Summary of Contents for comfortel CINDERALLA
- Page 1 CINDERALLA OWNERS GUIDE PEDICURE SPA These instructions show how to install and maintain your comfortel product. Specific adjustments vary according to each model. www.comfortel.com.au...
- Page 2 THIS MANUAL IS FOR: CINDERALLA Code: 6715 Dimensions: W: 75cm L: 140cm The Cinderella is one of the latest additions to our exclusive range of pedicure spas. Featuring Shiatsu massage, manicure armrests, adjustable footrest and full electric seat and back adjustment.
-
Page 3: Table Of Contents
PEDICURE SPA - INSTALLATION ............7 PEDICURE SPA - CONFIGURATION ..........8 OPERATING THE PEDICURE SPA ............9 OPERATION - MASSAGE AND SEAT ADJUSTMENT ......10 EXTRACTION PUMP - OPTIONAL .............11 CLEANING AND MAINTENANCE CLEANING AND MAINTENANCE ............12 NOTE PURCHASE DATE ....................INVOICE NUMBER ................... www.comfortel.com.au... -
Page 4: Warranty Period By Product
Comfortel Furniture Pty Ltd. shall not be liable for incidental or consequential damages in connection with or arising out of the use of this document and the program material. -
Page 5: Safety Precautions
13. This unit must be plumbed by a licensed plumber. PREGNANT CLIENTS SHOULD NOT USE MASSAGE FUNCTIONS C A U T I O N NEVER USE ANY OF THE PLUMBING FITTINGS (TAPS, DIVERTER ETC) OR THE FOOTREST TO LIFT THE PEDICURE SPA. www.comfortel.com.au... -
Page 6: Positioning
POSITIONING POSITIONING DIAGRAM A DIAGRAM B Cinderalla Spa Side View Cinderalla Spa Above View WALL 1/2” male hot & cold inlets COLD Mixer tap 32/40mm waste pipe Drain Whirlpool pump ø75mm P TRAP 470mm 750mm 1400mm • Allow 470mm of space behind your Spa to provide room for recline of back rest. -
Page 7: Pedicure Spa - Installation
SPA ASSEMBLY Mixer tap Pipeless Water Jet • Allow for the necessary room around the unit for free movement. Spa On/Off Drain open/close Adjustable foot-rest Drain plug Hand held shower Diverter - hand held Water inlet spout shower/water inlet www.comfortel.com.au... -
Page 8: Pedicure Spa - Configuration
PEDICURE SPA - CONFIGURATION DIAGRAM H From rear of spa www.comfortel.com.au... -
Page 9: Operating The Pedicure Spa
Hand held shower Diverter - hand held shower/water inlet Water inlet spout C A U T I O N ALWAYS CHECk WATER TEMPERATURE BEFORE USE; HOT WATER CAN BURN SkIN. WATER TEMPERATURE SHOULD NOT EXCEED 41° C (105° F). www.comfortel.com.au... -
Page 10: Operation - Massage And Seat Adjustment
Rolling massage On/Off - anti-clockwise (Medium) Rolling massage On/Off - anti-clockwise (High) Rolling massage On/Off - clockwise (Light) Rolling massage On/Off - clockwise (Medium) Rolling massage On/Off - clockwise (High) T I P REMEMBER TO TURN MASSAGE OFF WHEN CLIENT LEAVES THE CHAIR www.comfortel.com.au... -
Page 11: Extraction Pump - Optional
Medium Water Temperature 35°C W A R N I N G Electric Class THIS IS A GENERAL WARNING THAT Type FAILURE TO FOLLOW INSTRUCTIONS COULD RESULT IN POOR FUNCTIONING OF THE UNIT. Noise Level 40dBA Net Weight 3.5 KG www.comfortel.com.au... -
Page 12: Cleaning And Maintenance
For more information about our products and services, visit our showroom or to contact us visit us at www.comfortel.com.au. Please note: your warranty does not cover wrinkling, creasing, soiling, fading, pulls, tears or cuts. Fair wear and tear is not covered by your warranty. - Page 13 Allenby Gardens, SA 5009 Slacks Creek, QLD 4127 Bentley, WA 6102 Onehunga, Auckland, NZ Ph: 03 8581 8111 Ph: 02 9966 5900 Ph: 08 7225 8998 Ph: 07 3209 1444 Ph: 08 9258 4446 Ph: 09 525 3357 www.comfortel.com.au www.comfortel.com.au Last Updated: 27/02/15...
