- Page 1 ViaLite HD Fibre Optic Link System 3U chassis User Manual HRK3-HB-5 CR3274 17/12/14 Pulse Power & Measurement Ltd, 65 Shrivenham Hundred Business Park, Watchfield, Swindon, Wiltshire SN68TY, UK Tel +44 (0)1793 784389 Fax +44 (0)1793 784391 Email sales@ppm.co.uk www.vialite.com...
- Page 2 There are no user serviceable parts inside; the covers MUST NOT be removed. There are no user replaceable fuses in the chassis mounted equipment. Replacement should only be carried out by a ViaLite Communications technician. The chassis earth stud SHOULD be connected to the safety earth.
-
Page 3: Table Of Contents
ANDBOOK TABLE OF CONTENTS INITIAL INSPECTION .................................... 5 INTRODUCTION TO THE VIALITEHD RANGE ............................. 5 VIALITEHD AND VIALITE CLASSIC COMPATIBILITY .......................... 6 VIALITEHD SYSTEM COMPONENTS ..............................7 ViaLiteHD 19” chassis ................................7 Description ....................................7 Power Interface Management ..............................7 4.3.1... - Page 4 HRK3-HB-5 V HD 3U CHASSIS ANDBOOK PRODUCT WARRANTY ..................................34 FCC APPROVAL ....................................34...
-
Page 5: Initial Inspection
Unpack and inspect the equipment as soon as possible. If there is any sign of damage or any parts missing, do not install the equipment before seeking advice from ViaLite Communications or your local agent. The equipment received should match the delivery note that is shipped with the equipment. If there are any discrepancies, contact ViaLite Communications or your local agent. -
Page 6: Vialitehd And Vialite Classic Compatibility
The RF and optical interfaces of most ViaLiteHD and ViaLite Classic modules are compatible. However the physical size, mounting systems and control of the modules are different, so it will not be possible to fit ViaLiteHD module in a ViaLite Classic chassis or housing and vice versa. -
Page 7: Vialitehd System Components
It is also possible to provide external power to a chassis fitted with PSUs, for this reason the current share bus (CSB) is available on “Power Concentrator” connector J4. If this option is used the chassis must be interfaced to ViaLite Communications approved external power... -
Page 8: Module Bias Feed
HRK3-HB-5 V HD 3U CHASSIS ANDBOOK 4.3.2 Module bias feed It is possible to provide a bias voltage from the modules to connected devices. Dependent on module type, this can be either internally sourced from the module or provided via the “Power Concentrator” connector J4. The current limit is dependent on module type fitted. -
Page 9: Module Alarm Defeat
5V via 100k ohm, with series diode Applying external voltage to these pins may cause damage, contact ViaLite communications Note: the alarm line for slot 14 is always pulled up irrespective of the card status, these cards are all fitted with summary alarm relays. -
Page 10: Minimum Power Supply Load
HRK3-HB-5 V HD 3U CHASSIS ANDBOOK 85044 ViaLiteHD Blank Panel, 5HP 85046 ViaLiteHD Blank Panel, 7HP There are also reusable panels available (85049 and 85050) with handles to keep them in place. The 6 HP blanking panels are fitted with handles to secure them into either slot 15 or 16. These are design to permanently hold the blanking panel in position. -
Page 11: Chassis Specification
Max. No. of 7HP modules 1 (in slots 14 only) Max. No. of 6HP modules 2 (in slots 15,16 only) 19” Rack Mounting Desktop Mounting Not Suitable (use ViaLite Classic products) Width, internally 84 HP Width, externally 483 mm Height, internally... -
Page 12: Chassis Connector Pin Out J4 & J19-31
The pin out of connectors J4 & J19-31 has been changed, to add additional functionality to the chassis. Check serial number to find correct pin out. See section 4.9.1.1 and 4.9.1.2 below. The approximate last shipment date of the early revision racks is July 2013, contact ViaLite Communications for more details. -
Page 13: Lna Feed And Buc Feed Pin Assignment For Different Module Types
HRK3-HB-5 V HD 3U CHASSIS ANDBOOK Pin out – J4 “Power Concentrator” connector* Chassis J4* Chassis J4* Chassis J4* Chassis J4* Relay_1 (NC) LNA_feed_3 Relay_2 (COM) LNA_feed_2 LNA_feed_5 LNA_feed_4 LNA_feed_7 LNA_feed_6 BUC_feed_1 LNA_feed_9 LNA_feed_8 BUC_feed_3 LNA_feed_11 BUC_feed_2 LNA_feed_10 BUC_feed_5 LNA_feed_13... -
Page 14: Fan Replacement
HRK3-HB-5 V HD 3U CHASSIS ANDBOOK 4.10 Fan replacement If the fan is not turning, the fan cartridge assembly should be replaced. This can be completed without disconnecting the chassis from the mains supply. Please ensure that when the fan is outside of its safety enclosure it is disconnected from its power connector The fan is removed by the following procedure. -
Page 15: Vialitehd Power Supplies
Both types of power supply are internally fused; this fuse is only expected to fail under fault conditions. The fuse is located internally underneath the earthed safety cover; this is not user serviceable and must be returned to ViaLite Communications for replacement. -
Page 16: Specification
HRK3-HB-5 V HD 3U CHASSIS ANDBOOK 5.1.1 Specification HPS-3 HPS-3-DC Description Wide input range AC power supply Wide input range DC power supply Dimensions, internal (W x H) 6HP * 3U Dimensions, external (W x H x D) 188 x 129 x 30 mm Weight 0.6kg... -
Page 17: Redundancy Load Module, Plug-In Card
