Summary of Contents for Eclipse TD-M1
-
Page 2: Table Of Contents
Windows XP ……………………………… 18 (wireless network) …………………… 6 Connecting and playing via AUX ………… 19 Router mode (recommended) ……………… 6 Opening the TD-M1 Network Audio Direct mode ………………………………… 6 Device Settings screen …………… 20 Using the TD-M1 …………………… 7 ... -
Page 3: Features
In the first instance you should contact your original retailer of the Product who may be able to assist in resolving your issue. If the issue was not resolved, please contact FUJITSU TEN LIMITED as listed in the owner’s manual or on our Web support page (http://www.eclipse-td.net/), along with the receipt, for Warranty Repair. -
Page 4: Terminals
Terminals Right channel speaker Left channel speaker Terminal Power-input terminal Connect the included AC adapter. Connect a TV set, CD player or other external device. Use a AUX IN terminal (3.5 mm stereo jack) commercially available audio cable with a 3.5 mm stereo plug. Connect an iPhone, iPod or iPad. -
Page 5: Preparing The Speakers
Attach the grills as shown in the diagram. Connecting the power To connect the power of the TD-M1, perform the following procedure. Connect the left-channel speaker output terminal to the left-channel speaker input terminal. -
Page 6: Connecting Playback Devices
Connection requires a commercially available cable with a 3.5 mm stereo plug. * The functions of the TD-M1 were developed and tested based on the iPhone, iPod touch, iPad and Android device software versions listed on the Eclipse web site. If... -
Page 7: Playing Via Wi-Fi (Wireless Network)
While the device is communicating with the TD-M1, you cannot connect to the Internet from the playback device. In Direct mode, communication is not protected by encryption. If a third party connects without permission and attempts an audio playback operation from a wireless device, the TD-M1 may perform the operation. -
Page 8: Using The Td-M1
Wi-Fi mode Red (flashing) Auto-power function connecting procedure on page 9 “Connecting” .) When the TD-M1 is in network standby, in the following conditions, White (flashing) Software update in progress the power switches on automatically. Connection method Operation conditions When music is played back via... -
Page 9: Adjusting The Volume
Using the TD-M1 Adjusting the volume To raise the volume, touch . Alternatively, slide the volume slider to the right. To lower the volume, touch . Alternatively, slide the volume slider to the left. Switching the source Touch · The source can be switched in the following order: Wi-Fi (AirPlay/Android), USB B, USB A, and AUX. -
Page 10: Listening Via Airplay
Connecting using Router mode To play music wirelessly using AirPlay, connect your playback First connect your playback device and the device and the TD-M1 via Wi-Fi. To connect, perform the following TD-M1 in Direct mode. procedure. Connecting using Direct mode... - Page 11 From “Access Point Scan” , select the SSID of your router, and then enter the password. Finally, click [Apply]. After blinking orange, the TD-M1’s indicator turns blue. This can take up to 1 minute. If the connection is completed, the indicator switches on blue.
-
Page 12: Playing
Playing Operate the iOS device to play music. To play music via AirPlay, connect your playback device and the TD-M1 via Wi-Fi, and then perform the following procedure. (Page 9 “Connecting”) iOS device Make sure that the power of the TD-M1 is... -
Page 13: Listening Via Android Device
To play music wirelessly using an Android device, first install the To play music wirelessly using an Android device, connect your dedicated Android application. Android device and the TD-M1 via Wi-Fi. To connect, perform the following procedure. From the home screen of the Android ... -
Page 14: Connecting Using Router Mode
From “Access Point Scan” , select the SSID of your router, and then enter the password. Finally, click [Apply]. After blinking orange, the TD-M1’s indicator turns blue. This can take up to 1 minute. If the connection is completed, the indicator switches on blue. -
Page 15: Playing
Select the music you want to pay back from the Music Select screen. To play music via an Android device, connect your Android device and the TD-M1 via Wi-Fi, and then perform the following procedure. (Page 12 “Connecting”) Make sure that the power of the TD-M1 is on. -
Page 16: Playable Formats
Listening via Android device Playable formats With the TD-M1, you can play the following audio formats from your Android device. However, even if the audio format is one of the following, there are some cases when it cannot be played. -
Page 17: Listening Via Usb/Aux
Playable formats on, and then connect the iPhone/iPod/iPad to the USB terminal (Type A). With the TD-M1, you can play the following audio formats from a USB connection (B type). If an iPhone/iPod/iPad is connected to the USB terminal... -
Page 18: Windows Pc
When the following screen is displayed, connect the Windows PC to the TD-M1’s If you are using a Windows PC, first browse to the Eclipse web site, and then download the USB audio driver. USB terminal (B type) and click “OK” . -
Page 19: Windows 7, Windows 8
Windows 7, Windows 8 Windows XP *The below examples are the Windows 8 screens. Make sure that the power of the TD-M1 is Make sure that the power of the TD-M1 is on, and then connect the Windows PC to on, and then connect the Windows PC to the USB terminal (Type B). -
Page 20: Connecting And Playing Via Aux
Connecting and playing via AUX To play music via AUX connection, perform the following procedure. Make sure that the power of the TD-M1 is on, and then connect to the audio output cable of the external device to the AUX IN terminal. -
Page 21: Opening The Td-M1 Network Audio Device Settings Screen
TD-M1 Network Audio Device Settings screen. *The below examples are the Windows 8 screens. · Change the name displayed on the network for the TD-M1 · Configure advanced network settings · Update software (a Mac or Windows PC is required) Before opening the settings screen, connect your playback device and the TD-M1 via Wi-Fi. -
Page 22: Using My Network Places On Windows Xp
If the settings screen has been opened on an iOS/Android device, software cannot be updated. To update software, connect the TD-M1 in Router mode (Page 9 “Connecting”), and then use a Mac or Windows PC. The TD-M1 Network Audio Device Settings... -
Page 23: Checking And Changing The Network Settings
Network Settings You can change network settings. Software Update You can update software. * Language You can select the language. Device Name You can change the name displayed on the network for the TD-M1. * Displayed only in Router mode. -
Page 24: Network Settings Screen
Opening the TD-M1 Network Audio Device Settings screen Network Settings Screen Item Details Available access points are found automatically. Select an SSID, and then enter the Access Point Scan encryption key. You can select the SSID and security method manually. Use these settings when the Wireless Settings Wi-Fi router is set to stealth mode. -
Page 25: Updating Software
Opening the TD-M1 Network Audio Device Settings screen Updating software The software of the TD-M1 may be updated on an irregular basis. To update software, first browse to the Eclipse web site, and then download the update file. To update software, connect the TD-M1 in Router mode (Page 9 “Connecting”), and then use a Mac or Windows... -
Page 26: Resetting The Td-M1
Do not use gasoline or thinners, etc. on this unit as it may damage the cabinet. Troubleshooting When you have any troubles including system malfunction with the product, browse to the Eclipse web site (http://www.eclipse-td.net) and refer to the “Support” page. -
Page 27: Specifications
Specifications Be aware that the specifications and exterior may change without notice for improvements. TD-M1 Speaker unit ........... Full range speaker with 8-cm cone Method ............Bass reflex box Playback frequency ........70Hz to 30kHz Rated output ..........20 W (T.H.D: 1%) *When one channel is operating Maximum output ........... -
Page 28: License
License FLAC Decoder Copyright (C) 2000,2001,2002,2003,2004,2005,2006,2007 Josh Coalson Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: - Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer. - Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.
