The IP address shall ensure the location in the same network segment as the computer.
  • Page 53 Access Multiplexer with Fast Ethernet User Manual  Illustration of command configuration: The following is the application process of these commands operated in HyperTerminal (for reference only, applied according to the actual situation). Press down the button RESET, and release it again. Knock on a random key on the keyboard within 5-6 seconds to make the agent enter into the startup and configuration state, then input the password.
  • Page 54 Access Multiplexer with Fast Ethernet User Manual The Baud Rate is: 19200. \>setgate to query the current gateway Unlock finished Net Gate: 192.168.0.1 \>setgate 192.168.0.1 to modify the current gateway Unlock finished Set Net Gate: 192.168.0.1 Erase block at 0x23c0000 ok The Net Gate is saved.
  • Page 55 Access Multiplexer with Fast Ethernet User Manual The IP of devices <6> is : 010.010.000.165 The IP of devices <7> is : 192.168.000.165 The IP of devices <8> is : 255.255.255.255 The IP of devices <9> is : 255.255.255.255 \>setdevip -m to modify the IP address of the PC on the console Unlock finished The IP of devices <1>...
  • Page 56: Chapter 12 Typical Networking Scheme

    Ethernet network management mode. Default of IP address: 192.168.0.253 Default of gateway: 192.168.0.1 Default of mask: 255.255.255.0 Chapter 12 Typical Networking Scheme Ethernet Host PSTN VOICE AMX32FE AMX32FE Internet Ethernet IP Gateway V.35 Network Management & Monitoring Router Monitoring...
  • Page 57: Chapter 13 Db37-Rj45 (120Ω) Pin Definitions

    Access Multiplexer with Fast Ethernet User Manual Chapter 13 DB37-RJ45 (120Ω) Pin Definitions RJ45 Socket: 1,2,3,4,5,6,7,8 DB37 Socket Input Output Pin No. Pin No. Definition Definition – – DB37 OUT1 RJ45-1 DB37 OUT2 RJ45-1 DB37 OUT3 RJ45-1 DB37 OUT4 RJ45-1 P.S.: The 1 and the 8 pins of each RJ45 modular plug are...
  • Page 58 Access Multiplexer with Fast Ethernet User Manual...