HRK3-HB-5 V HD 3U CHASSIS ANDBOOK 5.3.1 Redundancy load module, plug-in card The redundancy load module does not have a microprocessor, I2C bus or an alarm line. It will not be recognised by the ViaLiteHD SNMP and web controller or included in the GUI. The alarm line of the module is resistively pulled down. -
Page 18: Redundancy Load Module, Setting The Load Dip Switches
HRK3-HB-5 V HD 3U CHASSIS ANDBOOK 5.3.4 Redundancy load module, setting the load DIP switches Detail of the DIP switch positions are given in section 5.3.3. If you wish to activate any of the resistive loads follow the sequence below. - Page 19 HRK3-HB-5 V HD 3U CHASSIS ANDBOOK HPS-CS-3 with supplied mounting bracket (power lead not shown)
-
Page 20: Installation Guide
HRK3-HB-5 V HD 3U CHASSIS ANDBOOK Installation Guide Chassis Installation The ViaLiteHD Power Supply Modules do not have an isolating switch on the mains voltage inlet. For this reason, the ViaLiteHD Chassis must be installed within easy reach of a clearly labelled dual pole mains isolation switch, which supplies the equipment. -
Page 21: 5Hp Blindmate Plug-In Modules (Slots 1-13)
HRK3-HB-5 V HD 3U CHASSIS ANDBOOK To remove a 5HP Standard module Disconnect any cables if necessary Push the release button of the module handle down and simultaneously pull the top of the handle forwards. Apply pressure via the handle and gently withdraw the module from the chassis. -
Page 22: 7Hp Standard Plug-In Modules (Slot 14 Only)
HRK3-HB-5 V HD 3U CHASSIS ANDBOOK 7HP Standard Plug-in Modules (slot 14 only) All ViaLiteHD plug-in modules are hot-swappable, so it is not necessary to power-down the chassis before inserting a module. All standard optical connectors are retained by the module. So it will be necessary to either disconnect any cables or have a sufficiently long service loop. -
Page 23: 5Hp Blanking Panel Installation (Slots 1-13)
HRK3-HB-5 V HD 3U CHASSIS ANDBOOK 5HP blanking panel installation (slots 1-13) Blanking panels should be the last panel installed into your chassis To install the blanking panel Firstly inspect the blanking panel ensure that the plastic barbs are in good condition ... -
Page 24: Separate Blindmate Panels
HRK3-HB-5 V HD 3U CHASSIS ANDBOOK Separate blindmate panels If you wish to pre-populate and cable your blindmate chassis in advance, chassis plates can be purchased as spares, details below. PPM part number 85058 ViaLiteHD, Chassis plate, Blindmate, 1 * SMA 50ohms, 1 * SC/APC ... -
Page 25: Typical Redundancy Configurations
HRK3-HB-5 V HD 3U CHASSIS ANDBOOK 6.11 Typical redundancy configurations The chassis configuration below can be used to provide redundant fibre optic links by the use of ViaLiteHD chassis, with transmitters, receivers, splitters and switches. Illustrated below are some popular configurations. -
Page 26: Six 1:1 Redundant Transmitters, Blindmate Modules
HRK3-HB-5 V HD 3U CHASSIS ANDBOOK 6.11.4 Six 1:1 redundant transmitters, blindmate modules Six 1:1 redundant transmitters using blindmate plug in modules and splitters, viewed from rear of chassis 6.11.5 Four 1:1 redundant receivers, standard modules The blank slot can be used as a storage slot for a hot spare Four 1:1 redundant receivers using standard plug in modules and switches, viewed from rear of chassis 6.11.6... -
Page 27: Six 1:1 Redundant Receivers, Standard Modules
HRK3-HB-5 V HD 3U CHASSIS ANDBOOK 6.11.7 Six 1:1 redundant receivers, standard modules Six 1:1 redundant receivers using standard plug in modules and switches, viewed from rear of chassis 6.11.8 Six 1:1 redundant receivers, blindmate modules SLOTS RF Port Fibre optic port... -
Page 28: Four 1:1 Redundant Links, Blindmate Modules
HRK3-HB-5 V HD 3U CHASSIS ANDBOOK 6.11.9 Four 1:1 redundant links, blindmate modules Four 1:1 redundant links using blindmate modules, splitters and switches, viewed from rear of chassis... -
Page 29: Six 1:1 Redundant Links, Blindmate Modules
HRK3-HB-5 V HD 3U CHASSIS ANDBOOK 6.11.10 Six 1:1 redundant links, blindmate modules Six 1:1 redundant links using blindmate modules, splitters and switches, viewed from rear of chassis... -
Page 30: Shock And Vibration
HRK3-HB-5 V HD 3U CHASSIS ANDBOOK 6.12 Shock and vibration ViaLiteHD modules have been designed and tested to operate under significant mechanical stress; the tests run far exceed normal ground fixed operational use. This has been done to assure the robustness and reliability of the designs. Below are detailed the tests undertaken. - Page 31 Sample plot of Half Sine Shock in Y+ axis No measureable change in RF power level was detected. The system under test passed all the vibration and shock tests, detailed above. A full test report is available, contact ViaLite Communications for more details.
-
Page 32: Part Numbering
HRK3-HB-5 V HD 3U CHASSIS ANDBOOK Part Numbering ViaLiteHD Chassis, part numbering ViaLiteHD Power supply, part numbering... -
Page 33: Maintenance And Fault-Finding Guide
Return the module to ViaLite Communications Failed Module. or your local agent. In the event of any problems or queries about the equipment, contact ViaLite Communications or your local agent. For module fault finding information see module handbooks... - Page 34 Claims must be made promptly, and during the warranty period. IMPORTANT:- Please contact both your selling agent and ViaLite Communications prior to returning any goods for Warranty or Non-Warranty repairs. Goods will not be accepted without a valid Goods Return Number (GRN).
